BEA PBS Instruction Manual

BEA introduces its new stainless steel push plates. The push plate fits into a single/double electrical gang
DESCRIPTION
box or guardrail for easy replacement of outdated or defective switches. The stainless steel push plate is not
OF
waterproof. The stainless steel push plates are available in the versions listed below:
THE PRODUCT
PBS
PBS-H
PBS-P
PBR
PBR-H
PBR-P
PBJ
PBJ-H
PBJ-P
Supply voltage
TECHNICAL
SPECIFICATIONS
Current rating
Output contacts
Housing
Temperature range
Typical operating force :
OPERATION
• Press to activate the door ;
INSTRUCTIONS
• Connect desired contact (NO or NC) to door control.
SWITCH
CONTACTS
PARTS
INCLUDED WITH
Mounting box (surface mount or flush mount, 152 mm round, 114 mm round, square or jamb)
MOUNTING BOX
Weather ring (standard)
MOUNTING Surface mounting
INSTRUCTIONS Hollow Wall or Solid Wall (illustration # 1)
STAINLESS STEEL PUSH PLATES
Name Dimensions (W x H x D)
120 mm x 120 mm x 16 mm square
120 mm x 120 mm x 16 mm square
120 mm x 120 mm x 16 mm square
152 mm diameter x 16 mm round
152 mm diameter x 16 mm round
152 mm diameter x 16 mm round
38 mm x 120 mm x 16 mm jamb
38 mm x 120 mm x 16 mm jamb
38 mm x 120 mm x 16 mm jamb
:
:
:
:
:
WARNING! :
This equipment may only be used to switch voltages lower than 40 V AC / 60 V DC
and to switch currents lower than the specified maximum ratings.
1. Drill pilot holes in plate box as shown in Top
View drawing (illustration # 3)
• 4 holes for square and round box
• 2 holes for jamb box
2. Drill pilot holes in mounting surface
3. Insert appropriate fastener (screw, toggle bolt,
etc.) through box and into mounting surface,
then tighten box to surface
4. Complete assembly of push-plate (see push-
plate assembly instructions)
INSTRUCTION MANUAL
12 to 24 V DC
12 to 24 VAC
6A max. (V DC)
15A max. (V AC)
Dry output contacts (NO, NC, COM)
Stainless Steel
from –30°C to +55°C
0.45 Kg
N.C.
COM
N.O.
Flush mounting
Hollow Wall only (illustration # 2)
1. Cut access hole into mounting surface
2. Insert plate box into hole
3. Tighten two Phillips head screws to tighten
4. Complete assembly of push-plate (see push-
Description
PUSH TO OPEN
Handicapped with logo PUSH TO OPEN
No logo
PUSH TO OPEN
Handicapped with logo PUSH TO OPEN
No logo
PUSH TO OPEN
Handicapped with logo PUSH TO OPEN
No logo
• square box : 159 mm W x 140 mm H
• 152 mm round box : 165 mm diameter
• 114 mm round box : 140 mm diameter
silver hanger to inside of the mounting surface
plate assembly instructions)
