Osram Traxon Ecue Ribbon Go 3 Mounting Manual

Safety Information
• Wear anti-static wristbands with earthing terminal or anti-static gloves to handle the products.
• The LED module itself and all its components may not be mechanically stressed.
• Care should be taken to avoid damage to the conducting paths on the circuit board of the LED strip during assembly.
• Do not connect or disconnect the LED strip when the circuit is powered.
• Do not connect the LED strip to the power supply while it is in the packing.
• Interconnection shall be made only by the use of the supplied connectors. For flat version, any open ends must be sealed-off before use.
• Please read the installation guide carefully for detailed installation planning.
Dimensions
Open Beam
300mm [11.81"]
10mm [0.39"]
Flat
300mm [11.81"]
10mm [0.39"]
Do's and Don'ts
Minimum Bending Radius
OB ≥ 15mm
Flat ≥ 30mm
www.traxon-ecue.com
Product Specification
Ribbon Go 3
Mounting Guide
50mm [1.97"]
8.33mm [0.33"]
1.2mm [0.05"]
10mm [0.39"]
50mm [1.97"]
8.33mm [0.33"]
4.3mm [0.17"]
Do Not Twist
OB ≥ 15mm
Flat ≥ 30mm
V1.0 02/24
5000mm [196.85"]
Adhesive type on backside
5000mm [196.85"]
10mm [0.39"]
Adhesive type on backside
