DXV Equility D35109100 Installation Instructions

INSTALLATION INSTRUCTIONS
Equility
™
(Formerly LYNDON
Single Control
Monoblock and Vessel
Lavatory Faucets
Models D35109100, D35109150
D35109100RB, D35109150RB
Thank you for selecting DXV. To ensure that your
installation proceeds smoothly, please read these
instructions carefully before you begin.

RECOMMENDED TOOLS AND MATERIALS

Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work is begun.
ROUGHING-IN DIMENSIONS:
• For reference
D35109100
1-5/8"
(42 mm)
5-3/4"
(146 mm)
2-3/8"
(60 mm)
NOTE:
MOUNTING
HOLES ARE
1-3/8" D. (35 mm)
