Product Manual
Wireless Sensor Module K101
FCC ID: Z4GK101
Digital Sensor Input
Battery A -ve
ve
Battery B -
Instruction for installation
Note the enclosure into which this module is installed must display a Label clearly visible to the
user without magnification stating "Contains FCC ID: Z4GK101"
This module is to be installed only in the end products of Cora Tine Teoranta t/a Kelsius
Analogue Sensors (2):
Digital Sensor:
Radio Frequency Band:
Line of sight Radio Range:
Modulation Type:
Power Output:
Reprogrammability:
Battery:
Battery Lifetime:
Antenna:
Analogue Sensor Inputs
Thermistor:
R@25 deg C = 10KOhms +/- 1%
B = 3977 +/- 1%
Normally Open contact
5VDC 25mA
902 to 928MHz
100m
FHSS
10mW
Fully Reprogrammable over RF
LithiumTiCl 3.6V 2AHr. AA Size.
5 years with a 10 minute
data transmission interval.
915MHz ¼ wave antenna 82mm long
Copper core 1.0mm
Antenna
Battery A +ve
2
PVC coated to 2.5mm OD
Battery B +ve
Advertisement
Summary of Contents for KELSIUS K101
- Page 1 Note the enclosure into which this module is installed must display a Label clearly visible to the user without magnification stating “Contains FCC ID: Z4GK101” This module is to be installed only in the end products of Cora Tine Teoranta t/a Kelsius Analogue Sensors (2):...
- Page 2 FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. WARNING! This module is to be installed only in Cora Tine Teoranta t/a Kelsius end products by Cora Tine Teoranta t/a Kelsius personnel, and shall not be offered to 3rd party OEM integrators or the general public.
