OWNER'S MANUAL
JACK STANDS
Item: T42002,T42002-1 T42002X, T43002, T43002-1,T43002X,T43006, T43006-1
T46002, T46002-1,T412002,T412002-1
Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating.
Failure to follow the safety rules and other basic safety precautions may result in serious personal injury.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Torin BIG RED T42002
Summary of Contents for Torin BIG RED T42002
- Page 1 OWNER’S MANUAL JACK STANDS Item: T42002,T42002-1 T42002X, T43002, T43002-1,T43002X,T43006, T43006-1 T46002, T46002-1,T412002,T412002-1 Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury.
-
Page 2: Owner / User Responsibility
Use both stands for each operation. TECHNICAL SPECIFICATIONS Lifting Range Lifting Range Lifting Range Lifting Range Item Capacity Min. (inch) Max. (inch) Min. (cm) Max. (cm) T42002 2 TON 10-13/16 16-9/16 27.5 T42002-1 T42002X 2 TON 9-13/16 14-15/16 T43002 3 TON... -
Page 3: General Safety Rules
GENERAL SAFETY RULES WARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in serious injury. CAUTION: Do not allow persons to operate or assemble this jack until they have read this manual and have developed a thorough understanding of how the jack works. WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur. -
Page 4: Safety Markings
SAFETY MARKINGS WARNING! 1. Study, understand, and follow all instructions before operating this device. 2. Do not exceed rated capacity. 3. Use only on hard, level surfaces, with less than 3 degrees of slope. 4. Center load on saddle. 5. Use as a matched pair only. 6. - Page 5 In this case the bolt can be threaded in toward the post until the bolt bottoms out. Item: T42002,T42002-1 T42002X, T43002, T43002-1,T43002X,T43006, T46002, T46002-1 1. Install ratchet bar into frame (fig.1) with ratchet portion of bar aligned with locking pawl (stopper).
- Page 6 OPERATION INSTRUCTIONS • If the operator is not fluent in English, the product and safety instructions shall be read to and discussed with the operator in the operator's native language by the purchaser/owner or his designee, making sure that the operator comprehends their contents. •...
-
Page 7: Maintenance Instructions
MAINTENANCE INSTRUCTIONS Maintain your equipment. It is recommended that the general condition of any equipment be examined • before it is used. Keep your equipment in good repair by adopting a program of conscientious repair and maintenance. Have necessary repairs made by qualified service personnel. •... -
Page 8: Assembly Diagram
ASSEMBLY DIAGRAM Part# Description Ref. T42002 T43002 T43006 T46002 T42002 T43002 T43006 T46002 T42002-1 T43002-1 T43006-1 T46002-1 T42002-1 T43002-1 T43006-1 T46002-1 T42002C-1 T43002C-1 T43006-1 T46002C-1 Ratchet bar T42002-4 T43002-4 T43006-4 T46002-4 Locking pawl Spring pin Spring pin Spring pin Spring pin...
