- Page 1 Alpha APP 9015S & APP 9022S ® Service Power Supply Technical Manual Effective: March 2024...
- Page 2 Safety Notes Review the drawings and illustrations contained in this document before proceeding. If there are any questions regarding the safe installation or operation of the system, contact Alpha Technologies Services, Inc. or the nearest Alpha product ® sales representative. Save this document for future reference. To reduce the risk of injury or death and to ensure the continued safe operation of this product, the following symbols have been placed throughout this manual.
- Page 3 Technical Manual 016-537-B0-002, Rev. C Effective Date: March 2024 © 2024 Alpha Technologies Services, Inc., an EnerSys company. All rights reserved. Disclaimer Images contained in this manual are for illustrative purposes only. These images may not match your installation. Operator is cautioned to review the drawings and illustrations contained in this manual before proceeding. If there are questions regarding the safe operation of this powering system, please contact Alpha Technologies Services, Inc.
-
Page 4: Table Of Contents
Table of Contents Introduction ......... . 8 The Alpha APP Service Power Supply . - Page 5 Figures Fig. 1-1, Alpha APP 9015S Service Power Supply, Front Panel ......11 ®...
- Page 6 Safety Precautions • The Alpha APP service power supply must be installed and serviced by qualified personnel. ® • Always use proper lifting techniques whenever handling units, modules or batteries. • Verify the voltage requirements of the equipment to be protected (load), the AC input voltage to the power supply (line), and the output voltage of the system prior to installation.
- Page 7 Unpacking and Inspection Verify that the following items have been included in the shipping container: APP 9015S APP 9015S service power supply (p/n 016-529-20) 2. Power cord with 5-20P plug (120 VAC) (p/n 874-726-20) NEMA 5-20 Plug 3. Power cord with 6-15P plug (240 VAC) (p/n 847-727-20) 4.
-
Page 8: Introduction
Introduction The Alpha APP Service Power Supply ® The Alpha APP service power supply (SPS) is a portable device used to provide temporary power while the existing ® power supply is being serviced. The APP SPS can be used in either pole- or ground mount enclosures to provide signal processing equipment in cable television and broadband LAN distribution systems with current-limited, regulated AC power. -
Page 9: Theory Of Operation
Introduction, continued Theory of Operation The APP SPS contains a ferroresonant transformer and a resonant capacitor. (Refer to Fig. 3-1, Alpha APP 9022S ® Service Power Supply Schematic.) During AC LINE operation, utility power is fed into the primary winding of the ferroresonant transformer, T1. - Page 10 Introduction, continued 60/75/90 VAC Output Connector The 60/75/90 VAC output connector supplies up to 22 Amps of power to a service power inserter (SPI) through an output cable. Output Cables 9015S: Included with the APP 9015S is an output cable used to connect the service power supply to the SPI, via a four-pin Jones connector.
-
Page 11: Fig. 1-1, Alpha ® App 9015S Service Power Supply, Front Panel
Introduction, continued Fig. 1-1, Alpha APP 9015S Service Power Supply, Front Panel ® Output current 2. 120 / 240 V input voltage selector 3. 20 Amp AC input breaker / power switch 4. 120 / 240 V input connector 5. 60 / 75 / 90 V output selector dial 6. -
Page 12: Fig. 1-2, Alpha ® App 9022S Service Power Supply, Front Panel
Introduction, continued Fig. 1-2, Alpha APP 9022S Service Power Supply, Front Panel ® Output current 2. Output power indicator 3. 30 Amp output breaker 4. 60 / 75 / 90 V output connector 5. 60 / 75 / 90 V output selector dial 6. -
Page 13: Installation
Installation Alpha APP SPS Installation and Power Module Removal ® NOTICE: Inspect all cables before installation. Replace or repair damaged cords. WARNING! ELECTRICAL HAZARD DO NOT unplug output connector or change setting of output selector while unit is in operation! Circuit breaker must be turned off first. -
Page 14: Fig. 2-1, 20A Service Power Inserter
Installation, continued “ALT/ON” Switch “ALT/ON” Switch Anderson™ connector Anderson™ connector Jones connector accepts from power supply 25A connectors accept from power supply mating plug from APP SPS mating plug from APP SPS Fig. 2-1, 20A Service Power Inserter Fig. 2-2, 25A Service Power Inserter (shown in Alpha PWE and UPE/M enclosures) (shown in Alpha... -
Page 15: Troubleshooting
Troubleshooting Troubleshooting Guide This guide is designed to cover typical symptoms, causes, and solutions for troubleshooting the APP SPS. Alpha Technologies Services, Inc. recommends that the power supply maintenance log accompany units brought in for bench service to aid the technician in troubleshooting the problem. Symptom #1 No output to cable;... -
Page 16: App 9022S Service Power Supply Schematic
Troubleshooting, continued APP 9022S Service Power Supply Schematic The schematic below is a very high-level drawing of the input and output voltages that are possible with the APP service power supply. There are a number of power cords and switches on the front panel that can be selected by the operator depending on their application. -
Page 17: Returns, Repair, And Parts Ordering
Troubleshooting, continued Returns, Repair, and Parts Ordering Returns for Repair For units that must be returned for repair, Alpha requires a Return Material Authorization (RMA). An RMA can be ® obtained from Alpha Customer Service, using either method listed below: •... - Page 18 Tel.: Toll Free North America: +1 800-322-5742 | Outside US: +1 360-647-2360 | Technical Support: +1 800-863-3364 For more information visit www.alpha.com © 2024 Alpha Technologies Services, Inc., an EnerSys company. All Rights Reserved. Trademarks and logos are the property of EnerSys and its affiliates except Anderson™, Airpax...
