2. SPECIFICATIONS

2.1 SPECIFICATIONS
For all items except the backup current, refer to the Owner's Manual.
Backup current.........................

2.2 DISC/CONTENT FORMAT

is a trademark of DVD Format/Logo Licensing Corporation.

3. BASIC ITEMS FOR SERVICE

3.1 CHECK POINTS AFTER SERVICING

To keep the product quality after servicing, please confirm following check points.
No. Procedures
1 Confirm whether the customer complain has
been solved.
If the customer complain occurs with the
specific media, use it for the operation check.
2 Flap-mecha Check the operation of the flap mechanism.
3 DVD Play back a DVD.
(Menu operation; Title/chapter search)
4 CD Play back a CD.
(Track search)
5 FM/AM Tuner Check FM/AM Tuner action.
(Seek, Preset)
Switch band to check both FM and AM.
6 USB Check USB-memory action.
(Seek, Preset)
7 Check whether no disc is inside the product. The media used for the operating check must
8 Appearance check
See the table below for the items to be checked regarding video and audio:
Item to be checked regarding video
Block-noise
Horizontal noise
Dot noise
Disturbed image (video jumpiness)
Too dark
Too bright
Mottled color
5
6
5 mA or less
Item to be checked regarding audio
Distortion
Noise
Volume too low
Volume too high
Volume fluctuating
Sound interrupted
AVH-3800DVD/XEUR
6
7
Item to be confirmed
The customer complain must not be
reappeared.
Display, video, audio and operations must be
normal.
The flap mechanism operation must be
smooth without making the noise and
scratches.
Display, video, audio and operations must be
normal.
Display, audio and operations must be
normal.
Display, audio and operations must be
normal.
Display, video, audio and operations must be
normal.
be ejected.
No scratches or dirt on its appearance after
receiving it for service.
