- Page 1 866.332.2403 (TOLL FREE) (707) 640.29.05 (Option 4) Direct Line for the Design Department; 7am – 7pm Pacific Time, Monday-Saturday ASSEMBLY INSTRUCTIONS FOR THE CUSTOM SCISSOR TRUSS PAVILION...
- Page 2 Insert the carriage bolts into the holes and lightly tap with a hammer until the square neck fit in the wood piece and the bolt head must flush with the wood piece. Finally, place the washer and the nut and carefully tighten it using a ratch with the necessary socket or a wrench. P| 1 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 3 Place the washers in their lag bolts. After that, insert the lag bolts into the holes and carefully tighten it using a ratch with the necessary socket. Use the washers only for the Wood Pieces. To install the deck screws. Insert the deck screws into the holes and carefully tighten it using a drill. P| 2 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 4 (They are unarmed) Cover Top Secondary Knee Braces Ridge Beams -A Ridge Beams -B Rafters Ceiling Fan Bases Roof Boards Fascias Roof Trims Boots Hight Wind Anchor Bases Metal Plaques -A Metal Plaques -B P| 3 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 5 CONTENT OF BOXES Qty. Description Drawings Metal Plaques -C Metal Plaques -D L -Plaques -A L -Plaques -B Metal Plaques -E Metal Plaques -F Metal Plaques -G P| 4 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
-
Page 6: Hardware List
3/8’’ x 4 ¼” bolts 3/8” x 2 ¾” bolts 5/16” x 3” Bolts 3/8” x 8 ½” Bolts 3/8” x 7 ½” Bolts 3” Deck screws 4” Deck screws 4900 2” Deck screws 6” Deck screws P| 5 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com... - Page 7 Roof Trims Boots High Anchor Bases Metal Plaques -A Metal Plaques -B Metal Plaques -C Metal Plaques -D L -Plaques -A L -Plaques -B Metal Plaques -E Metal Plaques -F Metal Plaques -G P| 6 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 8 Note: Part numbers in the Drawing are for reference only. These do not match to the numbers marked on the parts sent. P| 7 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 9 Step 2: Attach the single supports (2) to the posts with 3/8” x 9” bolts (BL1) with washer and nuts. Check the marked numbers on each support and place as drawings shown. Note: Don’t completely tighten yet the bolts – you will need the install the supports with in between blocking first. P| 8 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 10 Step 4: Use 3/8” x 9” bolts (BL1) to attach the main knee brace (4) to the supports (2,3). After that use ½” x 12” bolts (BL2) to the posts (1). Check the marked numbers on each main knee brace and place as drawings shown. P| 9 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 11 Step 5: Attach the central main knee braces (4) to the posts (1) with ½” x 16” bolts (BL3). After that use 3/8” x 9” bolts (BL1) to the supports (2,3). Check the marked on each main knee brace and place as drawings shown. P| 10 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 12 Step 6: Attach the section truss -A (5) to the posts (1) with metal plaque -A, D & E (17,20,23), 3/8” x 3 ½” lag bolts (LB2) and 3/8” x 8 ½” bolts (BL1). Check the marked on each section truss -A and place as drawings shown. P| 11 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 13 Step 8: Attach the section truss -C (5) between them with metal plaque -C (19) and 3/8” x 8 ½” bolts (BL7) & 3/8” x 3 ½” lag bolts (LB2). Check the marked on each section truss -C and place as drawings shown. P| 12 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 14 (LB2). After that use 3/8” x 7 ½” bolts (BL8) to attach the roof truss (5) to the large posts (1). Check the marked on each section -D and place as drawings shown. Note: drilling will be completed on site. Note: to reinforce the pieces between them, deck screws will be used. P| 13 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 15 Step 12: Attach the section -C with 3/8” x 8 ½” bolts (BL7) and metal plaque -C (19) to the king posts. Check the marked on each section -C and place as drawings shown. Note: repeat this step 3 time. Note: to reinforce the pieces between them, deck screws will be used. P| 14 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 16 Step 13: Attach the cover top (6) to the large posts (1) with 3” deck screws (DS1). Check the marked on each cover top and place as drawings shown. Step 14: Attach the cover top (6) to the king posts with 3” deck screws (DS1). Check the marked on each cover top and place as drawings shown. P| 15 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 17 Step 16: Attach the L-plaques -A & B (21,22) and to the roof trusses (5) with 3/8” x 3 ½” lag bolts (LB1). Check the marked on each ridge beam -A and place as drawings shown. P| 16 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 18 (LB1). Check the marked on each ridge beam -A and place as drawings shown. Step 18: Attach the metal plaque -E (23) to the ridge beam -B (9) with 3/8” x 4 ¼” bolts (BL4) and 3/8” x 3 ½” lag bolts (LB2). P| 17 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 19 Step 20: Attach the rafter (10) to the ridge beam -A (8) with 3/8” x 4 ½” lag bolts (LB5) and to the ridge beam -B (9) with 4” deck screws (DS2). Check the marked on each rafter and place as drawings shown. P| 18 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 20 Step 22: Attach the ceiling fan base (11) to the rafters (10) with 5/16” x 3” bolts (BL6). Check the marked on each ceiling fan base and place as drawings shown. P| 19 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 21 Step 24: Use 2” deck screws (DS3) to attach the fascia (13) to the roof trusses (5) and to the rafters (10). Check the marked on each fascia and place as drawings shown. P| 20 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 22 Step 25: Attach the overhang board (14) to the roof boards (12) whit 4” deck screws (DS2). Check the marked on each overhang board and place as drawings shown. Step 26: Finally, attach the boots (15) to each post with 3” deck screws (DS1). P| 21 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
- Page 23 This completes the Pavilion assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question, don't hesitate to call us (866 332 2403) or email us. We are here to support you. P| 22 CUSTOM SCISSOR TRUSS PAVILION www.ForeverRedwood.com...
