- Page 1 ACCESSORIES III HD El-kit: tilt-, recline- and leg support control Mounting Descriptions MD0187 UK 2024-02...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION THE NETTI EL-KIT - ELECTRICAL COMPONENTS SPECIFICATION OF THE ELECTRICAL COMPONENTS MOUNTING NETTI EL-KIT ON NETTI III START BY REMOVING CUSHIONS AND WHEELS REMOVE TILT GAS SPRING REMOVE RECLINE GAS SPRING REPOSITION REAR CROSS BAR MOUNT TILT ACTUATOR... -
Page 3: Introduction
1. INTRODUCTION Please study this mounting Netti El-kit is a kit for Netti multi-functional description and pay careful manual wheelchairs for wheeled transport for attention to the user manual partially or fully immobile persons with physical for the wheelchair where the and/or mental disabilities. -
Page 4: The Netti El-Kit Electrical Components
2. THE NETTI EL-KIT ELECTRICAL COMPONENTS Pos. 1 – 1 Control-box complete Pos. 2 – 1 Charger Pos. 3 – 2 Leg support – actuator contacts with bracket Pos. 4 – 1 Remote control Pos. 5 – 1 Charging socket Pos. -
Page 5: Specification Of The Electrical Components
The actuator socket bracket for the leg supports are fixed on each side of the front cross tube at the seating frame. Socket for the leg Leg support support Model: MD0187 Netti El-kit Language: English Version: 2024-02 My-Netti.com... -
Page 6: Mounting Netti El-Kit On Netti
3. MOUNTING NETTI EL-KIT ON NETTI III START BY REMOVING: • cushions and head support • arm supports and arm support brackets • leg supports • wheels • tilt handle and recline handle with wires • seat plate - for easier access to the rest •... - Page 7 It is moved rearwards to prevent conflict with the recline actuator. 4pc M8 screws 6 mm Allen key Re-tighten all crossbars that has been loosened firmly. Model: MD0187 Netti El-kit Language: English Version: 2024-02 My-Netti.com...
-
Page 8: Remove Recline Gas Spring
M8 lock nut (orange) as shown. Complete stripped down Netti III frame ready for mounting the el-kit. Model: MD0187 Netti El-kit My-Netti.com Language: English Version: 2024-02... - Page 9 16 mm open end spanner. Fix the lower part of the tilt actuator to the bracket mounted (here illustrated in blue). M10x37 bolt and M10 lock nut. 16 mm open end spanner. Model: MD0187 Netti El-kit Language: English Version: 2024-02 My-Netti.com...
- Page 10 Fix the recline actuator head in the recline bracket sitting on the lower chair-back crossbar with a spring release bolt that is pushed through the bracket and through the actuator head. Model: MD0187 Netti El-kit My-Netti.com Language: English Version: 2024-02...
- Page 11 The box is labelled for each feature. Charge and check that all functions work correct. Route all cables to prevent them from getting pinched or getting caught on other objects when moving the chair. Model: MD0187 Netti El-kit Language: English Version: 2024-02 My-Netti.com...
- Page 12 4. MOUNTING NETTI EL-KIT ON NETTI V START BY REMOVING: • cushions, • head support • arm supports • leg supports • wheels • tilt and recline handles and wires • tilt and recline gas cylinders 4.1 MOUNT TILT ACTUATOR BRACKET...
-
Page 13: Mount Tilt Actuator
M6 x 22 mm hex socket screw inserted through the tilt limiter disk and into the nut sitting in the seat frame profile. 5 mm Allen key Model: MD0187 Netti El-kit Language: English Version: 2024-02 My-Netti.com... -
Page 14: Mount Control Box
Fix the control box bracket to the crossbar with 2 bolt bows into 4 pc M6 lock nuts 10 mm open end spanner Fix the control box to the bracket with 4 pc POZ 4,2 x 19 Model: MD0187 Netti El-kit My-Netti.com Language: English Version: 2024-02... -
Page 15: Mount Recline Actuator
Route all cables with the wiring strips to prevent them from getting pinched or getting caught on other objects when moving the chair. Model: MD0187 Netti El-kit Language: English Version: 2024-02 My-Netti.com... - Page 16 FRONT VIEW OF NETTI V WITH EL KIT MOUNTED. The leg supports are not hooked on. REAR VIEW OF NETTI V WITH EL KIT MOUNTED. The leg supports are not hooked on. Model: MD0187 Netti El-kit My-Netti.com Language: English Version: 2024-02...
-
Page 17: Use Of The Netti El-Kit
LED will light up for a short while to indicate that a key lock is active. • To unlock: press both channel buttons at the same time for 3 seconds until the alert indicator LED is switched off. Model: MD0187 Netti El-kit Language: English Version: 2024-02 My-Netti.com... -
Page 18: Charger
Charge the batteries before first use. Automatic battery disconnect: To prevent deep discharge and protect batteries, the battery automatic goes into DEEP SLEEP if there is no operation within 30 minutes after power on. Model: MD0187 Netti El-kit My-Netti.com Language: English Version: 2024-02... -
Page 19: Troubleshooting El Functions
If the actuator is not working in any other outlets, it is defect and should be returned to the supplier for replacement. The procedure above is to be followed for all the actuators. Troubleshooting for Netti electrical equipment: Model: MD0187 Netti El-kit Language: English Version: 2024-02 My-Netti.com... - Page 20 EU Distributor Manufacturer of Netti: Alu Rehab ApS Alu Rehab AS Kløftehøj 8 Bedriftsvegen 23 DK-8680 Ry N-4353 Klepp Stasjon Denmark Norway info.ry@meyragroup.com post.klepp@meyragroup.com T: +45 87 88 73 00 T: +47 51 78 62 20 F: +45 87 88 73 19 my-netti.com my-netti.dk My-Netti.com...
