469146 Rev02
Please read these instructions thoroughly before installation.
60kg
132lb
If you have any questions or need
spare parts don't worry, we're happy to help.
Customer Helpline
Online Support
www.avfgroup.com/support
0333 320 0463
Helpine Open Mon to Thurs 9am - 5pm, Fri 9am - 4pm
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
Advertisement
Related Manuals for AVF Group 469146
Summary of Contents for AVF Group 469146
- Page 1 If you have any questions or need spare parts don’t worry, we’re happy to help. Customer Helpline Online Support www.avfgroup.com/support 0333 320 0463 Helpine Open Mon to Thurs 9am - 5pm, Fri 9am - 4pm AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England...
-
Page 2: Assembly Overview
Assembly Overview Tools Recommended Fit the TV Mounting Plate Stud Finder Fit the Wall Bracket Ø10mm (25/64”) Ø3mm (1/8”) Masonry Wood Hang the TV Suitable Wall Types Solid Wall Wood Stud... - Page 3 Index Measure the TV fixing holes Width and Height Preparing the TV Mounting Plate Fitting the TV Mounting Plate Fitting the Wall Bracket Hanging the TV Retain all packaging in case the product needs to be returned. Contents may vary from photography / illustrations. You will not need all these parts, so expect there to be some left over depending upon the specification of your TV.
- Page 4 Boxed Parts TV Screws, Reducers and Spacers...
- Page 5 Measure the TV fixing holes Width and Height 75 - 400mm M4 = M6 = M8 = TV Fixing Holes 75 - 400mm If width X is greater than You are provided with diameters of TV fixing screws M4, M6 and M8. mm or height Y greater Determine the screw diameter that fits than...
- Page 6 OPTION 1 75mm 100mm 200mm Attach Standoffs P in the holes shown. If using those holes to attach the plate to your TV, then fix Standoffs in holes a.
- Page 7 OPTION 2 Adaptors C can be fixed in different positions in the slots on Plate B to match your TV fixing holes. 400mm 300mm 400mm 300mm 200mm 400mm 400mm 200mm Example shown is 400 x 400 fixings...
- Page 8 Example shown is 400 x 400 fixings Attach Standoffs P in an adjacent hole to the TV fixing hole to be used on Arms C. Fitting the TV Mounting Plate No Spacers Spacers For TVs with flat / unobstructed back. For TVs with irregular / obstructed back.
- Page 9 WARNING After completing step you will have fittings left over, please keep for future reference. If required Attach the TV Mounting Plate to the back of your TV using suitable screw, reducer and spacer combinations.
- Page 12 Hanging the TV Hold the TV parallel to the wall. Offer the white bush towards the centre of the wall bracket and lower into position. Ensure both the white bush and locating plate securely engage with the wall bracket. When the white bush is in the horizontal slot your TV is secured.
- Page 13 Standoff Adjustment (optional) When you have hung your TV, the standoffs should touch the wall. You can adjust the standoffs simply by unscrewing or tightening as required. TV Levelling (optional) Adjust the levelling resistance, if necessary, by tightening or loosening the screw in the white bush.
- Page 14 LIFETIME WARRANTY AVF warrants that the product is free from defects in material and workmanship, as long as the product is owned by the original consumer purchaser. If, during the stated warranty of this product, it proves to be defective, AVF will remedy the defect by either repairing or replacing the defective part or, replacing the entire product.
