6

Operation

6.1

Charging process

To successfully charge the vehicle, proceed with the following
steps:
▶ Unplug the charging coupler from the parking holder.
CAUTION
Incorrect use!
To avoid tripping or cable breakage:
▶ Completely unwind the charging cable.
▶ Do not coil the cable too tightly.
Fig. 46 Charging cable handling
▶ Unlock the Power Charge 7000i with the RFID card, the
app, or via the external blocking device. This step is
optional ( Fig. 47 and 6.1.5, page 42).
▶ Plug the charging cable coupling into your vehicle.
When the charging process is completed, proceed with the
following steps:
▶ Disconnect the charging cable from the vehicle.
▶ Wrap the charging cable on the Power Charge 7000i.
▶ Plug the charging coupler into the parking holder.
Power Charge 7000i – 6721849906 (2022/11)

6.1.1 Charging process cancellation

There are three ways to cancel the charging process:
4. By using the controls in the vehicle. Additional information
can be found in the operating instructions of the vehicle.
5. By switching off the building circuit breakers to disconnect
the Power Charge 7000i from the power supply voltage.
6. By locking the charging system on the optional external
locking device.
0010044562-001
