Installation & Connection Instructions
Now you know what the Vision Twins Spot is capable of and how it works, we can take a look at how it can
be safely and properly installed and connected.
Always ensure that children are unable to access the unit or any connected cables and ensure that any
children are supervised by an adult when the unit is in use. Because this unit can be set up in a standing or
suspended position, it is possible for children to pull on any connected cables. The unit must be positioned or
installed in such a way that this is prevented.
Standing Positioning
When the Vision Twins Spot is set up in a standing position, ensure that
the unit is set on a stable surface like a table, DJ booth or bar. The base
of the Vision Twin Spot is fitted with feet to improve grip and ensure
stability.
Suspended Installation (Suspension Brackets)
When the Vision Twins Spot is suspended, the suspension brackets
need to be fitted to the baseplate of the unit. These brackets are fitted
via quick-couplers, which are inserted into the mounting points and
turned by one quarter to screw them in place. A half-coupler or G-hook
can then be secured via the mounting holes of the brackets. Standard
hooks and/or brackets for 35mm or 50mm poles (truss or lighting stand)
are available via your local retailer.
The hardware required for mounting the Vision Twin Spot to a wall,
ceiling or beam does not come included. If you're not sure what
hardware you'll need to install the unit, then contact a specialist for
advice. Securing the unit to a wooden beam will require different
hardware than when securing the unit to a stone wall, for example.
When the Vision Twins Spot is suspended, a safety cable must be used
to secure the unit. A safety cable does not come included but will be
available via your local retailer.
The Vision Twins Spot comes with a safety eyelet which can be screwed
into the base of the unit to secure a safety cable. The safety cable must
then be looped over the truss or stand the unit is suspended from before
being reattached to the hook.
This way, if one or both of the brackets should fail and come loose, the
safety cable will prevent the unit from falling.
A safety cable that's able to bear at least 10x the weight of the unit must
be used. The safety cable must be installed so that the unit is unable to
fall any further than 30cm. To ensure this, the safety cable can be
wrapped around the truss or stand to shorten the length as needed. The
shorter the fall-distance allowed by the safety cable, the more the
chance of damage or injury is reduced.
Light Source
The Vision Twins Spot comes fitted with powerful LED light modules
coupled with a special lens that intensifies the effect. Never look into the
lens of the unit from a short distance as the human eye is forced to react
too quickly to the sudden intensity of light. Normally, this will not cause
permanent injury, but will cause blind spots, impairing vision for a short
period of time and causing disorientation and discomfort.
Cooling
