2. SPECIFICATIONS

2.1 SC-95 SPECIFICATIONS
Amplifier section
A
Continuous average power output*
8 Ω ............................................................................................................................... 135 W** per channel
6 Ω ............................................................................................................................... 175 W*** per channel
* Measured pursuant to the Federal Trade Commission's Trade Regulation rule on Power Output Claims for
Amplifiers
** 1 kHz with no more than 0.08 %**** total harmonic distortion
*** 1 kHz with no more than 1 %**** total harmonic distortion
**** Measured by Audio Spectrum Analyzer
Multi channel simultaneous power output (1 kHz, 1 %, 8 Ω )
9 ch total ............................................................................................................................................... 760 W
Continuous Power Output (1 kHz, 8 Ω, 0.08 %)
Front ....................................................................................................................................... 135 W + 135 W
Center ................................................................................................................................................... 135 W
B
Surround ................................................................................................................................ 135 W + 135 W
Surround back ........................................................................................................................ 135 W + 135 W
Top middle/Extra 1 ................................................................................................................... 135 W + 135 W
Continuous Power Output (1 kHz, 6 Ω, 1.0 %)
Front ...................................................................................................................................... 175 W + 175 W
Center .................................................................................................................................................. 175 W
Surround ............................................................................................................................... 175 W + 175 W
Surround back ....................................................................................................................... 175 W + 175 W
Top middle/Extra 1 .................................................................................................................. 175 W + 175 W
Continuous Power Output (1 kHz, 4 Ω , 1.0 %)
Front ...................................................................................................................................... 220 W + 220 W
Center .................................................................................................................................................. 220 W
Surround ............................................................................................................................... 220 W + 220 W
C
Surround back ....................................................................................................................... 220 W + 220 W
Top middle/Extra 1 .................................................................................................................. 220 W + 220 W
Total harmonic distortion .............................................................................. 0.04 % (1 kHz, 110 W + 110 W, 8 Ω)
Guaranteed speaker impedance ........................................................................................................ 4 Ω to 16 Ω
Audio Section
Input (Sensitivity/Impedance)
LINE ......................................................................................................................................... 390 mV/47 kΩ
Output (Level/Impedance)
REC ......................................................................................................................................... 390 mV/2.2 kΩ
Signal-to-Noise Ratio (IHF, short circuited, A network)
LINE .................................................................................................................................................... 101 dB
Tuner Section
Frequency Range (FM) ........................................................................................................ 87.5 MHz to 108 MHz
D
Antenna Input (FM) ..................................................................................................................... 75 Ω unbalanced
Frequency Range (AM) ......................................................................................................... 530 kHz to 1 700 kHz
Antenna (AM) ................................................................................................................. Loop antenna (balanced)
Video Section
Signal level
Composite Video ........................................................................................................................ 1 Vp-p (75 Ω)
Component Video ......................................................................... Y: 1.0 Vp-p (75 Ω), PB/PR: 0.7 Vp-p (75 Ω)
Corresponding maximum resolution
Component Video ....................................................................................................................... ....1080i (1125i)
Bluetooth Section
Version ..................................................................................................... Bluetooth Specification Ver. 2.1 + EDR
Output ................................................................................................................... Bluetooth Specification Class 2
Estimated line-of-sight transmission distance* ................................................................................... About 10 m
E
*The line-of-sight transmission distance is an estimate. Actual transmission distances supported may differ
depending on surrounding conditions.
Frequency range ...................................................................................................................................... 2.4 GHz
Supported Bluetooth profiles .......................................................................................................... A2DP, AVRCP
Supported Codec ...................................................................................................... SBC (Subband Codec), AAC
Digital In/Out Section
HDMI terminal .............................................................................................................................. 19-pin (Not DVI)
HDMI output type ................................................................................................................................. 5 V, 55 mA
HDMI input/MHL terminal .................................................................................................................. 5 V, 900 mA
USB terminal .............................................................................................. USB2.0 High Speed (Type A) 5 V, 1 A
iPod terminal ................................................................................................................................................... USB
