Summary of Contents for DR. Z Amplification X-RAY ZA-52
- Page 1 X-RAY Manual Model: ZA-52 www.drzamps.com...
- Page 2 This symbol warns the user of dangerous voltage levels localized within the enclosure. This symbol advises the user to read all accompanying literature for safely operating the unit Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions.
-
Page 3: General Information
General Information The X-RAY is the long-awaited response to the demand of two different Legacy amps that were discontinued many years ago. It was conceived as an amalgamation of two amps country legend Brad Paisley helped popular- ize in the 2000s and 2010s, the Stang Ray and the DB4, both of which are still featured his live backline today. Over the years, a few modifications, tweaks, and design evolutions took place in both of these amps, those of which have all been included in this latest advancement. -
Page 4: Front Panel
FRONT PANEL 1. Input: Input jack for your guitar. 2. Volume: Controls the amp input signal. As you turn the volume up natural overdrive will occur along with an increase in volume. 3. Tone: Controls overall frequency response. Clockwise increases treble content and lowers bass. Counter- clockwise increases bass and lowers treble. -
Page 5: Made In Usa
MODEL: ___________________ SERIAL NUMBER: ___________ INPUT VOLTAGE: ____________ MADE IN USA... - Page 6 EC/EU Declaration of Conformity Document: CE – ZA-52 Manufacturer: Dr. Z Ampli cation 17011 Broadway Ave. Maple Heights, OH 44137 -3407 We declare that the designated product (s) DR. Z X-RAY is/are in conformity with the European Directives: 2014/30/EU EMC Directive of 26 February 2014 20 11/65/EU RoHS Directive of 8 June 2011 2014/35/EU...
-
Page 7: Declaration Of Conformity
Dr. Z Amps 17011 Broadway Ave. Maple Heights, OH 44137 USA DECLARATION OF CONFORMITY We, Dr. Z Amps, declare, taking this declaration under our total responsibility, that guitar amplifier model X-RAY (ZA-52) is in conformity with EN 55013, EN 61000-3-2, EN 61000-3-3, and EN 55020 in accordance with the Directive 2006/95/EC of 12 December 2006, even more declaring that the CE marking was affixed in the year 2001.
