Q-COP-C05
Flip the module upside down.
Retournez le module à l'envers.
Hand screw the metal plate to the base.
Vissez à la main la plaque de métal sur la base.
Fully screw the metal plate to the base.
Visser complètement la plaque de métal sur la structure.
PM LE CORBIN 11-24-2023
LE CORBIN
3x 140-1410
Repeat for each corner.
Répetez pour chaque coin.
1x
www.tricafurniture.com
8x 140-1411
Place the base on the frame.
Déposez la base sur la structure.
Align and center the base before fully screwing the
metal plate to the base.
Alignez et centrez la base avant de visser complètement la plaque
de métal sur la structure.
Put the module down and place the back cushion on it.
Retournez le module sur ses pattes et y placer les coussins.
8 x 400-1195
1/4"- 20 x 1"
U.S. Patent No. 11,612,253 and other patents pending.
2x
1x 400-1106
Allen key 4mm
