BlueSun BSM440PMB7-46SC Installation Manual

Solar shingled single-glasspv module

Advertisement

Quick Links

Version 202205
Installation Guide for Bluesun
Solar Shingled Single-Glass
PV Module
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BSM440PMB7-46SC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BlueSun BSM440PMB7-46SC

  • Page 1 Version 202205 Installation Guide for Bluesun Solar Shingled Single-Glass PV Module...
  • Page 2: Table Of Contents

    Contents 1 Scope ..................................2 2 The introduction of installation manual ......................... 2 2.1 Overview ................................2 2.2 Applicable products ..............................2 3 Product information ..............................3 3.1 Section structure and component description of modules ..................3 3.2 Module tag information ............................4 4 Installation ................................
  • Page 3: Scope

    This installation manual is intended for the installation and maintenance of PV modules, and helps customers to correctly install the photovoltaic power generation system, so that the design system can realize its potential. This installation manual does not apply to the installation of the Bluesun double glass modules. 2 The introduction of installation manual 2.1 Overview...
  • Page 4: Product Information

    BSMxxxCM5-72S, BSMxxxCM5-60S Monocrystalline PERC PV modules (Horizontal): BSMxxxPM5-78S, BSMxxxPM5-78SA, BSMxxxPM5-78SAF, BSMxxxPM5-78SAS, BSMxxxPMB5-78S, BSMxxxPMB5-78SA, BSMxxxPMB5-78SAF, BSMxxxPMB5-78SAS, BSMxxxPM5-72S, BSMxxxPM5-72SA, BSMxxxPM5-72SB,BSMxxxPM5-72SBF, BSMxxxPM5-72SBS, BSMxxxPMB5-72SB,BSMxxxPMB5-72SBF,BSMxxxPMB5-72SBS BSMxxxPM5-66S, BSMxxxPM5-66SA, BSMxxxPM5-66SAF, BSMxxxPM5-66SAS, BSMxxxPMB5-66S,BSMxxxPMB5-66SA, BSMxxxPMB5-66SAF, BSMxxxPMB5-66SAS, BSMxxxPM5-60S, BSMxxxPM5-60SA, BSMxxxPM5-60SB, BSMxxxPM5-60SBF, BSMxxxPM5-60SBS, BSMxxxPMB5-60SB,BSMxxxPMB5-60SBF, BSMxxxPMB5-60SBS Monocrystalline PERC PV modules (Vertical): BSMxxxPMB7-46SC , BSMxxxPMB7-46SCS , BSMxxxPMB7-46SCF BSMxxxPM6-54SC, BSMxxxPMB6-54SC, BSMxxxPM6-65SC, BSMxxxPMB6-65SC BSMxxxPM6-57SC, BSMxxxPMB6-57SC, BSMxxxPM6-68SC, BSMxxxPMB6-68SC BSMxxxPM6-58SC,BSMxxxPMB6-58SC, BSMxxxPM6-69SC, BSMxxxPMB6-69SC...
  • Page 5: Module Tag Information

    4 Installation 4.1 General safety 4.1.1 Bluesun solar’s modules have been evaluated by according to IEC61215 and IEC61730, Protection Class Ⅱ, modules rated for use in this protection class may be used in system operating at greater than 50V DC or...
  • Page 6: Electrical Properties Safety

    240W. The class of fire rating is Class C(According to the standard is UL790). 4.1.2 The maximum rating of a fuse connected in series with an array string is typically 20A, but the actual module specific rating can be found on the product label and in the product datasheet. 4.1.3 The installer should abide by the relevant local laws and regulations when installing module.
  • Page 7: Handling Safety

    4.3.1 Do not open the box until it reaches the installation location. Keep the package in a dry and dry place. 4.3.2 PV modules Unpacking Please refer to Unpacking manual of standard package of Bluesun solar photovoltaic modules. During all handling procedures, make sure that the modules are not subject to large vibrations, that the modules fall to the floor or that objects fall on the module, as this will Damage to the modules or solar cell.
  • Page 8: Installation Condition

    4.4.15 Modules can't be used to replace the roof and wall materials, partial replacement is not allowed. 4.4.16 Any part (including nameplate) of modules supplied by Bluesun Solar Co., Ltd can't be dismantled without permission.
  • Page 9: Installation Position

    Bluesun modules can be installed at seaside locations 50m to 500m from the sea, but the components should be protected against corrosion. For locations ≥ 500m from the sea, it is low risk with salt-mist corrosion, only annual preventive maintenance is required.
  • Page 10: Mechanical Installation

    For detailed installation angles, follow the advice given by the experienced PV module installer. Figure 2 Module tilt angle 6 Mechanical installation All of the installation methods described here are for reference only. Bluesun Solar Co., Ltd is not responsible for providing the relevant installation parts and module installation services. 6.1 Conventional requirement 6.1.1 Ensure that the installed modules and supporting rail of modules are strong enough, the entire PV system...
  • Page 11: Three Kinds Of Mounting

    Bluesun solar suggests selecting the support reinforcing mechanism shown in figure 3. T h e u p p e r m o d u le...
  • Page 12: Installation Methods

    6.3.2 Fixture installation 6.3.2.1 Use a certain number of clamps to fix the modules on the mounting bracket. Bluesun recommends that the clamps be clamped on the long frame of the module. The area of the A side of the module frame held by each fixed clamp is not less than 400mm2 (clamp length: ≥...
  • Page 13 Fixture A: Fixture for edge module Fixture B: Fixture for intermediate modules For the 30 frame, the recommended value of X is 29mm For the 30 frame, the recommended value of Y is 20mm For the 35 frame, the recommended value of X is 34mm For the 35 frame, the recommended value of Y is 25mm For the 40 frame, the recommended value of X is 39mm For the 40 frame, the recommended value of Y is 30mm...
  • Page 14 * Note: Bluesun limited warranty will be void in cases where improper clamps or installation methods deviating from this manual are used. When using clamps to fasten the modules, pay attention to the following requirements: (a) Take care of the module frames, not to twist or deform them.
  • Page 15 BSMxxxPM5-60SBS BSMxxxPMB5-60SB positive5400 1719 1140 345±50 9~11 ≥50 BSMxxxPMB5-60SBF negtive2400 BSMxxxPMB5-60SBS BSMxxxPMB7-46SC Long side positive5400 BSMxxxPMB7-46SCS 1812 380±50 ≥50 9~11 Installation negtive2400 BSMxxxPMB7-46SCF BSMxxxPM6-54SC Long side Positive5400 405±5 2253 1096 545±50 ≥50 9~11 BSMxxxPMB6-54SC Installation negtive2400 BSMxxxPM6-57SC Long side Positive5400 425±5 2355 1096...
  • Page 16: Wiring Method

    16mm Spring Stainless steel washer Flat washer Stainless steel Stainless steel Bolt beam: width * height * length 40mm*40mm* > 2000mm Module Type Installation method Design load*safety factor(1.5)/Pa BSMxxxPM5-78S BSMxxxPM5-78SA BSMxxxPM5-78SAF BSMxxxPM5-78SAS Long side Installation positive5400/negtive2400 BSMxxxPMB5-78S BSMxxxPMB5-78SA BSMxxxPMB5-78SAF BSMxxxPMB5-78SAS BSMxxxPM5-72SB BSMxxxPM5-72SBF BSMxxxPM5-72SBS...
  • Page 17 Horizontal Installation (Double row ,The junction box is on the outside) The wire length of 72 / 78 is not less than 1200mm, and that of 60 / 66 is not less than 1000mm. Horizontal Installation (Single row) The wire length of 72 / 78 is not less than 1200mm, and that of 60 / 66 is not less than 1000mm.
  • Page 18 Vertical Installation (Single row) The wire length of 72 / 78 is not less than 700mm, and that of 60 / 66 is not less than 700mm. 6.4.2 Wiring method of vertical modules Head to tail connection The wire length of this connection mode is not less than 800mm. During installation, attention should be paid to the positive and negative pole positions of the modules, and the next module need to be turned around .
  • Page 19: Electrical Installation

    The maximum voltage of string does not exceed the maximum system voltage of the modules (the maximum system voltage of Bluesun solar modules is 1500V), the maximum number of modules that can be connected in a series string must be calculated in...
  • Page 20: Cables And Wiring

    modules N= Imax (fuse rating) /Isc. 7.1.4 An over-current protection device with appropriately rated must be used when reverse current could exceed the value of the maximum fuse rating of the module, an over-current protection devices is required for each series string if more than two series strings are connected in parallel. 7.1.5 When installing the module, place the end with the junction box up and try to avoid the rain.
  • Page 21: Grounding

    The junction box of the Bluesun module contains bypass diode and forms a parallel structure with the solar cell circuit. When the solar cell sheet is blocked or damaged, a hot spot phenomenon occurs locally in the module, and the diode will operate so that the current is no longer discharged from the hot spot solar cell flow, thereby limiting module heat and performance loss.
  • Page 22: Maintenance And Care

    With negative Grounding Figure 7 Schematic diagram for grounding potential of the inverter 7.5.7 Bluesun modules may be grounded using a third-party earthing device, provided that the earthing must be reliable. The earthing device is operated in accordance with the manufacturer's requirements.
  • Page 23: Visual Inspection

    9.2 Bluesun shall not be liable for damage to the product resulting from the installation or the design of the power generation system.
  • Page 24 9.3 No responsibility is assumed by Bluesun for any infringement of patents or other rights of third parties, which may result from ues of the PV product, No license is granted by implication or otherwise under any patent or patent rights.
  • Page 25 Bluesun Solar Co., Ltd Add:1499 Zhenxing Road, Shushan District,230031 Hefei,China Tel: +86 (158) 5821 3997 Fax: +86 (551) 6565 2651 Email: info@bluesunpv.com Service: Service@bluesunpv.com...
