INSTALLATION GUIDE
SCXI -1357/1358 K
™
Introduction
SCXI ™ is a trademark of National Instruments Corporation. Product and company names mentioned herein are trademarks or trade names of their
respective companies.
322336A-01
This guide describes the components of the SCXI-1357 and
SCXI-1358 kits.
With the SCXI-1357/1358 kit, you can connect your NI-DMM to an
SCXI-1127 module. You can also use the SCXI-1357/1358 to create a
chassis-wide high-voltage backplane.
The SCXI-1357 kit consists of the following components:
•
Two 8-position high-voltage analog bus (HVAB) plugs
•
One 2-slot HVAB backplane adapter
•
Two 1-slot HVAB backplane adapters
•
SH9MD-9MD cable
•
HV8-BAN4 cable (not in multichassis kit)
•
HV8-HV8 cable (in multichassis kit only)
The SCXI-1358 kit consists of the following components:
•
Three 8-position high-voltage analog bus (HVAB) plugs
•
One 8-slot HVAB backplane adapter
•
One 2-slot HVAB backplane adapter
•
Two 1-slot HVAB backplane adapters
•
SH9MD-9MD cable
•
HV8-BAN4 cable (not in multichassis kit)
•
HV8-HV8 cable (in multichassis kit only)
If you ordered only the SCXI-1357/1358 backplane, you will have the
HVAB plugs and the backplane adapters, but no cables.
Use the HVAB plugs to interconnect the HVAB signals of the HVAB
backplane adapters. The HVAB backplane adapters, when installed and
© Copyright 1999 National Instruments Corp. All rights reserved.
IT
January 1999
