- Page 1 MS 1512 v.2.1 MS 13,8V/1A Buffer switch mode power supply module Edition: 4 from 16.09.2013 Supersedes the edition: 3 from 16.12.2011...
- Page 2 MS1512 Features: DC 13,8V/1A uninterruptible power supply LED indication high efficiency 78% protections: battery charging and maintenance control SCP short-circuit protection battery output full protection against short- OLP overload protection circuit and reverse polarity connection OHP overheat protection ...
- Page 3 MS1512 1.3. Description of components and connectors Table 1. Elements of the PSU module pcb (refer to fig. 2). Element no. Description potentiometer, voltage adjustment DC fuse in the battery circuit Connectors: +BAT- DC supply output of the battery...
- Page 4 MS1512 1.4. Specifications: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operating parameters (tab.5) Electrical parameters (tab. 3). Mains supply 18V÷22V AC 30VA min. (np. AWT150) Current up to 1,8A Power frequency 50Hz Power 21 W Efficiency Output voltage 11,0 V÷...
- Page 5 MS1512 informed about the method of unplugging (most frequently through separating and assigning an appropriate fuse in the fuse-box). The electrical system shall follow valid standards and regulations. The device should be installed in the metallic enclosure (cabinet). In order to meet the UE requirements, the rules concerning: supply, development and shielding ought to be followed- accordingly to the application.
-
Page 6: General Warranty Conditions
GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a five-years warranty for the equipment, counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects,...
