Edit Recall

This Edit Panel window function is used to recall the edited settings of a pattern, in the
event you have inadvertently left the editing mode and selected another pattern.
1) Click [FUNCTION] to enter the Function mode.
2) Click [EDIT RECALL].
3) Answer the display prompts "EDIT RECALL ?" and "ARE YOU SURE
?" by clicking [YES] twice.
• Edit Recall is available only in the Edit Panel window.
Pattern Init (Initialize)
The Pattern Initialize function lets you create a "blank slate" starting point for program-
ming a new pattern.
1) Click [FUNCTION] to enter the Function mode.
2) Click [VOICE INIT].
3) Answer the display prompts "VOICE INIT ?" and "ARE YOU SURE ?"
by clicking [YES] twice.
The resulting initialized pattern has the following settings:
* Algorithm 1
* No modulation
* Operator 1 Output Level set to 99; all other operators off
* "Square" envelopes (EGs)
* All frequency ratios set to 1.00
• Although this operation pertains to the Edit Panel window, a similar Pattern Initialize function
is also available in the DX200 Editor window from the

Version Check

This Edit Panel window function is used to check the current version of the DX200 Editor
software.
1) Click [FUNCTION] to enter the Function mode.
2) Click [VERSION CHECK].
The current software version is shown in the LCD.
Parameters /
DX Pattern List
63
DX7 Edit Panel Window
dialog box.
