Paradyne 9109 Release Note

9109 E&M Analog Voice Application Module (APM)
Extended Range Enhancements
Document Number 9109-A2-GK42-00
September 1997

Extended Ranges Offered

How to Identify Extended Range E&M APMs
9109-A2-GK42-00
TM
The version of the 9109 E&M APM that you have includes extended ranges for
the Rx Gain and Tx Attenuation configuration option settings:
Configuration Option
Rx Gain (dB)
Tx Attenuation (dB)
E&M APMs that offer the extended ranges are identified by a sticker on the card
printed with the number 870-2540-xxxx.
September 1997
Available Range
–17.0, –16.5, –16.0, –15.5, –15.0, ..., [0.0], ..., +15.0, +15.5,
+16.0
–17.0, –16.5, –16.0, –15.5, –15.0, ..., [0.0], ..., +15.0, +15.5,
+16.0
1
