Viribus AAE-L1AB-AB User Manual

Electric tricycle
Hide thumbs
Table of Contents

Advertisement

Quick Links

Contact Us
Thank you for choosing our products! If
you have any questions or comments,
contact us at support@viribusbikes.com
and we'll resolve your issue ASAP!
For a .pdf copy of the latest version of
these instructions, use the appropriate
app on your smartphone to scan the QR
code.
Electric Tricycle
User Manual
Read Carefully Before Use
Keep for Future Reference
V20240430

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AAE-L1AB-AB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Viribus AAE-L1AB-AB

Summary of Contents for Viribus AAE-L1AB-AB

  • Page 1 V20240430 Electric Tricycle Contact Us Thank you for choosing our products! If you have any questions or comments, User Manual Read Carefully Before Use contact us at support@viribusbikes.com Keep for Future Reference and we'll resolve your issue ASAP! For a .pdf copy of the latest version of these instructions, use the appropriate app on your smartphone to scan the QR code.

  • Page 2: Table Of Contents

    Contents Safety First ..................1 Specifications .................. 9 Assembly ..................9 General Notice ..................1 Traffic Rules ..................1 Installing the Rear Wheels ............10 Clothing ....................1 Installing the Handlebars ............12 Safety Checks ..................2 Installing the Saddle ..............13 Sensible Use ..................2 Connecting the Rear and Main Frames ........
  • Page 3 Adjustment ..................31 Riding with Pedal Assist Control ..........44 Adjusting the Cable Tension ............31 Riding with Push Assist Control ..........45 Adjusting the Handlebar ............32 Riding with Manual Control ............45 Adjusting the Handlebar Height and Alignment ....32 Turning ON/OFF the Front Light ..........

  • Page 4: Safety First

    Safety First General Notice Clothing • Read ALL these instructions completely before assembly • ALWAYS wear appropriate hand protection during assembly, and use. Contact customer service if any point is unclear. disassembly, adjustment, or repair of this tricycle. • DO NOT wear loose footwear or clothing that may become •...

  • Page 5: Safety Checks

    Safety Checks If you have an emergency that makes it necessary, keep your light on and limit your speed appropriately. • ALWAYS check that BOTH the front and rear brakes are • It is recommended that you NOT ride your tricycle fast UNTIL positioned properly BEFORE riding.

  • Page 6: Electronic Component Issues

    Battery Safety • DO NOT ride this tricycle near precipices or on highly uneven, sandy, or sloped surfaces. Failure to observe the following warnings could result in • DO NOT carry packages or objects on your tricycle in a way electrical fires, explosions, severe burns, or electrocution.

  • Page 7: Battery Charger Compatibility

    • ALWAYS remove the battery FULLY from this tricycle Battery Charging Environment BEFORE performing any cleaning, servicing, and storage. • It is recommended to remove the battery from the tricycle • NEVER expose the battery to radiation or excessive pressure. before charging and store both the battery and battery charger indoors, in a clean, dry area with good ventilation to •...

  • Page 8: Battery Disposal

    Battery Disposal • The battery and battery charger contain regulated materials and must be disposed of/discarded in accordance with national and/or local laws. • Do not dispose of the battery and battery charger by throwing them into fire, water or with ordinary household waste/garbage.

  • Page 9: Product Diagram

    Product Diagram Overview Display Panel Throttle Handle Stem Horn Button Steerer Tube Head Tube Locking Handle Front V-Brake Down Tube Seat Tube Battery Front Fork Motor Crank Arm Control Hardware (Inside) Spoke Reflector...

  • Page 10: Parts List

    Parts List Item Name Qty. Rear Basket Frame Rear Frame Saddle Chain Chain Guard Main Frame with Battery Pedals Handlebars with Display Panel & Keys Front Light Front Fender Front Fender Stay Rear Fenders 17 18 Rear Fender Stays Rear Wheels Note Motorized Front Wheel Upon receiving your new tricycle, carefully unpack all these parts and check that...

  • Page 11: Fasteners List

    Fasteners List Tools List Item Name Qty. Item Name Qty. Short Bolts & Nuts M4 Hex Wrench (For rear fenders & stays) Middle Bolts & Nuts M5 Hex Wrench (For stays & main frame) Rear Reflector Screw M6 Hex Wrench Rear Reflectors Dual-Purpose Screwdriver Front Wheel Cap...

  • Page 12: Specifications

    Specifications Assembly Motor Power 250 W Type Liquid Crystal Display (LCD) Display • Put on hand and eye protection during assembly Panel to prevent accidents. Work gloves and goggles (not Weatherproof Rating IPX5 included) are strongly recommended. Type 36 V Lithium •...

  • Page 13: Installing The Rear Wheels

    Installing the Rear Wheels Parts and Tools Rear Frame 14 Rear Wheels 24 Rear Wheel Caps 41 22 mm Wrench Steps Right Wheel Left Wheel O-Shaped Slot D-Shaped Slot 1. Arrange the frame and the wheels. The two rear wheels ARE different. The one 2.
  • Page 14 Spacer 3. Connect the wheel with the D-shaped 4. Replace washer nut, 5. Slide the spacer inwards and connect slot to the hub. tightening the nut with the 22 mm the wheel with the O-shaped slot to wrench. the hub. 6.

  • Page 15: Installing The Handlebars

    Installing the Handlebars Parts and Tools Main Frame 27 Rubber Plug M6 Hex Wrench 3. Retighten stem 4. Loosen the handlebar Steps binder bolt. binder bolt. 90° 1. Loosen the bolt with the 2. Slide the steerer tube 5. Arrange the handlebar 6.

  • Page 16: Installing The Saddle

    Installing the Saddle Parts and Tools Steps Saddle Arrow Screw Reflector Bracket 1. Loosen the locking bolt and 2. Retighten the locking bolt by 3. Assemble the saddle reflector then insert the saddle into the turning its handle clockwise. and reflector bracket. seat tube.

  • Page 17: Connecting The Rear And Main Frames

    Connecting the Rear and Main Frames Parts and Tools Assembled Main Frame Assembled Rear Frame 41 22 mm Wrench Steps Loosen the 4 sets of nuts and bolts on both sides of the Partially tighten these bolts and nuts on both frames. (Fully frames.

  • Page 18: Installing The Chain

    Installing the Chain Parts and Tools Steps Chain (link, plate, and clip) 22 mm Wrench Multifunctional Wrench Pliers (Not included)
  • Page 19 6. Push the main frame forward until the chain is taut. 7. Tighten the nuts and bolts completely. 8. Tighten the nuts and bolts completely. 9. Test that the chain moves freely by rotating the right crank arm.

  • Page 20: Feeding The Rear Brake Cable

    Feeding the Rear Brake Cable Parts and Tools Spring 42 Multifunctional Wrench 3. Feed the rear brake cable 4. Feed the rear brake cable through the support and through the locking bolt. Steps spring. Locking Bolt & Nut 1. Loosen the locking nut. 2.

  • Page 21: Installing The Front Fender And Light

    Installing the Front Fender and Light Parts and Tools Front Light 10 Front Fender 11 Front Fender Stay 28 Connecting Plates 38/39 Dual-Purpose Multifunctional Screwdriver Wrench Steps 1. Assemble the front fender. 2. Press the front brake and remove the 3.

  • Page 22: Installing The Front Wheel

    Installing the Front Wheel Parts and Tools Steps Motorized Front Wheel Front Wheel 1. Remove the cap and then 2. Keep the motor cable on the 3. Fit the front wheel into the loosen the nuts on both sides right. front fork dropouts.

  • Page 23: Adjusting The Front Brake

    Adjusting the Front Brake Parts and Tools Steps M5 Hex Wrench Cable Anchor Bolt Brake Noodle 1/8“ Gap(Both Pads) Brake Holder Brake Pad 38/39 Dual- Purpose Wheel Rim Screwdriver 1. Attach the brake cable to the brake holder. 2. Adjust the brake pads. a.
  • Page 24 Incorrect Alignment Wheel should be centered Correct Alignment Even clearance between wheel and fork (both sides) 3. Center the brake pads. 4. Adjust the brake pad alignment. Rotate the wheel and squint at the clearance between the Check that all brake pads are aligned correctly. rim, brake pads, and fork.
  • Page 25 5. If the clearance between the brake pad and rim is uneven, adjust the position of the brake pads. a. Using a Phillips head screwdriver, adjust the brake arm screws on either side of the brake arm. Note: Turning the screw clockwise moves the pad away from the rim, and the other pad toward the opposite rim.

  • Page 26: Installing The Rear Fender Stays

    Installing the Rear Fender Stays Parts and Tools Pliers Rear Fenders 13 Rear Fender Short Bolts 21 Rear Reflector Rear 38/39 Dual- 42 Multifunctional Purpose Stays & Nuts Screw Reflectors Wrench (Not included) Screwdriver Steps 4. Remove preinstalled bolts, 5. Replace the removed bolts, washers, 6.

  • Page 27: Installing The Rear Basket

    Installing the Rear Basket Parts and Tools Rear Basket Frame 33 Long Bolts & Nuts 32 Slats 41 22 mm Wrench 42 Multifunctional Wrench Steps 1. Unfold the rear basket frame and 2. Insert the long bolts into the slots. 3.
  • Page 28 4. Remove the 4 sets of nuts, washers, 5. Fit the rear basket onto the rear 6. Place the slats and the removed bolts. and bolts from the rear frame. frame. 7. Replace these washers. 8. Replace these nuts 9. Tighten nuts with multifunctional wrench and the 22...

  • Page 29: Install The Chain Guard

    Installing the Handlebars Parts and Tools Chain Guard 38/39 Dual-Purpose Screwdriver 2. Align the chain guard and the main frame, replace the Steps bolts and nuts, and tighten the nuts. 3. Rotate the chain to confirm it does not rub against the guard. If it does, readjust the guard so that the chain can move 1.

  • Page 30: Installing The Pedals

    Installing the Pedals Parts and Tools Pedals 41 22 mm Wrench Note: The two pedals ARE different and should NOT be mixed up. The right pedal is marked with R and the left with L. Steps After installation, test that the chain turns smoothly using the pedals, adjusting as needed.

  • Page 31: Connecting The Light/Motor Cables

    Connecting the Light/Motor Cables Make sure the color of the connector is the same. Left Right Connect the wiring from the handlebars to the light. Connect the wiring from the handlebars to the motor. Arrange the wiring neatly throughout the slots along the front fork.

  • Page 32: Inflating Tires

    Inflating Tires 1. Check the tire for low pressure. If it is underinflated, examine 2. Remove the cover. the interface between the hubs and tires to ensure that the inner tubes are not exposed. 3. Connect the pump. Innertube valve type: Schrader 4.

  • Page 33: Post-Assembly Actions

    Post-assembly Actions Remember to take the following post-assembly actions to ensure optimal functionality for a safe and enjoyable riding experience. Failure to do so may result in unpleasant riding, property damage, and personal injury. • Thoroughly check that ALL components and fasteners ARE undamaged and securely attached.

  • Page 34: Adjustment

    Adjustment Adjusting the Cable Tension 1. Check that the brake cable tension allows the brake lever about 1/3 of the travel before the front pads contact the wheel rim or the rear brake pad contact the drum. 1/3 distance 2. Loosen the cable anchor bolt for the front brake and loosen to handlebar the locking bolt for the rear brake.

  • Page 35: Adjusting The Handlebar

    Adjusting the Handlebar • Improper adjustment of the handlebar may result in damage to the stem post, and steering tube and result in loss of control, serious injury or death. Ensure the minimum insertion marks on the stem post are not visible above the top of the headset.

  • Page 36: Adjusting The Saddle Height

    Adjust the Handlebar Angle Adjusting the Saddle Height 1. Using the M6 Hex wrench to loosen the handlebar binder 1. Loosen the locking bolt. bolt. 2. Adjust the saddle to your desired height. 2. Rotate the handlebar into the desired position. 3.

  • Page 37: Operation

    Operation Failure to follow all local and state regulations and laws about tricycle use as well as the safety warnings in this manual may result in serious injury or death. Always follow all local and state regulations and laws about tricycle use, follow the safety warnings in this manual and use common sense when riding the tricycle.
  • Page 38 It is recommended to carry out the following safety checks before every ride. DO NOT ride a tricycle that is not in proper working condition. Parts Tasks  Ensure front and rear brakes work properly.  Check brake pads for wear and ensure they are not overworn. ...
  • Page 39 Parts Tasks  Ensure the battery is charged before use.  Ensure there is no damage to the battery. Battery  Lock the battery to the frame and ensure that it is secured.  Charge and store the tricycle and battery in a dry location, between 50°F−77°F (10°C−25°C). ...

  • Page 40: Familiarizing With The Handlebars

    Familiarizing with the Handlebars • If the front brake is applied too quickly or too hard, especially when riding down a slope, the front wheel will completely lose traction and the rear wheel may go off road, potentially tipping over the tricycle and causing serious injuries •...

  • Page 41: Turning On/Off The Tricycle

    Turning ON/OFF the Bike To turn on the bike: 1. Check the battery’s remaining power for each use. 6. Press and hold for a few seconds until the display is If necessary, refill the battery using the provided charger as illuminated.

  • Page 42: Display Panel

    Display Panel Overview Turns on/off the display panel when held. Toggles the variable display when pressed. Increases the pedal assist level when pressed. Control Buttons Turns on/off the front light when held. Decreases the pedal assist level when pressed. Variable Display Speed PAS Level −...

  • Page 43: Adjusting Parameters

    Adjusting Parameters When the display panel is on, you can set parameters by following the steps below. 1. Press to select a 2. Hold + and – 3. Use + or – to change the 4. Press to save your 5.

  • Page 44: Battery

    Battery Battery Capacity Levels In addition to the handlebar display, your tricycle’s current power level can be checked on the battery itself. For your safety, be sure to read Turn the key to ON and hold the power display button to see how many of the battery’s the battery safety instructions in indicator lights turn on.

  • Page 45: Charging

    Charging When you find that recharging is necessary: Charge the battery on the tricycle. Charge the battery off the tricycle. Charging Port Charger Power Cord Connect to the power supply Connect to the power supply 1. Turn the key counterclockwise to OFF. 1.

  • Page 46: Riding With Throttle Control

    Riding with Throttle Control The throttle control is available when the battery and display panel Automatically Pausing are on, enabling your tricycle to run at the 15.5 mph (25 km/h) top Throttle control automatically pauses and the motor temporarily speed using the throttle handle on the right handlebar. shifts to neutral in the following cases: •...

  • Page 47: Riding With Pedal Assist Control

    Riding with Pedal Assist Control The pedal assist system (PAS) is available when the battery and Reactivating display panel are on. The PAS reactivates in the following conditions: Using the Pedal Assist • You resume pedaling. This requires you to continue using the pedals to keep the motor •...

  • Page 48: Riding With Push Assist Control

    Riding with Push Assist Control Riding with Manual Control The push assist system provides additional strength as you push To ride your tricycle normally, you can select any of the following the tricycle for a walk or climb. methods. After the display panel is turned on, stand beside the tricycle, and •...

  • Page 49: Securing Your Tricycle

    Securing Your Tricycle Nobody wants their newly bought tricycle to be stolen. Do the following to prevent: • Register the tricycle with the local police and/or tricycle registry. • Invest in a high-quality lock that will resist hacksaws and bolt cutters.

  • Page 50: Maintenance

    Maintenance Failure to maintain this tricycle may result in malfunction of a critical part and serious injury or death. Proper maintenance is critical to the performance and safe operation of the tricycle. The exact intervals for lubrication and maintenance may vary depending on the conditions the tricycle is exposed to. Always inspect the tricycle and conduct necessary maintenance before each use of the tricycle.
  • Page 51 • Store your tricycle sheltered. Avoid leaving it in the rain or • If the tricycle is not to be used for an extended period, exposed to corrosive materials. remove the battery and store everything in a cool dry place inaccessible to children and away from direct sunlight and •...

  • Page 52: Lubrication Schedule

    Lubrication Schedule Schedule Parts Lubricant Method Chains Chain lube or light oil Brush on or squirt Brake levers Two drops from oil can Weekly Freewheels Two drops from oil can Remove cables from the casing. Grease the entire length. Wipe off Brake cables Lithium based grease excess lubrication from other surfaces.
  • Page 53 Parts Inspect Action Maintenance Use a clean rag or wash with soapy water, Rims Inspect for dirt and grease. rinse, and air dry. Wheels Check the wheels are securely fastened to the tricycle and axle Adjust if necessary and tighten axle nuts. (Frequency: Inspect nuts are tight.

  • Page 54: Hub Bearings

    Hub Bearings Servicing hub bearings requires special thin wrenches called cone wrenches. If you do not own these tools, do not attempt hub-bearing adjustments. Have a qualified tricycle mechanic perform the adjustment if you have any doubts. 1. Check to make sure neither locknut is loose. 2.

  • Page 55: Repairing A Flat Tire

    Repairing A Flat Tire An unseated tire can rupture unexpectedly and may cause serious injury or death under some circumstances. Be sure the tire is properly seated when inflating the innertube. Materials Needed Here’s a list of some things you will need to repair your tube: •...
  • Page 56 Procedure Step 2. Find the Leak Follow these 4 steps to patch your punctured innertube and tire. 1. Find the leak. Step 1. Remove Your Tire 2. If the puncture or gash in your tube is not easily apparent, fill the tube back up to locate where the air is escaping from.
  • Page 57 Step 3. Patch the Holes Step 4. Put It All Back Together When patching the hole, make sure that the area around the 1. Make sure, again, that there are no foreign objects remaining puncture is clean and has been scuffed so that the patch will stick. in the tire.

  • Page 58: Troubleshooting

    Troubleshooting Problems Causes Solutions • Excessively worn/chipped chain wheel or freewheel • Replace the chain wheel, sprockets and chain. sprocket teeth • Replace the chain. Slipping chain • Chain worn/stretched • Lubricate or replace the link. • Stiff link in the chain •...
  • Page 59 Problems Causes Solutions • Bulge in the rim or rim out of true • True wheel or take to a tricycle shop for repair. Knocking or shuddering when • Brake mounting bolts loose • Tighten the bolts. applying brakes • Brakes out of adjustment •...

  • Page 60: Disposal

    Disposal Electrical products should not be disposed of with household products. In the EU and UK, according to the European Directive 2012/19/EU for the disposal of electrical and electronic equipment and its implementation in national laws, used electrical products must be collected separately and disposed of at the collection points provided for this purpose.
