GBK/GNK/HR-B-GB 01.2006
OPERATING MANUAL
Equipment for the Creation and Maintenance
for Greens and Sports Fields
GBK / GNK / HR 11 - 13 - 15 - 20 -25
Postfach 51
D-49202 Hasbergen-
Gaste
Tel.: (05405) 501-0
Fax: (05405) 501 147
17, rue de la Verrerie - BP 90106
F-57602 Forbach/France
Tel: 03 87 84 65 70
Internet : www.amazone.fr
991831
H. Dreyer Str.
D-27798 Hude/Oldenburg
Tel.: (04408) 927-0
Fax: (04408) 927 399
Machines Agricoles S.A.
Fax: 03 87 84 65 71
E-mail : Forbach@amazone.fr
GB
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amazone GBK 11
Summary of Contents for Amazone GBK 11
- Page 1 Tel.: (05405) 501-0 Fax: (04408) 927 399 Fax: (05405) 501 147 Machines Agricoles S.A. 17, rue de la Verrerie - BP 90106 F-57602 Forbach/France Tel: 03 87 84 65 70 Fax: 03 87 84 65 71 Internet : www.amazone.fr E-mail : Forbach@amazone.fr...
-
Page 2: Table Of Contents
Technical data of screen roller ..........26 Technical data of flat roller............26 Scraper bar ................ 26-27 Screen roller dismounting ..........27-28 Flat roller weighting..............29 Maintenance ................29 © GBK/GNK/HR-B-GB 01.2006 - 991831 - Copyright 2006 AMAZONE Machines Agricoles S.A. F-57602 Forbach All rights reserved... - Page 3 Adjustment of the range selector box to high speed ..... 37 Flow rate table ................ 38 Flow rate adjustment ............38-40 Maintenance ................41 AMAZONE GBK Combination Seeding System ..42-51 Fields of application ............... 42 Working with the combination seeding system ...... 42 7.2.1 Harrow working depth adjustment ........
- Page 4 10.0 Further Soil Cultivation Equipment ........60-70 10.1 Seeding system with rotary harrow......... 60 10.1.1 Mounting and adjustment of the rotary harrow....60-61 10.1.2 Cardan shaft ................61 10.1.3 Cardan shaft mounting ............61 10.1.4 Cardan shaft adjustment by coupling the machine for the first time...............
-
Page 5: Machine Data
Machine data Manufacturer AMAZONE Machines Agricoles S.A., F-57602 Forbach (Agricultural Machine Factory) Phone. : 03 87 84 65 70 Internet: www.amazone.fr Fax : 03 87 84 65 71 E-mail : forbach@amazone.fr Technical data 1.2.1 Combination seeding system Name GBK 11... -
Page 6: Conditionmaster
1.2.2 Condition master reciprocating power harrow equipped with: rigid tine bars + flat roller + side brush + rear brush HR 15 HR 20 HR 25 Total weight (kg) Working width 1,50 2,00 2,50 „ (in) Required tractor (HP) from 15 from 24 from 35 „... -
Page 7: Important Recommendations
Important recommendations ”DANGER” symbol All text included in this manual which concerns your personal safety or the safety of third parties are marked with the opposite triangle symbol. Observe all these rules carefully and always proceed with special care. It is up to you to ensure that all persons using the machine have full access to these rules. - Page 8 Strictly observe the instructions on the recommendation and note labels. You have to pass on all safety recommendations to all other operators of the machine. Keep the recommendation and note labels on the machine in good order. Replace those recommendation and note labels which are missing or which have been damaged(figure No.
-
Page 9: Arrival Of The Machine
A proper and appropriate application also means that all the manufacturer’s rules and recommendations with regard to the conditions of use, maintenance and repair are complied with and that original AMAZONE spare parts are used exclusively. - Page 10 AMAZONE HR Conditionmasters, GBK Combination Seeding Systems and GNK Overseeders may only be operated, maintained and repaired by trained personnel who have also been informed about the risks involved. Observe all rules for prevention of accidents as well as all other general...
-
Page 11: General Safety Regulations And Rules For Prevention Of Accidents
General safety regulations and rules for prevention of accidents Basic Rule! Before every application, check the machine and the tractor for compliance with the road and occupational safety regulations! In addition to the regulations stated in this manual you also have to observe the general safety regulations and rules for prevention of accidents! The note and recommendation labels attached on the machine will give... - Page 12 Take the necessary precautions for coupling and uncoupling the machines to and from the tractor! 10. Suitably position the supports for coupling/uncoupling purposes in order to ensure the stability of the machine during operation! 11. Always duly fix the weights at the prescribed fixing points! 12.
- Page 13 19. In curves, protruding objects and the mass of inertia have to be taken into account! To avoid oscillations of the spreader during operation, the lower tractor coupling bars have to be reinforced! 20. Before you start, the protection devices have to be mounted and checked for correct operation! 21.
-
Page 14: Machines Coupled To A Tractor
It is stricktly forbidden to trail any, so called, vehicle behind a machine already hooked on a tractor. Machines coupled to a tractor Before coupling/uncoupling the machine at the 3 lifting points, position the controls in such a way that any unintentional lifting/lowering of the machine is prevented! For 3-point couplings, it has to be ensured that the coupling parts of the tractor are in accordance with those of the machine! -
Page 15: Power Take-Off
Power take-off Exclusively use the cardan drives prescribed by the manufacturer and equipped with the required protection devices! The protecting tube and protective covering of the cardan drive as well as the protection device of the power take-off - also on the machine - must be available and fully protective! Take care to observe the correct overlapping length of both halves of the cardan drive, both, during transport and during operation (refer to... - Page 16 10. Before switching on the power take-off, make sure that there is nobody in the working range of the machine! 11. Never switch on the power take-off when the engine is switched off! 12. Make sure that there is nobody in the areas of rotation of the power take-off or of the cardan drive when work is in progress! 13.
-
Page 17: Maintenance Instructions
Maintenance instructions Before any repair, maintenance or cleaning works are carried out and before any troubles are eliminated, switch off the drive and the engine! Take out the ignition key! Regularly check the bolts and nuts for a tight fit and tighten them, if necessary! Fasten the machine by appropriate means for any intervention requiring that the machine remains in its position! -
Page 18: Modular System Components
Modular system components AMAZONE equipment for creating and maintaining greens and sports fields is composed of several components forming a modular system. These components are as follows: • a reciprocating harrow onto which the different machine bars can be mounted, •... -
Page 19: Reciprocating Harrow
• as a combination seeding system for newly created greens, • as an overseeder for already existing greens, • for regenerating surfaced grounds and consolidated surfaces, • for weekly maintaining consolidated surfaces, • for maintaining sandy artificial lawn. Reciprocating harrow 4.1.1 Technical data REG15... - Page 20 The upper tie rod of the coupling has to be adjusted in such a way that the reciprocating harrow is horizontal or slightly inclined towards the back when in operating position. Caution: The machine must never be inclined towards the front (Fig. 2 + 3). Fig 2 Fig 3 Take care that there is nobody behind or beneath the...
-
Page 21: Cardan Shaft
4.1.3 Cardan shaft Only use the cardan drive prescribed by the manufacturer! Walterscheid W 2300 SD 15 560 K65/2 4.1.4 Cardan shaft mounting Preliminarily clean the shaft entering the casing and always put a greased cardan shaft on the entry shaft. 4.1.5 Cardan shaft adjustment by coupling the machine for the first time... - Page 22 Fig 4...
- Page 23 When mounting the machine for the first time, fix the transmission half in front onto the power take-off shaft of the tractor. Do not insert the special section tubes into each other. Check whether the special section tubes can be inserted into each other in any position by holding them side by side.
-
Page 24: Speed At The Entry Of The Angular Gear Casing
The angle of a cardan crosspiece must not exceed 25°. Please also follow the mounting and maintenance instructions attached on the cardan drive. To ensure that the cardan drive is not damaged, only start it slowly at a low engine speed! 4.1.6 Speed at the entry of the angular gear casing The maximum speed at the input shaft is 540 rpm. -
Page 25: Maintenance
Overseeding tine bars The overseeding tine bars combined with the seeder ensure regular and even broadcast overseeding over the whole working surface. This combination can also be used as a combination seeding system on a surface where the soil has already been prepared. Actually, the position of the overseeding tine bars avoid buried stones are retransported to the surface. -
Page 26: Screen Roller And Flat Roller
Screen roller and flat roller Technical data of screen roller GIW 11 GIW 13 GIW 15 GIW 20 GIW 25 Diameter (mm) Working width (m) 1.20 1.40 1.60 2.10 2.60 Weight (kg) Technical data of flat roller GLW 11 GLW 13 GLW 15 GLW 20 GLW 25 Diameter (mm) Working width (m) 1.20... -
Page 27: Screen Roller Dismounting
fig. 5 Screen roller dismounting The screen roller is combined with the reciprocating harrow by two support bars (Fig. 6/1). To dismount the screen roller from the reciprocating harrow proceed as follows: • Lower the lift of the tractor until the support bars are free, i. e. until they are neither supported by the upper eccentric (Fig. - Page 28 C A U T I O N ! ! Before uncoupling the harrow, the screen roller must be blocked to ensure its balance and security. For coupling another machine (rotary harrow or stone burier) proceed as follows when uncoupling the harrow from the roller: •...
-
Page 29: Flat Roller Weighting
Flat roller weighting To obtain a stronger consolidation and compactness, the flat roller can be weighted by means of water. The flasks laterally attached to the roller are equipped with fasteners for connecting an irrigation tube on the one side and for allowing the air to escape on the other side during the filling process. -
Page 30: Seeder
Seeder Technical data Seeders 1.10 m 1.30 m 1.50 m 2.00 m 2.50 m Working Width (m) 1.10 1.30 1.50 2.00 2.50 Overall Width (m) 1.44 1.64 1.84 2.34 2.84 Height (m) 0.51 0.51 0.51 0.51 0.51 Length (m) 0.43 0.43 0.43 0.43... - Page 31 The tension of the chain drive is ensured by a tensioning roller fixed at the roller chassis (Fig. 10/1) 10.1 fig. 10 The chain drive is housed in a protective casing. For dismounting the seeder proceed as follows: • Remove the upper and the lower protective casing of the chain drive (Fig.
-
Page 32: Seeder Filling
• Detach the spring of the tensioning roller by means of pliers. • Remove the chain by preliminarily dismounting the chain link for a rapid disassembly. • Remove the three fastening screws M12 by means of which the seeder is held on the chassis. •... -
Page 33: Seeder Emptying
Seeder emptying After the works have been carried out, the seeder is emptied as follows: • Open the wing screw holding the emptying slide rail. • Detach the slide rail from the rear part of the seeder (Fig. 12). fig. 12 •... - Page 34 • Open the bolts of the bottom plate (Fig. 13) and let it fold down. The seeds flow into the chute and from there into the sack until the slide rail is removed from the chute (Fig. 14). • After the seeder has been emptied, restore the slide rail on the rear part of the seeder.
-
Page 35: Adjustment Of Flow Rate
Adjustment of flow rate To adjust the flow rate, refer to the flow rate table in chapter 6.7. • Unscrew the handle of the selector lever (Fig. 15/1) for adjusting the flow rate of seeds, • place the index on the selected value in the flow rate table, •... -
Page 36: Recommendations For Slow- And High-Speed Seeding
Recommendations for slow- and high-speed seeding The speed of the camshaft - and thus the flow rate of grains - is infinitely adjustable by means of the range selector box (Fig. 15/2). The box includes an additional reduction by means of gearwheels. By exchanging one of these gearwheels, two distributing speeds can be obtained: Low speed High speed... -
Page 37: Adjustment Of The Range Selector Box To High Speed
6.6.1 How can the range selector box be adjusted to high speed? If necessary, proceed as follows for switching from low speed to high speed: Open the cover (Fig. 17/1) on the side of the selector box by unscrewing the wing screw and the two wing nuts (Fig. 17/2). fig. -
Page 38: Flow Rate Table
Flow rate table Seeds: Resistant Lawn Specific Gravity : 0.37 kg / P Weight at Flow Rate Seeded Quantity kg/ha Selector Switch Low Speed High Speed 25 kg/ha 38 kg/ha 56 kg/ha 137 kg/ha 82 kg/ha 212 kg/ha 109 kg/ha 304 kg/ha 137 kg/ha 387 kg/ha... - Page 39 • Slide the crank handle onto the roller axle on the left in the running direction (Fig. 18): fig. 18 • Effect some rotations to the right until seeds are released from the distributing wheels. All wheels are now filled with seeds. •...
- Page 40 The seeds collected in the sack have to be weighed (Fig. 19). The weight of these seeds has to be multiplied by 100 in order to obtain the equivalent of the quantity in kg/ha. fig. 19 For 1 are (100 m²): Weighed quantity x 100 = Seeded quantity in kg/ha To obtain a larger quantity a higher number has to be selected on the graduated scale of the selector, and vice versa to obtain a smaller quantity.
-
Page 41: Maintenance
6.9. Maintenance The AMAZONE Seeder has been designed and realised for reducing maintenance works to a minimum. However, it is recommended to check the following points at regular intervals: The oil level in the selector box by means of the level indicator. -
Page 42: Amazone Gbk Combination Seeding System
AMAZONE GBK Combination seeding system Fields of application With the AMAZONE GBK Combination Seeding System, you can create new greens, such as e. g. sports fields, fairways, parks, etc. Its application for creating greens makes it possible to execute the following works in a single operation: •... - Page 43 fig. 20 Adjustment of the upper eccentrics: • Lift the machine until the upper eccentrics are no longer in contact with the support bars. • Detach the locking screws of the eccentrics by means of the crank handle (Fig. 21). fig.
- Page 44 The two upper eccentrics must be adjusted in the same way to achieve a regular performance. By means of the lower eccentrics it is possible to block the support bars and thus to shift the weight of the roller to the harrow. This possibility is used when the machine is operated on very hard and consolidated grounds where the teeth penetrate the soil insufficiently.
-
Page 45: Adjustment Of Lateral Weeders
7.2.2 Adjustment of lateral weeders After the working depth has been regulated, the lateral weeders situated at the outer ends of the front rack have to be adjusted. Procedure: • Let the power take-off turn, and lower the machine until it is in operating position. -
Page 46: Control And Adjustment Of Tracking Bars
7.2.3 Control and adjustment of tracking bars The AMAZONE Combination Seeding System can be equipped with tracking bars for ensuring a very precise seeding operation so that already seeded rows are not overseeded. Adjustment of tracking bars: • Remove the cable from the safety hook (Fig. 24). - Page 47 Tracking on the basis of the tractor path Tractor Path A = Working Width of GBK - ————————- Example: Tractor Path......... 1.25 m Working Width GBK 20 ...... 2.00 m 1.25 A = 2.00 - ————— m = 137.5 cm (Fig.
- Page 48 To adjust the tracking bar on the basis of the dimension figure A you only have to detach the locking screw by means of the crank handle and to shift the tracking bar on its support until it has reached the desired figure (Fig. 27 A).
-
Page 49: Chute Adjustment
fig. 27 B 7.2.4 Chute adjustment The chute allows you to distribute the seeds regularly by guiding the seeds towards the soil and avoiding that they are blown away by the wind. The seeding depth is variable and depends on the inclination of the chute. Operating principle During operation, a great or less pronounced accumulation of soil is formed behind the harrow depending on the working depth and the running speed. -
Page 50: Levelling Blade
To incline the chute: • Detach the two nuts M10 on both sides of the chute (Fig. 28); • Incline the chute to the desired position; • Tighten the two nuts M10 again. fig. 28 7.2.5 Levelling blade The reciprocating harrow can be equipped with a levelling blade (option) by means of which the surface of the soil to be worked can be shaped. - Page 51 fig. 29 fig. 30...
-
Page 52: Amazone Gnk Overseeder
AMAZONE GNK Overseeder Fields of application With the AMAZONE GNK Overseeder it is possible to overseed already existing lawns, such as e. g. sports fields, fairways, parks, etc. The pick-ups at the pick-up bracket are a combination of spring blades and a round bar of spring band steel assembled in such a way that: •... -
Page 53: Chute Adjustment
This adjustment can be carried out as follows: • Couple the machine to the tractor (see Chapt. 4.1.2) • Lift the machine, • Remove the storing supports: Remove the pin. Remove the axle. Detach the support. Fasten the support to the storing pedestal (Fig. 31). •... -
Page 54: Amazone Hr Conditionmaster
AMAZONE HR Conditionmaster Fields of application The AMAZONE HR Conditionmaster is composed of the reciprocating harrow and the flat roller being equipped with lateral brushes and a rear brush. By exchanging the different bars, the Conditionmaster HR can carry out the following work: •... -
Page 55: Adjustment Of Lateral Brushes
Adjustment of lateral brushes The lateral brushes prevent a furrow from being formed along the worked rows. To obtain an optimum efficiency, the brushes must be adjusted to a distance of approx.1 cm from the worked surface. To adjust the lateral brushes: •... -
Page 56: Adjustment Of Rear Brush
Adjustment of rear brush The rear brush eliminates all traces and makes the worked surface look flat simply by its dead weight. This brush is adjusted as follows: • Lower the machine to its operating position. • Lower the brush to its operating position (Fig. 35). •... -
Page 57: Application On Hard And Very Solid Grounds
Application on hard and very solid grounds To thoroughly loosen very solid ground the support bars must be blocked by means of the eccentrics, thus shifting the weight of the roller to the harrow (see Chapt. 7.2.1). It may happen that the teeth of the harrow cannot penetrate the soil. -
Page 58: Adjustment Of Rear Brush Bracket
9.11 Adjustment of rear brush bracket For weekly maintenance of consolidated ground, the brush bracket mounted on the rear side of the harrow brushes and levels the top soil which has beforehand been combed by the pick-up bracket. The rear brush bracket must be adjusted in such a way that the brushes gently touch the soil when the machine in operating position. -
Page 59: Maintenance Of Sandy Artificial Lawn
9.12 Maintenance of sandy artificial lawn To brush the sand from artificial lawns and to regularly maintain them it is sufficient to mount the brush bars at the front and rear sides of the harrow. The brushes level the traces of the operating equipment after its use and allow the sand possibly scattered over the lawn to be brushed away. -
Page 60: Further Soil Cultivation Equipment
Further Soil Cultivation Equipment The AMAZONE Combination Seeding System (roller + seeder) can also be adapted to a rotary harrow or to a stone burier (see Chapt. 5.4). 10.1 Seeding system with rotary harrow 10.1.1 Mounting and adjustment of the rotary harrow The ”three-point”... -
Page 61: Cardan Shaft
Lowering of the machine must take at least two seconds. Adjust the lowering limit switch, if any, accordingly. Smoothly put the loaded machine on the ground. 10.1.2 Cardan shaft Only use the cardan shaft prescribed by the manufacturer ! Walterscheid W 2300 SD 15-610 K34B-110 up to 1,30m working width Walterscheid W 2400 SD 25-610 K34B-120 from 1,50m working width... -
Page 62: Adjustment Of The Working Depth
10.1.6 Working depth adjustment The working depth is set using adjustment links located on each side of the rotary harrow. To do this, put the stop bolt in one of the drilled holes (fig. 39) according to the working depth desired. Adjustment links must be set on each side in the same manner. -
Page 63: Greasing
10.1.8 Greasing After the first 50 hours of operation, change the oil of the final drive by draining it using the drain plug (item S, fig. 40). Clean the inner part of the final drive with gas oil or kerosene. Fill the oil case (see characteristics in table below) through the filling plug (item C, fig. -
Page 64: Maintenance
10.1.9 Maintenance Daily checks: • Block the coupling arms of the tractor. • Check tightening of all bolts and, in particular, the central teeth carrier locknut. • Check tightening of the teeth attachment screws. Damaged teeth must be replaced immediately. Refer to chapter 10.1.10. 10.1.10 Teeth replacement The teeth of the rotary harrow are important components, the subject of... -
Page 65: Seeding System With Stone Burier
fig. 41 A fig. 41 B 10.2 Seeding system with stone burier 10.2.1 Mounting and adjustment of the stone burier Connect the coupling arms of the tractor to the coupling jaws of the tool using locking pins and bolts. The upper tie rod of the coupling has to be adjusted in such a way that the tool is more or less horizontal when in operating position. -
Page 66: Cardan Shaft Mounting
10.2.3 Cardan shaft mounting See § 4.1.4 10.2.4 Cardan shaft adjustment by coupling the machine for the first time See § 4.1.5 10.2.5 Speed at the entry of the angular gear casing See § 4.1.6 10.2.6 Adjustment of the working depth The working depth is set using adjustment links located on each side of the tool. -
Page 67: Starting
10.2.7 Starting Choose an area freshly and properly prepared or in-depth decompacted by a trailing-tooth tool of the ripper or weeder type. Remove large stones and detritus. For trouble-free burying in the future, detritus must not exceed 5/6 cm in diameter (if you follow this logic, you will always have perfect lawns, healthy soil and equipment in perfect order, at a low cost). - Page 68 • lift the tool so that the rotor is slightly above the ground. • for the first tests, select the gear corresponding to a forward movement of approximately 1,000 to 1,200 meters an hour. Slowly e engage the clutch and position the tool simultaneously. THE LIFT MUST BE FULLY LOWERED AND FLOATING.
-
Page 69: Driving
• completely remove the selection grille (fig. 44), • remove the blade which is blocked by the stone or the obstacle, • remove the obstacle and install the blade. fig. 44 10.2.8 Driving Good work is obtained when the tool follows the contours of the ground as closely as possible. -
Page 70: Stone Burier Principle
10.2.9 Stone burier principle Blades work in the ground from the bottom up by creating an excavation. The material thus removed is projected against the preselection grille which collects stones and detritus more than 4 centimeters in diameter in the bottom part of the excavation made by the rotor, the second grille placing finer materials on top. - Page 71 NOTES ............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
