Assembly and Operating Instructions
en
Radio controlled sun protection drives with locking
system
Important information for:
• Fitters / • Electricians / • Users
Please forward accordingly!
These instructions must be kept safe for future reference.
Becker-Antriebe GmbH
Friedrich-Ebert-Straße 2-4
35764 Sinn/Germany
www.becker-antriebe.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Becker SEF T1
Summary of Contents for Becker SEF T1
- Page 1 R12/17C Version: SEF T1 Assembly and Operating Instructions Radio controlled sun protection drives with locking system Important information for: • Fitters / • Electricians / • Users Please forward accordingly! These instructions must be kept safe for future reference. Becker-Antriebe GmbH Friedrich-Ebert-Straße 2-4...
-
Page 2: Table Of Contents
Table of contents General .................................... 3 Warranty ..................................... 3 Safety instructions ................................ 4 Instructions for the user.............................. 4 Instructions for installation and commissioning........................ 4 Intended use .................................. 5 Assembling and disassembling the plug-in connecting cable.................... 6 Assembling the plug-in connecting cable .......................... 6 Disassembling the plug-in connecting cable for tubular drives dia. -
Page 3: General
General These tubular drives are high-quality products with the following features: • Optimised for sun protection applications with locking system • Locking limit position and unlocking limit position freely programmable • Automatic detection of upper limit position • Automatic detection of lower limit position when the locking system is activated •... -
Page 4: Safety Instructions
Safety instructions The following safety instructions and warnings are intended to avert hazards and to prevent property damage and personal injury. Instructions for the user General information • All work, including maintenance and cleaning, on electrical installations as well as other system parts must always be performed by authorised specialists, in particular qualified electricians. -
Page 5: Intended Use
• Moving parts of drives must be installed at a height of over 2.5 m above floor level or any other surface from which access to the drive is gained. • To ensure safe operation of the system after commissioning, the limit positions must be correctly set/ programmed in. -
Page 6: Assembling And Disassembling The Plug-In Connecting Cable
Assembling and disassembling the plug-in connecting cable Assembling the plug-in connecting cable Insert the dead connecting cable into the drive head until the locating lug clicks into place in the drive. If necessary, use a suitable flathead screwdriver to assist with insertion. Set the screwdriver into one of the two plug grooves provided for this purpose. Check that the cable is properly engaged. -
Page 7: Disassembling The Plug-In Connecting Cable For Tubular Drives Dia. 45 And Dia. 58
Disassembling the plug-in connecting cable for tubular drives dia. 45 and dia. 58 Caution Prior to disassembly, the power supply to the connecting cable must be disconnected. Insert a suitable flathead screwdriver right into the recess of the locating latch, so that the latch releases the locating lug from the plug. -
Page 8: Installation
Installation Assembling the drive Attention To connect the drive to the driven part, solely mechanical accessory components made by the drive manufacturer from the current product catalogue may be used. Prior to mounting, the fitter must ensure that the masonry and the system being motorised are sufficiently robust (drive torque plus weight of the shading solution). -
Page 9: Securing The Drive Against Axial Displacement
Securing the drive against axial displacement In order to secure the drive against axial displacement, we recommend screwing the drive adapter to the tube. Attention When drilling into the barrel, never drill near the tubular drive! Fixing the drive adapter to the barrel dia. 45 Size of drive Diameter of barrel Torque... -
Page 10: Commissioning
Commissioning Explanation of symbols UP button STOP button DOWN button Programming button The tubular drive clicks once to confirm The tubular drive clicks twice to confirm The tubular drive clicks three times to confirm 1 = direction switch 2 = radio switch Unlocked Locked Bolt... -
Page 11: Intelligent Installation Management
If several tubular drives are to be connected in parallel, you can deactivate the program- ming mode on one tubular drive by switching the radio switch to the outside position after turning the power on. Readying the tubular drive for programming with the radio switch Switch the radio switch to the inside position. -
Page 12: Setting The Limit Positions
Changing direction of rotation via the master transmitter It is only possible to change the direction of rotation if no limit position has been set. Press the UP or DOWN button. ▻ The shading solution runs in the desired direction. ►... -
Page 13: Deleting The Limit Positions
Installation step 4: Use the DOWN button to run the bolt in the down direction and disengage it from the bolt mechanism, and then stop the tubular drive immediately. Now press the pro- gramming button and also the DOWN button. The unlocking limit position is now saved and the tubular drive makes a "click"... -
Page 14: Intermediate Position Ii In The Up Direction
Intermediate position II in the up direction The intermediate position II is any shading solution position of your choosing. It is not pos- sible to set an intermediate position II in the area of the limit position. Both limit positions must be set before the intermediate position II is set. -
Page 15: Deleting Transmitters
Deleting transmitters Deleting individual transmitters The programmed master transmitter cannot be deleted. It can only be overwritten (see Programming the master transmitter [} 11]). Press the programming button on the master transmitter for 3 seconds. ▻ The tubular drive makes a “click” sound to confirm. Now press the programming button of the transmitter to be deleted for 3 seconds. -
Page 16: Overwriting The Master
Overwriting the master There are two ways to overwrite the master: • Readying the tubular drive for programming by switching on the power • Readying the tubular drive for programming with the radio switch Readying the tubular drive for programming by switching on the power To ensure that the new master transmitter is programmed in the desired tubular drive only, all other tubular drives which are connected to the same power supply must be deactivated from the programming mode. -
Page 17: Technical Data Dia. 45
Technical data dia. 45 Type R12/17C SEF T1 Rated torque [Nm] Output speed [rpm] Limit switch range 64 revolutions Supply voltage 230 V AC / 50 Hz Connected load [W] Rated current consumption [A] 0.50 Operating mode S2 4 min Degree of protection IP 44 Min. tube inside diameter [mm] Frequency 868.3 MHz... -
Page 18: Declaration Of Conformity
Declaration of conformity... - Page 20 2010 300 448 0h 07/07/2016 ...
