  • Page 1 User Manual P21WL01/ P21AL01/ P21EL01...

  • Page 2: Notice

    Notice The illustrations in this user’s manual are for reference only. Actual product specifications may vary with territories. The information in this user’s manual is subject to change without notice. THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE FOR ERRORS OR OMISSIONS CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL DAMAGES, WHICH MAY RESULT FROM THE PERFORMANCE OR USE OF THIS MANUAL.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Notice ...................... 2 Preface ....................4 1.1 Regulations information ............4 1.2 Safety instructions ..............5 1.2 Consignes de sécurité ............6 1.3 Notes for this manual .............. 7 1.4 Release history ............... 7 Getting to know the basics ..............8 2.1 Product specification ..............

  • Page 4: Preface

    Preface 1.1 Regulations information • CE compliance This device is classed as a technical information equipment (ITE) in class A and is intended for use in commercial, transport, retailer, public, automation…field. • FCC rules This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 5: Safety Instructions

    1.2 Safety instructions The following safety precautions will increase the life of the panel PC. Follow all Precautions and instructions. Do not place this device underneath heavy loads or in an unstable position. Do not use or expose this device around magnetic fields as magnetic interference may affect the performance of the device.

  • Page 6: Consignes De Sécurité

    1.2 Consignes de sécurité Les mesures de précaution suivantes servent à prolonger la durée de vie de l'ordinateur. Par conséquent, veuillez observer l'ensemble des mesures de précaution et des instructions. Ne pas poser d'objets lourds sur l'appareil ou ne pas le mettre pas dans une position instable.

  • Page 7: Notes For This Manual

    1.3 Notes for this manual CAUTION! Important information that must be followed for safe operation.  NOTE: Information for special situations. 1.4 Release history Date Version Revision note 10.2023 First released...

  • Page 8: Getting To Know The Basics

    NOTE: The product’s specification will depend upon the actually shipped product. System 8th Gen. Intel Whiskey Lake-U series Processors – ® Intel Core™ i7-8665UE vPro ® Intel Core™ i7-8565U ® P21WL01 Intel Core™ i5-8365UE vPro ® Intel Core™ i5-8265U ® Intel Core™ i3-8145UE ® Intel Celeron 4305UE ®...
  • Page 9 2 x 260 pin SO-DIMM up to 64GB, P21WL01 Dual Channel 1.2 V DDR4 2400MHz 2 x 260 pin SO-DIMM up to 32GB, P21EL01 Memory Dual Channel 1.2 V DDR4 3200MHz 2 x 262 pin SO-DIMM up to 64GB, P21AL01 Dual Channel 1.1 V DDR5 4800MHz...
  • Page 10 Network 1 x Intel 2.5 GbE ® Ethernet 1 x Intel GbE LAN or 2.5 GbE (optional) ® (Support Wake on Lan) 1x M.2 2230, M key Realtek RTL8821C (optional) WLAN ( 802.11a/b/g/n/ac + Bluetooth 4.2 with 2x internal antenna (default) / 2x external antenna (optional)) I/O Interface 1 x RJ-45 Gigabit Ethernet...
  • Page 11 CE, FCC, BSMI, Safety CB, cTUVus,CEC, BSMI EU, US, Taiwan CAUTION: MODEL P21WL01/ P21AL01/ P21EL01 IS DESIGNED TO USE WITH THE DC INPUT: (19Vdc / 4.74A) ADAPTERS. CAUTION! Adapter watt should follow default setting or refer to rating label information.

  • Page 12: Product Overview

    2.2 Product overview Refer to the following illustration to identify the components on this side of the panel PC. Features and configurations vary by model.  NOTE: The product’s color, I/O port, indicator location will depend upon the actually shipped product.
  • Page 13 Webcam 21.5" FHD LCD display (True-Flat PCAP touch) Connector for external antenna (optional) SSD 2.5", 7mm Potential equalization pin (POAG) (optional) DVI-I (Single Link) (optional) COM 3 port (RS232/ RS422/ RS485) COM 2 port (RS232/ RS422/ RS485) Headphone / Line-out jack Microphone jack LAN (RJ45) ports : 1st LAN on MB, 2nd LAN via optional daughter board (support wake on LAN)

  • Page 14: Product Dimensions

    2.3 Product dimensions Unit: mm 542.04 25.9 271.02 478.24...

  • Page 15: Getting Started

    Getting Started CAUTION: For safety reasons, please ensure that the power cord is disconnected before opening the case. →  Follow the steps 1 4 to remove the cover. →  Follow the steps 4 1 to install the cover. Middle Frame Cover Ten screws...

  • Page 16: Device Installation

    3.1 M.2 Device Installation 1. Locate the M.2 2280 M key slot on the motherboard, unfasten the screw first. SO-DIMM slot M.2 2280 M key slot Cover 2. Install the M.2 device into the M.2 slot and secure with the screw. ...

  • Page 17: Memory Module Installation

    3.2 Memory Module Installation 2 x 260 pin SO-DIMM up to 64GB, P21WL01 Dual Channel 1.2 V DDR4 2400MHz 2 x 260 pin SO-DIMM up to 32GB, P21EL01 Dual Channel 1.2 V DDR4 3200MHz 2 x 262 pin SO-DIMM up to 64GB, P21AL01 Dual Channel 1.1 V DDR5 4800MHz...
  • Page 18 4. Gently insert the module into the slot in a 45-degree angle. 5. Carefully push down the memory module until it snaps into the locking mechanism. 45-degree angle 6. Install the 2nd memory module into the DIMMB1 slot (proceed with steps B3 to B5). 7.

  • Page 19: How To Replace The 2.5" Ssd

    3.3 How to replace the 2.5" SSD 1. If you want to replace the 2.5" SSD, unscrew the thumbscrew and two screws of the bracket and remove it. Old SSD 2. Unfasten the two screws (M3 x 4L) New SSD and remove old SSD.

  • Page 20: Optional Installation Of Wlan Antennas

    3.4 Optional installation of WLAN antennas (appropriate chassis version required) Take the two antennas out of the accessory box. Screw the antennas on to the appropriate connectors on the back panel. Make sure the antennas are aligned vertically or horizontally to achieve the best possible signal reception.

  • Page 21: Powering On The System

    3.5 Powering on the system Follow the steps (1-3) below to connect the AC adapter to the power jack (DC-IN). Press the power switch/button (4) to turn on the system. DC-IN Method 1: Depending on the model, press the power switch (a or b) to turn on the system.

  • Page 22: Potential Equalization (Optional)

    3.6 Potential equalization (optional) When potential equalization between the panel PC and other devices is required then connect the potential equalization pin (POAG) to the potential equalization terminal of the equipment. Potential equalization pin (POAG) Potential equalization cable (with 2 POAG-plugs) Other devices...

  • Page 23: Vesa Mounting To The Wall (Optional)

    3.7 VESA mounting to the wall (optional) The standard VESA openings show where an arm / wall mount kit which is available separately can be attached. Support VESA Mount 100 x 100 mm Screws M4x6L*4pcs  NOTE: The Panel PC can be wall-mounted using a VESA compatible 100 mm x 100 mm wall / arm bracket.

  • Page 24: How To Use The Touch Panel

    3.8 How to use the Touch Panel Touch panel brings digital life for an easy touch experience. Experience the ease of managing your digital life with a few touches. Your touch functions like a mouse device and all you need to interact with the touch panel.

  • Page 25: Using The Vertical Stand (Optional)

    3.10 Using the Vertical Stand (optional) 1. Tighten the vertical stand securely with four screws (M4 x 12L) 2. Properly tighten the vertical stand with four screws (M4 x 10L) at the rear of the Panel PC. Screws M4 x 10L * 4pcs Screws M4 x 12L * 4pcs...

  • Page 26: Bios Setup

    BIOS Setup 4.1 About BIOS Setup The default BIOS (Basic Input/Output System) is already properly configured and optimized, there is normally no need to run this utility. 4.1.1 When to Use BIOS Setup ? You may need to run the BIOS Setup when: ・...
  • Page 27 ・ When OS support is Windows 11 : 1. Click the "Start menu" and select "Settings". 2. Select "Windows Update" and Click "Advanced options". 3. Click "Recovery". 4. Under "Advanced startup", click "Restart now". The system will restart and show the Windows 11 boot menu. 5.
