PartySpeaker XXL1
Outdoor Mobile Speaker
I.
Features
1. Ultra-large magnetic circuit high-sensitivity speaker with high penetrating power,
low-frequency vibration and perfect medium/high frequency representation.
2. The latest decoding chips supporting stable playback of MP3 from USB/TF card of up to 32GB.
3. 3.5mm audio input for connection to a wide range of sound sources.
4. Built-in high capacity battery for up to 2 hours of consecutive playback.
5. Connect the microphone and use adjustable reverberation, voice and Karaoke function for
outstanding performances.
6. Battery with built-in recharging protection to ensure a long and stable service life.
7. Built-in low battery and full recharging indication. Human-oriented use.
8. With belt/handle design for best choice of mobile speaker.
9. Microphone recording input can be used as your personal business assistant.
10. Supports Bluetooth and TWS function.
II. Recording
Recording via External Microphone:
Connect a storage device (USB/TF card) and briefly press RECORD to start recording for a
duration that depends on the storage capacity. During recording, tune the "-ECHO+" button to
minimum. Note that the microphone should be located a proper distance away from the speaker to
prevent any feedback or noise.
Note: This product starts recording from the time as displayed on the LED screen.
III. Bluetooth pairing operation and related parameters:
1.Power: switch ON the power, press "MODE" to enter Bluetooth mode. The display screen will
show "BLUE".
2.Switch on the Bluetooth function of your mobile phone and start searching. When the mobile
phone shows
"PartySpeaker
does not require a password. If a password is asked, please enter "0000" to continue pairing. After
successful pairing, the speaker sends out a prompt message. This means that the pairing between
mobile phone and Bluetooth speaker has been successful.
3.Play the music on your mobile phone and you will hear a good sound from the speaker.
IV. Functional Operations and Features
User Manual
XXL1", immediately click on connect. The mobile phone connection
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Klipsch PartySpeaker XXL1
Summary of Contents for Klipsch PartySpeaker XXL1
- Page 1 PartySpeaker XXL1 Outdoor Mobile Speaker User Manual Features 1. Ultra-large magnetic circuit high-sensitivity speaker with high penetrating power, low-frequency vibration and perfect medium/high frequency representation. 2. The latest decoding chips supporting stable playback of MP3 from USB/TF card of up to 32GB.
- Page 2 1. LED screen. 2. VOLUME PRESS BASS/TREBLE/MIC VOL/ECHO/GT.VOL ： By default, this button regulates master volume. Press once briefly for bass adjustment. Press twice briefly for high pitch adjustment. Press three times briefly for microphone volume adjustment. Press four times briefly for microphone reverb adjustment.
- Page 3 : In USB/TF card/Bluetooth reading mode, briefly press this key to play/pause. In USB/TF card reading mode, hold down this key to select one of four playback sequencing modes (All - play all tracks in sequence; RAND - play at random; ONE - repeat one track; FOD - repeat all tracks in a folder).
- Page 4 V. Operating Instructions on Remote Control 1. Power Button: Briefly press this button to enter standby mode; briefly press it again to resume. If no device is connected, the system goes to " BT ". : In USB/TF/AUX/Bluetooth mode, briefly press this key to mute the device. 3.
- Page 5 10. VOL-: Master volume down control button. : Functions as “ ” on the master device. : Functions as “ ” on the master device. : Functions as “ ” on the master device. 14. Numeric Keys 0~9: In USB/TF card reading mode, to play Track 12 simply enter numbers "1" and "2"...
