Summary of Contents for THOMSON VTH7090
- Page 1 Manuel d’utilisation Bedienungsanleitung Manuale di utilizzazione User manual Gebruiksaanwijzing Manual de utilización Manual de utilização Eγχειρί ιο χρήσης ®...
- Page 2 DEUTSCH ....ITALIANO ....ENGLISH ....
- Page 3 0000 index mark exit menu 0/--...
-
Page 5: Table Of Contents
10 cm 10 cm Recording ......12 Preparing the recording - Simple recording, with automatic stop, "S.O.S. -
Page 6: Before You Start
Installation efore you start Thank you for purchasing one or our videos. Unpack the set completely and tear off the protection films. Video recorder Remote control 2 non-rechargeable batteries, type AA Power cord Coaxial cable (75 Ω) Scart cable (21 pins connected) -
Page 7: Making The Connections
1 Disconnect the aerial cable from your TV set and reconnect it to the IN socket of your video recorder. 2 By means of the coaxial cable supplied, connect the video recorder's OUT socket to the... -
Page 8: Initial Installation
Installation nitial Installation As the video recorder has not been preset to receive channels from your region, you have to install the channels yourself by carrying out the automatic channel installation procedure described below. Auto Installation 1 Switch on the television. -
Page 9: Clock Setting
C C (10) or B B (8). 5 If you wish to change the name of the channel, call up the Name line and with keys C C (10) or B B (8), scroll the names available, or you may enter the name with keys 1 and 2 and press B (8) to pass on to the next character. -
Page 10: S Atellite/Cable Receiver
AV2 of the video recorder by means of a SCART cable. Position the satellite receiver on top of the video recorder and see that you leave the infrared windows uncovered. For the other possible connection schemes, refer to the set-up manual of your satellite receiver. -
Page 11: Video Recorder Settings
10 If the satellite receiver uses the channel 12, select YES with the ok (11) key. 11 Press ok (11) key again. Wait for quite a long time (up to 15 minutes) until a message tells you that the storage of your satellite channels is completed. -
Page 12: Other Sets
With compatible camcorders, the PAUSE socket facilitates copying by able to reproduce all the triggering the recording mode of the video recorder as soon as the sound effects of your tapes camcorder switches over from PAUSE to PLAY. The video recorder (musicals, films...) on your... -
Page 13: Using The Remote Control
Your remote control may also be used to control various other televisions, video recorders, and THOMSON DVD players. In order to be able to do this, you must programme the remote control with one of the codes provided above or on page 26. -
Page 14: Use
Right channel Mono track Display of clock or time: the time elapsed from the beginning of the tape in play or record mode, the time remaining (r) before end of tape on STOP. On the screen... -
Page 15: Viewing A Tape
Press key REW. (23) or F.FWD. (25) to change the speed and direction of slow motion. The inner knob JOG fitted to the front of the video recorder may also be used to explore an image by image sequence in both forward or backward play. -
Page 16: Recording
REW., F.FWD., STOP, PLAY (23, 25, 27, 24). 2 Select the channel to be recorded with the key pr+ / pr- (19) or the keys 0 to 9 (21), or else select the AV socket to which the unit is connected with key AV (22). -
Page 17: Naviclick
1 Press the key NAVICLICK to display the NAVICLICK page. 2 Use key pr+ / pr- (19) or C C (10) or B B (8) ) to change from one channel to another. This function is available on most of the channels displaying the Teletext (for satellite channels previously select SA with key AV). -
Page 18: Programming A Recording
(single, daily, weekly), recording speed (SP/LP), recording sub-titles (from Teletext) at the same time as the programme. 4 Press ok (11) to verify your recording time on the Timer review line : if not, press key exit (12). -
Page 19: Recording Programmed By An External Connected
The recording of a programme can be triggered by a satellite receiver or any other unit supporting this feature and connected to socket AV1 or AV2 by means of a Scart cable. This connection scheme prevents you from having to programme both units. -
Page 20: Tape Library
1 Load the tape. 2 Select New tape in the menu which is displayed then press ok (11). Should a message appear to inform you that the tape library is full, you will not be able to add a new tape. -
Page 21: Looking For A Recorded Programme
• Edit title: to modify its title, • Delete title: to delete it from the memory. The video recorder will automatically give the exact name to the programme you have recorded if this programme is shown on a channel where the NAVICLICK function works. -
Page 22: Tape Control
(hired films for example), you must enter the cassette type. The video recorder will then be able to accurately calculate and display the elapsed and remaining time of your tape. To enter the recording time of the tape, press keys C (10) or B (8), or the keys 0 to 9. Auto sequence memory Refer to page 24. -
Page 23: Index Search - Introduction Search - Clear Index - Access To Counter - Access To Remaining Time - Tape Type - Auto Sequence Memory Sound Adjusting
- TRACK 1: sound of the left track, - TRACK 2: sound of the right track, - MIX: sound of the mixed Hi-Fi and mono tracks. When viewing a HI-FI STEREO tape, you may select the sound tracks with key AV ( Readjusting the recording HIFI CONTROLS Stereo The sound level varies with each channel. -
Page 24: Picture Adjusting
1 During play, select Tracking from the P menu. ICTURE 2 With keys (10) or (8), adjust tracking. 3 Press key 0000 (16) to return to standard tracking or select Tracking line and display Auto with keys (10) or (8). Sharpness To improve picture clearness in play. -
Page 25: Copy Mode
S-VHS cassette If you should wish to read a cassette recorded in a S-VHS format, tick a box with the key ok (11) (þ). NTSC TV To view a cassette recorded in the NTSC 3.58 format on a NTSC TV connected to AV1. -
Page 26: Tracking - Sharpness - Stability - Format - S Cassette - Vhs - Tvntsc - Copy - Black And White - Colour System Adjusting Preferences
REFERENCES Tape library Tick the box in the Tape library line with the key ok (11) (þ) to have a systematic display of the T menu when you load a cassette (see page 16 for more information on APE LIBRARY the tape library functions). - Page 27 Auto LP The LP function enables you to double the recording time of a video tape. Thus, an E180 tape with a three-hour recording time in SP mode can have a 6-hour recording time in LP mode.
-
Page 28: Audio Dubbing - Auto Sequence Memory.24
3 Select the connected unit (Au3 for white, red and yellow cinch sockets on the front of the video recorder; Au1, Au2 or Au4 for the sockets at the back of the unit; MIC for a microphone connected to the front of the video recorder) to monitor the sound. -
Page 29: Other Functions
Electronic lock To prevent the video recorder from being used, keys on the front can be locked. 1 Hold down the standby key B (3) on the remote control for 10 seconds and put it in a safe place. 2 Press the standby key B (3) on the remote control to unlock the video recorder. -
Page 30: More Information
SAMSUNG ........133... -
Page 31: Technical Features
In our efforts to improve the quality of our products, we reserve the right to change their features. The information contained in these instructions are therefore liable to change and are not contractual. Mains supply 200 to 240 V ±10% - 50/60 Hz... - Page 32 X100, X100PLUS SRD 500, SRD510/SRD520, SRD540, SRD545, SRD550 PACE APOLLO, MSS100, MSS200, MSS300/1, MSS500/1 MSS 1000, PRD 800, PRD 800 IRD, PRD 800+ SRD600IRD, SRD600E, SRD650E, SRD700, SRD2000 PRD690IRD, PRD900, PRD900IRD, PRD900+ SRX20016Ch, SRX20048Ch, SRX300, SRX310, SRX320 PSR800, PSR800+, PSR900, SBR99, SS-600, SS-9000...
- Page 33 THOMSON MULTIMEDIA 46 quai A. Le Gallo 92648 Boulogne Cedex France RCS NANTERRE B 322 019 464 http://www.thomson-multimedia.com 21063020 © Copyright THOMSON multimedia 2000 DAE Communication - 95000 Cergy...
