Summary of Contents for Pandora DWM-502
- Page 1 DWM . 502 Window regulator control module (5-output) USER INSTALLATION MANUAL...
- Page 2 Eurasia. Module DWM-502 is designed for sequential control 5 car window regulators in one direction, provided that the vehicle electric drives are installed. Control over this module can be performed via signal of car security system or another device when arming or closing door locks (‘negative’...
-
Page 3: Specifications
Specifications Name of parameter Value Supply voltage 9-15V Current consumption Maximum output current Type of the trigger pulse Positive or negative, not less than 300ms Pulse type on ‘Expansion’ output Negative, no less than 500ms, 200mA Pulse type on ‘Status’ output Negative, during operation, 200mA Operation control Electromagnetic noise of the engine... - Page 4 Module operation features Module DWM-502 can be controlled with a signal of ‘positive’ or ‘negative’ polarity. To do this, connect the control pin of the security system to ‘Yellow’ or ‘Yellow/Black’ module pin respectively. The duration of trigger pulse must be at least 300 ms (0,3 sec.).
-
Page 5: Module Installation
Module installation It should be installed in the car interior in place that is protected from moisture and dust. When connecting, pay attention to the quality of connections. All wiring must be insulated on the outside when installation is finished. Throughout the metal bulkhead, wiring should pass only through special rubber bushings. -
Page 6: Storage And Transportation Rules
This warranty does not include batteries of the remotes, as they have their own service life time. Maintenances and repairs of the module with expired warranty period are carried out at the expense of the user on a separate contracts between the user and the installer/service center. Window regulator control module DWM-502... -
Page 7: Acceptance Certificate
Acceptance certificate Pandora DWM-502 is in conformity with Electromagnetic Compatibility Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC Serial number ___________________________________________________________________ Date of production _______________________________________________________________ Responsible person’s signature (stamp) Packager ________________________________________________________________________ Signature (personal stamp) Warranty card Model Pandora DWM-502 Serial number ____________________________________________________________________ Date of purchase «____»... - Page 8 Connection scheme of module DWM-502 White Window regulator 1 White/Red Grey Window regulator 2 Grey/Red Blue Window regulator 3 Blue/Red Green Window regulator 4 Green/Red Orange Window regulator 5 Orange/Red Start input ( Yellow Engine Yellow/Black Start input ( noise...
