CEMB C350 US Use And Maintenance Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Use and maintenance manual
C350 US
CEMB S.p.A.
Via Risorgimento, 9
23826 Mandello del Lario (LC) ITALY
Telefono: + 39 706369 Fax: + 39 0341 700725
www.cemb.com garage@cemb.com
The Manufacturer declines all liability for any damage to people or property caused by incorrect use of this product.
Subject to change without prior notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C350 US and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CEMB C350 US

Summary of Contents for CEMB C350 US

  • Page 1 Use and maintenance manual C350 US CEMB S.p.A. Via Risorgimento, 9 23826 Mandello del Lario (LC) ITALY Telefono: + 39 706369 Fax: + 39 0341 700725 www.cemb.com garage@cemb.com The Manufacturer declines all liability for any damage to people or property caused by incorrect use of this product.
  • Page 2 Istruzioni originali Translation of the original instructions Traduction de la notice originale Übersetzung der Originalanweisungen Traducción de las instrucciones originales Tradução das instruções originais...
  • Page 3 Use and maintenance manual General Index FOREWORD GENERAL PURPOSE OF THE MANUAL WHERE AND HOW TO KEEP THE MANUAL MANUAL UPGRADES COLLABORATION WITH USERS MANUFACTURER MANUFACTURER’S RESPONSIBILITY AND WARRANTY 1.7.1 Terms of warranty TECHNICAL ASSISTANCE SERVICE COPYRIGHT MACHINE DESCRIPTION TECHNICAL SPECIFICATIONS DIMENSIONS COMPONENTS STARTING...
  • Page 4 5.11.1 Presetting of tolerance on the machine 5.11.2 Value of static unbalance, correlated with eccentricity 5.11.3 Value of unbalance corresponding to eccentricity MENU MENU ACCESS DIAGRAM STATISTICS CALIBRATIONS 6.3.1 Sensors calibration 6.3.1.1 Distance gauge calibration 6.3.1.2 Diameter gauge calibration 6.3.1.3 Width gauge calibration 6.3.2 Balancing machine calibration...
  • Page 5 9.1.2 Safety rules 9.1.3 Replacing fuses 9.1.4 Cleaning the screen DISPOSAL 10.1 DISPOSING OF THE BALANCER 10.2 DISPOSING OF ELECTRONICS COMPONENTS SPARE PARTS 11.1 IDENTIFICATION AND ORDERING METHOD ATTACHED DOCUMENTATION...

  • Page 6: Purpose Of The Manual

    Use and maintenance manual 1. Foreword This manual is an integral part of the INSTALLATION manual which should be consulted concerning starting and using the machine safely. Read carefully before continuing. GENERAL The machine has been constructed in conformity with the current EC Directives and the technical standards im- plementing the requirements, as stated in the declaration of conformity issued by the manufacturer and attached to the manual.

  • Page 7: Where And How To Keep The Manual

    Use and maintenance manual WHERE AND HOW TO KEEP THE MANUAL This manual (and relative attachments) must be kept in a safe and dry place and must always be available for consultation. Make a copy and keep it in the archive. When exchanging information with the manufacturer or the technical assistance staff authorised by the former, quote the rating plate information and the serial number of the machine.

  • Page 8: Technical Assistance Service

    Use and maintenance manual The manufacturer declines all direct and indirect liability caused by: ▪ use of the machine in a different way from that indicated in this manual ▪ use of the machine by people who have not read and fully understood the contents of this manual ▪...

  • Page 9: Machine Description

    Use and maintenance manual 2. Machine description It is used to balance the wheels of cars, vans, 4-WD, motorcycles and scooters. The wheels must weigh less than 200 kg. and, when fitted on the balancing machine, must not interfere with any fixed part of the machine, excluding the shaft and support adaptor.
  • Page 10 Use and maintenance manual COMPONENTS TOUCH CONTROL PANEL WEIGHT-TOOL HOLDER AUTOMATIC GAUGE GAUGE INDEX LOCK NUT WEIGHT POSITIONING LASER LA SONAR EMS SONAR Machine description...
  • Page 11 Use and maintenance manual 3. Starting Before switching on the machine, make sure that all the connections described in the INSTALLATION chapter have been made correctly. The following operations involve a potential risk for the operator, given the presence of voltage on the equipment. The Personal Protective Equipment described in the INSTALLATION manual must be worn and work must be done with due care and attention.
  • Page 12 Use and maintenance manual 7. Position the wheel on the terminal with the inner part facing the balancer. STEEL RIMS ALU RIMS 8. Firmly attach the wheel to the balancer shaft using the lock nut. In the pneumatic version, use the specific collar provided.
  • Page 13 Use and maintenance manual 4. Correction plane identification ▪ Standard dynamic balancing using only clip-on weights: inside plane distance diameter width ▪ Standard dynamic balancing using adhesive weights or a mix of adhesive and clip-on weights: inside plane distance inside plane distance outside inside inside...

  • Page 14: Use Of The Wheel Balancer

    Use and maintenance manual 5. Use of the wheel balancer INITIAL SCREEN displays the residual out-of-balance selects the correction type car/truck selection wheel locks/unlocks main functions screen MENU ACCESS DIAGRAM spindle up indicator spindle down indicator pulling it out, it measures the wheel dimensions ( Dimensions gauge WHEEL DIMENSIONS SETTING If the machine remains on the initial screen for a certain amount of time without being used, the system is...
  • Page 15 Use and maintenance manual selects the type of weight to be applied improves the dimensional calibra- tion of large-diameter wheels such as off-road, trucks, wheels which protrude significantly from the rim. Press it several times to select the type of tyre projection (from 1.0” to 2.0”).
  • Page 16 Use and maintenance manual 5.2.2 Result of the measurement and weight application Inside unbalance indicator Outside unbalance indicator If the unbalance is out of tolerance: 1. At the end of the spin, the wheel automatically comes near to the outer side (on the inner side if the outer side is already within tolerance).
  • Page 17 Use and maintenance manual selects the correction mode. When the mode is changed, the unbalance values are recalculated automatically on the basis of the previous spin. Simultaneous display of the dynamic+static unbalance can be enabled through the special function in Setup ( STATIC ALWAYS ENABLED car/truck selection wheel locks/unlocks...
  • Page 18 Use and maintenance manual 2. The symbol is shown on the display on the side corresponding to the active correction plane. If laser option = OFF: after positioning and locking the wheel, apply the weight vertically at the top. If laser option = ON: apply the clip-on weights at 12 o’clock. If using adhesive weights, when the correction position is reached, the laser turns on indicating the point where to apply the adhesive counterweight.

  • Page 19: Static Unbalance

    Use and maintenance manual Adhesive weight at the point Clip-on weight at 12 o’clock indicated by the internal laser Adhesive weight at the point Adhesive weight at 12 o’clock indicated by the internal laser STATIC Adhesive weight at the point indicated by the internal laser After dimension acquisition in ALU mode, pressing the buttons , you can select one of the following correction modes.

  • Page 20: Multiple Users

    Use and maintenance manual HIDE THE ADHESIVE WEIGHTS (SPLIT) SPLIT is only possible in the event of static unbalance or ALU external side and is used to hide any adhesive weights correcting unbalance behind the rim spokes. 1. Position the static unbalance or outside ALU in the in the correction position: 2.

  • Page 21: Automatic Minimization Of Static Unbalance

    Use and maintenance manual AUTOMATIC MINIMIZATION OF STATIC UNBALANCE Initial unbalance 50° Phase shift Possible approximations static residue static residue static residue static residue With traditional wheel Choice with minimum balancer static unbalance This program is designed to improve the quality of balancing without any mental effort or loss of time by the operator.
  • Page 22 Use and maintenance manual 5.10 WHEEL ECCENTRICITY MEASUREMENT AND OPTIMISATION (OPTION) 5.11.1 Whel eccentricity measurement If the EMS sonar (Eccentricity Measurment System) is present and correctly positioned in the centre of the tread, it automatically measures the wheel eccentricity ( during the unbalance ECCENTRICITY AND MATCHING: THEORY) measurement spin.
  • Page 23 Use and maintenance manual Repeat the lateral runout measurement, making sure that the sonar reads all points of the wheel (green sonar icon 5.10.2 Lateral runout measurement procedure Lower the guard to position the lateral sonar in front of the tyre side, possibly in an area without any raised wri- ting, with the aid of the laser pointer.
  • Page 24 Use and maintenance manual 5.10.3 Wheel eccentricity optimisation This procedure is used to assess the possibility of rotating the tyre on the rim to reduce the eccentricity of the wheel to a minimum. The eccentricity optimisation procedure is normally recommended for first harmonic values greater than the maximum limit RUNOUT SETUP - FIRST HARMONIC LIMIT Follow the simple instructions shown on the monitor.
  • Page 25 Use and maintenance manual Example 2 wheel Ideal wheel Rim + 0.8 mm Tyre - 0.6 mm Wheel + 0.3 mm Eccentricity of the single items has been compensated. tyre The wheel is acceptable. rotation axle Example 3 wheel Ideal wheel Rim 0 mm Tyre + 1.2 mm Wheel + 1,2 mm...

  • Page 26: Menu Access Diagram

    Use and maintenance manual 6. Menu MENU ACCESS DIAGRAM PASSWORD : press in sequence the following buttons: Menu...
  • Page 27 Use and maintenance manual STATISTICS resets the relative counter For the TOTAL counters a correct password must be entered returns to the previous screen returns to the measurement screen DAILY N° OF RUNS: Indicates the number of runs performed as from switching on the machine. Such parameter is automatically reset after switching the machine off.
  • Page 28 Use and maintenance manual 6.3.1.3 Width gauge calibration When calibrating the width gauge, set a measurable dimension as follows: Distance: Gauge at rest → “0” sonar Gauge at rest Calibro a riposo 0 Sonar dIS. Flange plane Piano Flangia Check the calibration by making a measurement on a wheel with a steel rim of known width. Should the measurement be incorrect, correct the calibration value proportional to the error.

  • Page 29: Acoustic Signal

    Use and maintenance manual 7. Setup The Setup screen provides the user with many possibilities required for presetting the machine according to his own requirements. Such settings remain unaltered even when the machine is switched off. Enabled buttons: returns to measurement screen returns to previous screen selects the parameter.
  • Page 30 Use and maintenance manual 7.5.2 Radial runout setup Enable the display of a menu where to set the following parameters: Radial runout Enables/disables radial runout measurement Limit of first harmonic car This is the limit of the first harmonic above which it is recommended to rotate the tyre on the rim by 180°...

  • Page 31: Balancing Setup

    Use and maintenance manual 7.6.5 Date Enables/disables date display. 7.6.6 Time Enables/disables time display. 7.6.7 LT automatic If set to ON and with EMS enabled, the wheel bulges are automatically calculated; the calculated value can however be modified by pressing the button WHEEL DIMENSIONS SETTING 7.6.8 Power-on screensaver...

  • Page 32: Inconsistent Unbalance Readings

    Use and maintenance manual 8. Diagnostics INCONSISTENT UNBALANCE READINGS In some cases, when a wheel that has just been balanced is repositioned on the balancer, the machine can detect an unbalance. This is not a machine problem but is due to faulty mounting of the wheel on the flange. In other words, when mounting the wheel after initial balancing, it has taken another position with respect to the balancer shaft axis.
  • Page 33 Use and maintenance manual ▪ Err. 11 Speed too high error Check if there is any damage or dirt on the timing disc ▪ Check in self-diagnostics that the encoder functions properly During unbalance measurement rotation, ▪ Replace the computer board wheel speed is more than 270 rpm Err.14 / Unbalance measurement error...

  • Page 34: Maintenance

    Use and maintenance manual 9. Maintenance GENERAL Before performing any maintenance operations, make sure the machine has been disconnected from the mains power supply. Always use the Personal Protective Equipment indicated in the Installation Manual. 9.1.1 Introductory notes This machine has been designed so as not to require routine maintenance, apart from accurate periodic cleaning. It is important to keep the machine perfectly clean in order to prevent dust or impurities from compromising the operation of the balancer.

  • Page 35: Disposing Of The Balancer

    Use and maintenance manual 9.1.3 Replacing fuses Some protection fuses are located on the power board (see wiring diagrams) accessible by dismantling the weight shelf). If fuses require replacement, use ones with an identical current intensity. 9.1.4 Cleaning the screen Use a soft cloth and NON-ABRASIVE commercial glass/plastic cleaning spray or ethanol or natural detergents.

  • Page 36: Spare Parts

    Use and maintenance manual 11. Spare parts 11.1 IDENTIFICATION AND ORDERING METHOD The various parts can be identified using the exploded drawings, the electrical drawings and diagrams in the ma- chine technical file which is archived by the Manufacturer to which a request can be made. For off-the-shelf parts, the technical manuals or the supplier’s original documents can be provided if the Manu- facturer deems this to be useful.
