NOBLE DOOR-TYPE DISHMACHINES
INSTALLATION, OPERATION,
AND SERVICE MANUAL
HT-180
HT-180
WITH VENTLESS & ENERGY RECOVERY
HT-180 Manual • 07610-004-25-05-K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HT-180 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Noble HT-180

Summary of Contents for Noble HT-180

  • Page 1 NOBLE DOOR-TYPE DISHMACHINES INSTALLATION, OPERATION, AND SERVICE MANUAL HT-180 HT-180 WITH VENTLESS & ENERGY RECOVERY HT-180 Manual • 07610-004-25-05-K...
  • Page 2 REVISION HISTORY Revision Date Made by Process Details 7-16-15 Released to production. 9-8-15 Added Sleeve Hood Spacer to parts breakdown on pg. 21. 11-10-15 Corrected part number for item #40 on pg. 25. Changed item 12 on page 25 to 05700-003-07-76. Added 05700-004-23-78 and 05700-004-23-79 to 1-12-16 QOF-386 view (pg.
  • Page 3 NOMENCLATURE HT-180 Door-type dishmachine; electrically-heated, high-temp, hot-water sanitizing, with booster heater. HT-180 FL Door-type dishmachine; front-loading, ENERGY STAR qualified, electrically-heated, ® high-temp, hot-water sanitizing, with booster heater. HT-180 NB Door-type dishmachine; electrically-heated, high-temp, hot-water sanitizing, with no rinse booster. The manufacturer provides...

  • Page 4: Table Of Contents

    GUIDES Symbols ............................1 Abbreviations & Acronyms ......................1 SPECIFICATIONS HT-180/NB/S Dimensions ......................2 HT-180 FL Dimensions ....................... 3 HT-180 VER Dimensions ......................4 HT-180 FL-VER Dimensions ...................... 5 Table Dimensions ........................6 Operating Parameters ........................ 7 Electrical Requirements ......................8 INSTALLATION Installation Instructions ......................
  • Page 5 Frame ............................46 Rinse Tank ..........................47 Steam Coil ..........................48 Motors ............................49 Heaters ............................. 51 HT-180/FL Plumbing ......................... 53 Plumbing - NB Models ......................55 Plumbing - Steam Models ......................56 Plumbing - VER/FL-VER ......................58 Plumbing Options ........................59 Wash &...

  • Page 6: Symbols

    GUIDES GUIDES SYMBOLS - Risk of Injury to Personnel WARNING - Risk of Damage to Equipment CAUTION - Risk of Electrical Shock - Caustic Chemicals - Reference Data Plate - Lockout Electrical Power - Important Note NOTICE  - Instructions Hyperlink ABBREVIATIONS &...

  • Page 7: Specifications

    HT-180/NB/S DIMENSIONS SPECIFICATIONS LEGEND A - Water Inlet (1/2” NPT) B - Electrical Connection Point C - Drain (1 1/2” NPT) D - Optional Steam Connection (3/4” NPT) can be increased 1 1/8" using the machine's adjustable feet. 07610-004-25-05-K...

  • Page 8: Ht-180 Fl Dimensions

    HT-180 FL DIMENSIONS SPECIFICATIONS 4 (102 mm) LEGEND MINIMUM A - Drain (1 1/2" NPT) B - Water Inlet (3/4" NPT) C - Electrical Connection can be increased 1 1/8" using the machine's adjustable feet. 4 (102 mm) MINIMUM 28 (711 mm)

  • Page 9: Ht-180 Ver Dimensions

    HT-180 VER DIMENSIONS SPECIFICATIONS LEGEND A - Drain (1 1/2" NPT) B - Water Inlet (3/4" NPT) C - Electrical Connection (134 mm) 4 (102 mm) can be increased 1 1/8" using the (785 mm) MINIMUM machine's adjustable feet. (641 mm)

  • Page 10: Ht-180 Fl-Ver Dimensions

    HT-180 FL-VER DIMENSIONS SPECIFICATIONS LEGEND A - Drain (1 1/2" NPT) B - Water Inlet (3/4" NPT) C - Electrical Connection (134 mm) 4 (102 mm) can be increased 1 1/8" using the (819 mm) MINIMUM machine's adjustable feet. (597 mm)
  • Page 11 TABLE DIMENSIONS SPECIFICATIONS CORNER INSTALLATION CORNER INSTALLATION 4 (102 mm) MIN ALIGN WITH TABLE - DISTANCE CAN VARY For corner install instructions:  8 7/16 4 (102 mm) MIN (214 mm) 20 1/2” ALIGN WITH TABLE - (521 mm) DISTANCE CAN VARY (762 mm) OPENING Distance from wall...

  • Page 12: Operating Parameters

    OPERATING PARAMETERS SPECIFICATIONS PERFORMANCE/CAPABILITIES WATER REQUIREMENTS Operating Capacity: HT-180/FL/VER/FL-VER HT-180/FL/NB/S Minimum Wash Temperature (°F/°C) 150/66 Racks per Hour 63 (58*) (41**) Minimum Rinse Temperature (°F/°C) 180/83 Dishes per Hour 1575 Inlet Water Temperature: Glasses per Hour 2268 12 kW Rinse Heater (°F/°C) 140/60 14 kW Rinse Heater (°F/°C)

  • Page 13: Electrical Requirements

    Numbers in this manual are for reference and may change without notice. On three-phase machines, imbalanced wild leg goes to L3. Also see the Motor Rotation section. HT-180/FL 70° Rise (14 kW) & VER/FL-VER Wash Wash...
  • Page 14 Numbers in this manual are for reference and may change without notice. On three-phase machines, imbalanced wild leg goes to L3. Also see the Motor Rotation section. HT-180 NB Wash Wash...

  • Page 15: Installation

    INSTRUCTIONS INSTALLATION INSPECTION Before installing the machine, check packaging and machine for damage. If packaging is damaged, the machine might also be damaged. If there is damage to both packaging and machine, do not throw away the packaging. The machine has been inspected and packed at the factory and is expected to arrive in new, undamaged Do not throw away condition.
  • Page 16 INSTRUCTIONS INSTALLATION VER SYSTEM 3. Lift VER system up and over lower air inlet, then align and slide into lower air inlet. VER system slides inside lower air inlet at the seam. ASSEMBLY WARNING WARNING! Use proper lifting techiques or use a lifting aid. Lower Inlet Seam...
  • Page 17 INSTRUCTIONS INSTALLATION VER SYSTEM 6. Use adustable wrench to connect long red hose to top of tee on plumbing from booster. ASSEMBLY Adjustable wrench used in this step. Apply thread tape to threads of hose before connecting. Hose is cut-to-length and will only reach intended connection point.
  • Page 18 INSTRUCTIONS INSTALLATION VER SYSTEM 9. Tidy hoses by sliding them under clamps. ASSEMBLY 10. Locate wire connectors at top of VER system (near fans) and connect black wire and white wire from machine control box (located in black cord routed from Black wire and white wire control box), black in one connector and white in the other.

  • Page 19: Leveling

    INSTRUCTIONS INSTALLATION LEVELING The machine must be level in its operating location to prevent damage to the machine during operation and to ensure best results. The machine comes with four adjustable bullet feet, which can be turned using a pair of channel locks (or by hand if the machine can be raised safely).

  • Page 20: Steam Line Connection

    (see the Plumbing Options page). The PRV comes standard  on the HT-180 VER but ships inside the machine. Click instructions icon for install instructions. Do not confuse static pressure with flow pressure. Static pressure is the line pressure in a “no flow”...

  • Page 21: Chemical Connections

    INSTRUCTIONS INSTALLATION CHEMICAL Detergent Connect detergent by removing bulkhead fitting on back of the machine and CONNECTIONS replacing it with appropriate dispensing equipment. Chemical connections should be made by chemical supplier. Using deionized water or other aggressive fluids will result in corrosion and Detergent Probe failure of components and Installs Here...

  • Page 22: Electrical Power Connections

    INSTRUCTIONS INSTALLATION ELECTRICAL POWER Electrical and grounding conductors must comply with applicable portions of National Electric Code ANSI/NFPA 70 (latest edition) and/or other electrical codes. CONNECTIONS Data plate is located on right side of the machine. Refer to data plate for machine operating requirements, machine voltage, total amperage, and serial number.

  • Page 23: Motor Rotation

    INSTRUCTIONS INSTALLATION MOTOR ROTATION On 3-Phase machines only, correct pump motor rotation must be verified before the machine is operated. Failure to do so can result in damage to the machine and components. 1. Follow Filling the Wash Tub section. 2.

  • Page 24: Operation

    OPERATING INSTRUCTIONS OPERATION PREPARATION Before operating the machine, verify the following: 1. Tank is clean and free of debris. 2. Wash arms, rinse arms, sump strainer, and scrap screen are all installed correctly. 3. Standpipe is installed. Wash & Rinse Arms, Scrap Screen Sump Strainer Standpipe POWER UP...

  • Page 25: Warm-Up Cycles

    OPERATING INSTRUCTIONS OPERATION WARM-UP CYCLES For first operation of each day, it might be necessary to run the machine through three cycles to ensure all cold water is out of the system and to verify that the machine is operating correctly. To cycle the machine, ensure power is on and tub has filled to correct level.
  • Page 26 OPERATING INSTRUCTIONS OPERATION SHUTDOWN & 4. Remove scrap screen and sump strainer. CLEANING 5. Use a hand-scraper to scrape foodsoil into a trash basket. 6. Rinse with pre-rinse hose and replace. 7. Remove all wash and rinse arms. 8. Remove end-caps from the arms. 9.

  • Page 27: Ver Coil Cleaning

    OPERATING INSTRUCTIONS OPERATION SHUTDOWN & 12. Replace end-caps and ensure they are tight. CLEANING 13. Spray or wipe out interior of the machine. 14. Replace wash and rinse arms. 15. Ensure sump strainer and scrap screen are clean and securely in place. 16.

  • Page 28: Detergent Control

    DETERGENT CONTROL OPERATION DETERGENT Detergent usage and water hardness are two factors that contribute greatly to how efficiently the machine will operate. Using detergent in proper amounts can become CONTROL a source of substantial savings. A qualified water treatment specialist can determine what is needed for maximum efficiency from the detergent.

  • Page 29: Deliming

    DELIMING OPERATION DELIMING To delime the machine, follow steps below. Tank capacities of the machine can be found on Operating Parameters page. 1. Remove rinse arms and place in sink with deliming solution. 2. Disconnect or turn off chemical feeder pumps. 3.

  • Page 30: Maintenance

    PREVENTATIVE MAINTENANCE MAINTENANCE PREVENTATIVE The manufacturer highly recommends that any maintenance and repairs not specifically discussed in this manual be performed only by qualified service personnel. MAINTENANCE WARNING! Unqualified personnel performing maintenance on the machine may void the warranty, lead to larger problems, or cause harm to the operator. WARNING Following operating and cleaning instructions in this manual will result in the most efficient results from the machine.

  • Page 31: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING WARNING! Inspection, testing, and repair of electrical equipment should only be performed by a qualified service technician. Many tests require the machine have power to it and live electrical components be exposed. USE EXTREME CAUTION WHEN TESTING THE MACHINE. WARNING OBSERVATION POSSIBLE CAUSE...
  • Page 32 TROUBLESHOOTING TROUBLESHOOTING WARNING! Inspection, testing, and repair of electrical equipment should only be performed by a qualified service technician. Many tests require the machine have power to it and live electrical components be exposed. USE EXTREME CAUTION WHEN TESTING THE MACHINE. WARNING OBSERVATION POSSIBLE CAUSE...

  • Page 33: Control Box

    CONTROL BOX PARTS NOTICE Machines before 21D393474 have a different control box. Click here to open earlier manual. *Power supply and relay used only on machines with door interlock and VER machines with DC fans. 07610-004-25-05-K...
  • Page 34 CONTROL BOX PARTS 07610-004-25-05-K...
  • Page 35 CONTROL BOX PARTS Fuses 208/230 V 460 V WARNING: DISCONNECT POWER TO MACHINE BEFORE SERVICING WARNING: DISCONNECT POWER TO MACHINE BEFORE SERVICING DETERGENT EXHAUST FAN CONSTANT VOLTAGE RINSE-AID DISPENSER DETERGENT EXHAUST FAN CONSTANT VOLTAGE RINSE-AID DISPENSER DISPENSER CONTROL CONNECTION CONNECTION DISPENSER CONTROL CONNECTION...
  • Page 36 CONTROL BOX PARTS ITEM DESCRIPTION PART NUMBER Timer Bracket 05700-003-02-08 Locknut, 6-32 05310-373-03-00 Contactor, 4-Pole 05945-109-01-69 Terminal Block 05940-011-48-27 Locknut, 10-24 05310-373-01-00 Contactor, Wash Motor 05945-002-74-20 Light, Green 05945-111-44-43 Light, Red 05945-111-44-45 Light, Yellow 05945-111-44-44 Ground Lug 05940-200-76-00 Tricnut, 6-32 05340-118-04-00 Plug, 1/2”...
  • Page 37 CONTROL BOX PARTS ITEM DESCRIPTION PART NUMBER Switch, Rotary Selector 05930-003-97-61 Switch, Operation 05930-301-53-00 Switch, Power 05930-011-49-55 Dome Plug 05975-002-29-94 Power Supply, In 100-240 V DC, 1.8 A, Out 24 V, 2.5 A* 05950-004-81-79* Relay, 10 A, 220 V* 05945-004-84-93* Relay, 240 V 05945-002-47-74 Control Box Weldment...

  • Page 38: Hood

    HOOD PARTS ITEM DESCRIPTION PART NUMBER Hood Support 05700-002-78-99 Bolt, 1/4-20 x 1/2” 05305-274-21-00 Washer, Flat, SS, 1/4-20 05311-174-01-00 Spacer, Sleeve Hood 05700-003-55-15 Locknut, 1/4-20 with Nylon Insert (Not Shown) 05310-374-01-00 07610-004-25-05-K...

  • Page 39: Hood - Fl/Fl-Ver

    HOOD - FL/FL-VER PARTS ITEM DESCRIPTION PART NUMBER Upright, Right 05700-004-81-53 Upright, Left 05700-004-81-54 Bracket, Upright Upper 05700-004-76-36 Cap, Upright 05700-004-79-65 Bracket, Manifold Position 05700-011-34-63 Guide Block, Stop 09330-004-77-73 Bracket, Conduit EL-104106 Screw, 1/4-20 x 1/2" Button Head Hex 05305-004-62-33 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00 Washer, 1/4-20...

  • Page 40: Door & Arm

    DOOR & ARM PARTS 11 12 07610-004-25-05-K...
  • Page 41 DOOR & ARM PARTS ITEM DESCRIPTION PART NUMBER Cantilever Arm 05700-031-50-67 Spring Pin, 1/4" x 1 1/8" 05315-407-06-00 Yoke Assembly 05700-000-75-77 Cotter Pin 05315-207-01-00 Yoke 05700-000-75-78 Clevis Pin, 5/16” x 1 3/8” 05315-700-01-00 Nylon Washer 05311-369-03-00 Bushing 03120-100-03-00 Rod, Spring 05700-003-67-39 Spring 05340-109-02-00...
  • Page 42 DOOR & ARM PARTS ITEM DESCRIPTION PART NUMBER Door, Left Side (Complete Assembly) 05700-002-30-87 Door, Left Side (VER, Complete Assembly) 05700-004-24-32 Door Only, Left Side 05700-002-29-86 Door Only, Left Side (VER) 05700-004-24-34 Door Connecting Plate (Not Shown) 05700-002-20-78 Bracket, Cantilever Arm Support 09515-003-15-64 Wear Button, 1/2"...

  • Page 43: Door - Fl/Fl-Ver

    DOOR - FL/FL-VER PARTS SECTION A-A 07610-004-25-05-K...
  • Page 44 DOOR - FL/FL-VER PARTS ITEM DESCRIPTION PART NUMBER Bracket, Door, Right 05700-004-74-35 Bracket, Door, Left 05700-004-74-36 Guide, Rack, Right 05700-004-72-81 Guide, Rack, Left 05700-004-72-82 Spring, Door Torsion, Right 05340-004-74-71 Spring, Door Torsion, Left 05340-004-77-89 Yoke, Spring Rod 09515-004-74-76 Washer, Nylon 05311-369-03-00 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00...

  • Page 45: Tub

    PARTS NOTICE Machines before 21D393474 did not have a float. Click here to open earlier manual. 07610-004-25-05-K...
  • Page 46 PARTS ITEM DESCRIPTION PART NUMBER Track Assembly 05700-002-01-00 Bulk Head Plug 04730-609-05-00 Wash Motor See Motors page. Gasket 05700-111-35-03 O-ring 05330-111-35-15 Bolt, Hex 3/8-16 x 1 1/4" Long 05305-276-10-00 Lower Wash Manifold 05700-031-46-00 Sump Strainer 05700-002-16-13 Bracket, Sump Strainer 05700-001-22-24 Locknut, 1/4-20 with Nylon Insert 05310-374-02-00 Scrap Screen...
  • Page 47 PARTS ITEM DESCRIPTION PART NUMBER Lockwasher, 5/16", Split 05311-275-01-00 Nut, Hex, 5/16-18 05310-275-01-00 Locknut, 10-24 with Nylon Insert 05310-373-01-00 Cover, Wash Heater 05700-031-47-57 Decal, Warning-Disconnect Power 09905-004-08-16 Harness, 5-Connector 05700-004-23-78 Thermostat Mounting Bracket 05700-004-22-17 Wash Heater Gasket 05330-011-47-79 Probe, Thermistor 4” 06685-004-17-26 Thermostat, High Limit 05930-004-33-12...

  • Page 48: Steam Tub

    STEAM TUB PARTS 07610-004-25-05-K...
  • Page 49 STEAM TUB PARTS ITEM DESCRIPTION PART NUMBER Track Assembly 05700-002-01-00 Bulk Head Plug 04730-609-05-00 Wash Motor See Motors page. Gasket 05700-111-35-03 O-ring 05330-111-35-15 Bolt, Hex 3/8-16 x 1 1/4" Long 05305-276-10-00 Lower Wash Manifold 05700-031-46-00 Sump Strainer 05700-002-16-13 Bracket, Sump Strainer 05700-001-22-24 Locknut, 1/4-20 with Nylon Insert 05310-374-02-00...
  • Page 50 STEAM TUB PARTS ITEM DESCRIPTION PART NUMBER Probe, High Water 06680-200-02-68 Thermostat, High Limit 05930-004-33-12 Cover, Wash Heater 05700-031-47-57 Decal, Warning-Disconnect Power 09905-004-08-16 Locknut, 10-24 with Nylon Insert 05310-373-01-00 Steam Coil 05700-031-41-37 Probe, Thermistor 4” 06685-004-17-26 Thermostat Mounting Bracket 05700-004-22-17 Thermostat, Electric Dual 06685-004-17-27 Harness, 5-Connector...

  • Page 51: Frame

    FRAME PARTS ITEM DESCRIPTION PART NUMBER Bolt, 1/4-20 x 1/2” 05305-274-02-00 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-02-00 Front Panel 05700-002-36-65 Bullet Foot 05340-108-01-03 Flanged Bullet Foot (Optional) (Back feet on FL/FL-VER) 05340-002-34-86 07610-004-25-05-K...

  • Page 52: Rinse Tank

    RINSE TANK PARTS Complete Assemblies 208-230 V, 14 kW 70 ◦ Rise - 05700-004-43-33 208-230 V, 12 kW 40 ◦ Rise - 05700-004-52-19 460 V, 14 kW 70 ◦ Rise - 05700-004-53-22 460 V, 12 kW 40 ◦ Rise - 05700-004-53-21 NOTICE Machines before 18C355287 have a...

  • Page 53: Steam Coil

    STEAM COIL PARTS ITEM DESCRIPTION PART NUMBER Complete Steam Coil Assembly 05700-002-08-62 Steam Coil 05700-021-41-38 Stand C, Steam Coil Support 05700-002-08-52 Stand D, Steam Coil Support 05700-002-08-53 Gasket, Steam Coil 05700-001-17-86 Washer, Steam Coil 05700-001-17-87 Adapter, Steam Coil Nut 05310-011-17-85 Stand A, Steam Coil Support 05700-002-08-50 Stand B, Steam Coil Support...

  • Page 54: Motors

    MOTORS PARTS Complete Assemblies (See next page for parts.) See Motor Rotation section. The models covered in this manual come supplied with various wash motor assemblies (a wash motor assembly includes the wash motor and the pump end), depending on the characteristics of the machine. To ensure you order the correct wash motor assembly for the model you are servicing, please refer to the following table: MODEL VOLTS...
  • Page 55 MOTORS PARTS Parts (See previous page for complete assemblies.) The models covered in this manual come supplied with various wash motors (see previous page), depending on the characteristics of the machine. To ensure you order the correct parts for the model you are servicing, please refer to the following table: ITEM DESCRIPTION...

  • Page 56: Heaters

    04540-121-47-39 04540-121-47-40 04540-121-63-38 04540-121-47-39 04540-121-47-40 04540-121-63-38 04540-002-44-31 04540-002-44-32 04540-121-63-38 04540-002-43-09 04540-002-43-10 04540-121-65-99 04540-100-01-15 04540-121-63-39 04540-121-65-99 04540-100-01-15 04540-121-63-39 HT-180 VER Volts Phase Wash Heater Rinse Heater (14 kW) 04540-121-47-39 04540-121-63-38 04540-121-47-39 04540-121-63-38 04540-121-47-39 04540-121-63-38 04540-121-47-39 04540-121-63-38 04540-121-47-39 04540-121-63-38 04540-121-47-39 04540-121-63-38 04540-121-47-39...
  • Page 57 Phase Wash Heater 04540-121-47-39 04540-121-47-39 04540-121-47-39 04540-121-47-39 04540-121-47-39 04540-121-47-39 04540-121-47-39 04540-121-47-39 04540-002-44-31 04540-002-43-09 04540-121-65-99 04540-121-65-99 HT-180 with Round-Flanged Rinse Heater Volts Phase Wash Heater Rinse Heater (12 kW) Rinse Heater (14 kW) 04540-121-47-39 04540-003-58-27 04540-003-58-28 04540-121-47-39 04540-003-58-27 04540-003-58-28 04540-121-47-39 04540-003-58-27...

  • Page 58: Ht-180/Fl Plumbing

    HT-180/FL PLUMBING PARTS Complete Plumbing Assembly 05700-004-54-52 Top View Back View NOTICE When servicing plumbing components, take care not to damage the threads of each individual item. Damaged threads can cause leaks and loss of pressure, which could adversely affect the performance of the machine. It is strongly recommended that thread tape—used in conservative amounts—be applied to threads when joining components together.
  • Page 59 HT-180/FL PLUMBING PARTS ITEM DESCRIPTION PART NUMBER Y-strainer, 1/2" 04730-217-01-10 Vacuum Breaker, 1/2" Brass 04820-003-06-13 Plug, Rinse Injector, 1/8” Brass 04730-209-07-37 Casting, 1/2" Flanged Coupling 05700-004-47-97 Rinse Injector 05700-002-56-75 Gasket, Rinse Injector (Not Shown) 05330-111-42-81 Washer, 1/4-20 Hex with Nylon Insert...

  • Page 60: Plumbing - Nb Models

    PLUMBING - NB MODELS PARTS ITEM DESCRIPTION PART NUMBER Complete Assembly 05700-003-60-73 Tee, Brass, 1/2" x 1/2" x 1/4" 04730-411-25-01 Adapter, 1/2” 04730-011-59-53 Y-Strainer, 1/2” 04730-217-01-10 Ball Valve, Bronze, 1/4" 04810-011-72-67 Adapter, 1/2” 04730-401-03-01 Pressure Gauge, 0-100 PSI 06685-111-88-34 Valve, Solenoid, 1/2" 208-240 V 04810-003-71-56 Vacuum Breaker, 1/2"...

  • Page 61: Plumbing - Steam Models

    PLUMBING - STEAM MODELS PARTS NOTICE When servicing plumbing components, take care not to damage the threads of each individual item. Damaged threads can cause leaks and loss of pressure, which could adversely affect the performance of the machine. It is strongly recommended that thread tape—used in conservative amounts—be applied to threads when joining components together.
  • Page 62 PLUMBING - STEAM MODELS PARTS ITEM DESCRIPTION PART NUMBER Complete Assembly 05700-002-01-60 Bushing, Reducing, 3/4’’ to 1/2’’ 04730-911-02-34 Union, 3/4’’, Black Iron 04730-912-01-00 Elbow, 3/4”, Black Iron 04730-906-10-34 Nipple, Close, 3/4’’, Black Iron 04730-907-01-00 Gate Valve, 3/4” 04820-100-19-00 Y-Strainer, 3/4”, Black Iron 04730-217-01-32 Bracket, Steam Plumbing Support 05700-002-01-63...

  • Page 63: Plumbing - Ver/Fl-Ver

    PLUMBING - VER/FL-VER PARTS BACK OF MACHINE APPROX. 45° ITEM DESCRIPTION PART NUMBER Complete Assembly 05700-004-53-48 Elbow, 1/2", 90-degree Street Brass 04730-206-08-00 Nipple, 1/2" Close Brass 04730-207-15-00 Valve, Solenoid, 1/2" 208-240 V 04810-003-71-56 Y-Strainer, 1/2” 04730-217-01-10 Elbow, 1/2" 90-degree Brass 04730-011-42-96 Tee, 1/2"...

  • Page 64: Plumbing Options

    Tee, Brass, 1/2" x 1/2" x 1/4" 04730-002-22-56 Water Pressure Regulator, 1/2” 04820-100-04-07 Water Pressure Regulator, 3/4” (VER) 06685-011-58-22 Adapter, 1/2" 04730-011-59-53  *PRV comes standard on the HT-180 VER but ships inside the machine. Click here for install instructions. 07610-004-25-05-K...

  • Page 65: Wash & Rinse Assemblies

    WASH & RINSE ASSEMBLIES PARTS FINAL RINSE ARMS & MANIFOLD WASH ARMS & MANIFOLD 07610-004-25-05-K...
  • Page 66 WASH & RINSE ASSEMBLIES PARTS ITEM DESCRIPTION PART NUMBER Upper Manifold 05700-031-34-82 Nut, 3/8-16 Hex 05310-276-01-00 Lockwasher, 3/8" 05311-276-01-00 Bolt, Hex 3/8-16 x 7/8" 05306-011-36-95 O-ring 05330-111-35-15 Positioning Bracket, Manifold Tube 05700-011-34-63 Tube, Wash Manifold 05700-131-15-07 Gasket, Manifold 05700-111-35-03 Wash Arm 05700-004-13-13 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00...

  • Page 67: Ver System

    VER SYSTEM PARTS 07610-004-25-05-K...
  • Page 68 VER SYSTEM PARTS ITEM DESCRIPTION PART NUMBER VER System, Complete Assembly 05700-004-53-47 Plate, Fan Mounting 05700-004-18-07 Upper Shroud 05700-004-18-06 Screw, 6-32 x 1 3/4" 05305-004-19-80 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00 Exhaust Box 05700-004-18-04 Gasket, Heat Exchanger 05330-004-18-22 Gauge 06680-004-19-78 Coil Box, Back 05700-004-18-03...

  • Page 69: Ver Door Interlock

    VER DOOR INTERLOCK PARTS Complete Interlock Assembly 05700-004-97-05 Complete Interlock Box Assembly (includes above) 05700-004-97-06 07610-004-25-05-K...
  • Page 70 VER DOOR INTERLOCK PARTS ITEM DESCRIPTION PART NUMBER Plate, Interlock 05700-004-97-10 Link, Interlock Connector 05700-004-71-37 Interlock Cam 05700-004-71-39 Interlock Guide 05700-004-71-50 Pin, Interlock 05700-004-71-49 Motor, Interlock 06105-004-70-04 Switch, Interlock 05930-004-71-36 Set Screw, 6-32 x 1/4" 05305-004-71-42 Shoulder Screw, 10-32 05305-004-71-40 Screw, 10-32 x 1/2"...

  • Page 71: Fl-Ver Door Interlock

    FL-VER DOOR INTERLOCK PARTS FL-VER Door Interlock Assembly 05700-005-05-42 ITEM DESCRIPTION PART NUMBER Bracket, Solenoid Guide 05700-005-05-41 Screw, 6-32 x 1/8" 05305-004-51-01 Locknut, 1/4-20 Low Profile with Nylon Insert 05310-374-02-00 Bushing, Door Interlock Latch Pivot 09330-005-06-56 Washer, 1/4-20 x 3/4" OD 05311-011-76-30 Latch, Door Interlock 05700-005-05-38...

  • Page 72: Ver Door Interlock Override

    VER DOOR INTERLOCK OVERRIDE PARTS The following instructions are for models equipped with the Door Interlock option. These instructions should only be used if the door interlock fails to unlatch and the door won't open. 1. Turn machine off by flipping the power switch to "OFF." CYCLE POWER HI LIMIT...

  • Page 73: 460 V Machine Transformer Mounting Box

    460 V MACHINE TRANSFORMER MOUNTING BOX PARTS 460 V Transformer 2 A Circuit Breaker 05950-111-65-93 05925-111-64-18 Transformer Mounting Bracket 05700-031-62-82 Transformer Mounting Box 05700-002-10-01 Transformer Mounting Box Top (Not Shown) 05700-000-78-53 07610-004-25-05-K...

  • Page 74: Kits

    KITS PARTS Call 1-880-800-5672 to order kits for HT-180 models and use the part numbers below: DESCRIPTION PART NUMBER VER Door Interlock Kit 06401-004-03-23 Door Magnet Cover Kit 06401-004-07-73 Drain Water Tempering Kit 06401-004-85-80 Exhaust Fan Contactor Kit 05700-004-35-35 False Panel Kit...

  • Page 75: Schematics

    208-230 V SCHEMATICS HT-180 SCHEMATIC 07610-004-25-05-K...

  • Page 76: 460 V

    460 V SCHEMATICS HT-180 SCHEMATIC 07610-004-25-05-K...
  • Page 77 NB, 208-230 V SCHEMATICS HT-180 SCHEMATIC 07610-004-25-05-K...
  • Page 78 NB, 460 V SCHEMATICS HT-180 SCHEMATIC 07610-004-25-05-K...

  • Page 79: Steam, 208-230 V

    STEAM, 208-230 V SCHEMATICS HT180 SCHEMATIC STEAM 07610-004-25-05-K...

  • Page 80: Sdi Options

    SDI OPTIONS SCHEMATICS SDI OPTION SDI OPTION 07610-004-25-05-K...
  • Page 82 NOBLE DOOR-TYPE DISHMACHINES Noble Warewashing • Lancaster, Pennsylvania www.nobleproducts.biz For Service Call 1-888-800-5672 HT-180 Manual • 07610-004-25-05-K...
