OPERATION, INSTALLATION AND MAINTENANCE MANUAL
Wall Mounted Radiant Gas Heater
DANGER
!
If you smell gas:
1.
Shut off gas to the appliance.
Extinguish any open flame.
2.
3.
If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department
DANGER
!
1. Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
2. An LP-cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
!
!
Improper Installation, adjustment,
alteration, service, or maintenance can
cause property damage, injury or death.
Read this operating and assembly
instruction thoroughly before installing
or serving this heater.
.
!
!
FOR OUTDOOR USE ONLY.
Appliance is to be protected from rain.
TO BE INSTALLED ONLY BY AN
AUTHORIZED PERSON.
TGH34WL-2
TGH34WN-2
WARNING
WARNING
Manual # P80196019A - Date:2018/12/19
!
!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HEATSTRIP TGH34WN-2
Summary of Contents for HEATSTRIP TGH34WN-2
- Page 1 OPERATION, INSTALLATION AND MAINTENANCE MANUAL TGH34WL-2 Wall Mounted Radiant Gas Heater TGH34WN-2 DANGER WARNING Improper Installation, adjustment, If you smell gas: alteration, service, or maintenance can Shut off gas to the appliance. cause property damage, injury or death. Extinguish any open flame.
-
Page 2: Table Of Contents
Table of Contents Pre-Assembly Instructions........................3 Primary Safety Warnings.........................4-5 Product Overview..........................6 Part Diagrams and Lists......................7-9 Assembly Instructions........................10-11 Use and Care Instruction.......................12-13 Lighting Instruction..........................14 Troubleshooting.............................15 Cleaning and Maintenance......................15 Warranty Terms........................Back Cover For the repair or replacement parts you need: Call 1-800-474-5587 M-F 8AM-4:30 PM PST To obtain the correct replacement parts for your gas grill, please refer to the part numbers in this parts list. -
Page 3: Pre-Assembly Instructions
Pre-Assembly Instructions For Your Safety PRE-ASSEMBLY LPG CYLINDER USE AND SAFETY Read and perform the following pre-assembly LP Gas heater models are designed for use with a instructions: standard 20 lb. Liquid Propane Gas (LP Gas) tank, Required Tools not included with heater. Never connect your gas •... -
Page 4: Primary Safety Warnings
OUTDOOR AREAS SAFETY APPLIANCE LOCATIONS This appliance is for outdoor use only. This appliance must be placed on level firm ground. This appliance shall only be used in an above ground open-air situation with natural ventilation, without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural convection. - Page 5 FOR YOUR SAFETY LPG CYLINDER USE AND SAFETY WARNING WARNING 1. Do NOT store or use gasoline or other flammable • LPG heater models must be used with Liquid liquids and vapors within 25 feet (8m) of this appliance. Propane Gas and the regulator assembly supplied. •...
-
Page 6: Product Overview
The following clearance should be followed: Model Type Wall Mounted The heater should not be installed: Model No TGH34WL-2 TGH34WN-2 - Where heat ignition can cause damage to gas cylinders/lines Gas Type Propane Natural Gas - Near other combustible materials. -
Page 7: Part Diagrams And Lists
Hardware Pack Parts List PART # PART DESCRIPTION PURPOSE OF PART P06033006A Hardware Pack For use in assembly of TGH34WN - 2 S112M05102 Pan Head Screw M5 x 10mm Install Heat Deflector to Head P05501166D Pin Φ6 x 150mm P05501164B R Cotter Pin Install heater to Wall Mounting Bracket S020100223 Bolt M6 x 150mm S411M0606A Wing Nut M6... - Page 8 Parts Diagram For the repair or replacement parts you need: Call 1-800-474-5587 M-F 8AM-4:30 PM PST To obtain the correct replacement parts for your gas grill, please refer to the part numbers in this parts list. The following information is required to ensure you receive the correct parts: 1.
- Page 9 Parts List DESCRIPTION PART NO. QTY. Protective Guard P03351045D Name Plate P00408001A Pilot Burner Assembly - NG Y0040027 Orifice (NG) P06536035A Thermocouple with wire P05308006B Electrode with wire P02618081A Thermocouple wind shield P033510234 Burner Assembly P02005035D Burner Bracket, Side P033510324 Burner Holder P020110804 Manifold assembly - NG...
-
Page 10: Assembly Instructions
Assembly Instructions CAUTION: To assemble this heater, you should obtain assistance from another person when handling the larger, heavier pieces. Please refer to the Page 6 "Dimension and Clearance Detail" before installing this heater. Remove all the packing materials. Install the Heat Deflector to the Head using 3 Pan Head Screws M5x10mm, then tighten all the screws securely. - Page 11 Install Wall Mounting Bracket Install the wall mounting bracket to the wall with appropriate fixings for the material to be attached (Masonry, wood, metal etc.), using 6 appropriate fasteners (not included), then tighten all the screws securely. Install Heater Install the Heater to the Wall Mounting Bracket using 1 Pin Φ6*150mm with 1 R Cotter Pin, using 1 Bolt M6*150mm with 1 Plan Washer M6 and 1 Wing Nut M6.
-
Page 12: Use And Care Instruction
USE AND CARE INSTRUCTIONS LP Gas Model only: Natural Gas Model only: Connecting Natural Gas To Your Heater Connect Regulator with Hose to your LP Gas Tank Connect the Swivel nut of the 12' Natural Gas Hose Turn Burner Valve to the OFF position. to the horizontal fitting of NG Regulator as shown Inspect the valve connection port and regulator as- in Fig.1. - Page 13 USE AND CARE INSTRUCTIONS Check For Gas Leaks GAS REQUIREMENTS Never test for leaks with an open flame. Prior to first TGH34WL(LPG) Model: use, at the beginning of each season, or every time your LP Gas Cylinder is changed, you must check for gas This appliance is for use with a LP Gas.
-
Page 14: Lighting Instruction
LIGHTING INSTRUCTIONS Heater Lighting Instructions Before each use, check all hoses for cracks, nicks, cuts, burns or abrasions. If a hose is damaged in any way, do not use your heater before replacing the hose with an authorized part from the Parts List. Also make sure all gas supply connections are securely tightened. -
Page 15: Troubleshooting
TROUBLE SHOOTING Fault Causes Remedy (a) Air in gas line Purge gas line (b) Blockage in gas line Trace back and clear Pilot or main burner will not light (c) Igniter not sparking Repair lead, electrode, piezo or replace battery (d) Cylinder turned off Turn on (e) Cylinder empty... -
Page 16: Warranty Terms
WARRANTY TERMS Thermofilm warrants to the original owner that HEATSTRIP products will be free from defects in materials and workmanship for a period of 24 months from the date of purchase in accordance with the following warranty terms and conditions.
