Summary of Contents for Comica CVM.SIG.LAV V05 UC
- Page 1 CVM.SIG.LAV V05 Multi-functional Single Lavalier Microphone For USB-C For USB-C Smartphone Computer User Manual...
- Page 3 Foreword Thanks for purchasing Comica Multi-functional Single Lavalier Microphone (For Devices with USB-C Interface). To ensure bring you a good using experience, please read this manual book carefully before using and correctly install and operate. Notice The product may not be compatible with part of the device in Default...
-
Page 4: Packing List
Packing List Body of Microphone Back Clip Carry Case User Manual Warranty Card... - Page 5 Components Microphone USB-C Audio Output Cable Monitoring Jack Work Indicator Light Capsule Gain Control Wheel Power/Ordinary Recording/Low Cut Recording Switch Back Clip Battery Tray...
-
Page 6: Installation And Use
Installation and Use 1. Switch to Ordinary Recording/Low Cut Recording Mode, the indicator light turns green Switch to Ordinary Recording/Low Cut Recording Mode The indicator light turns green... - Page 7 2. Insert the USB-C output connector into the devices with USB-C input interface and use the recording system for recording...
-
Page 8: Function And Usage
Function and Usage 1. Gain Control Wheel During the usage, the gain control wheel can adjust the output sensitivity of microphone Gain Control Wheel 2. 3.5mm Monitoring Jack You can monitor the recording status through the 3.5mm monitoring jack 3. Power/Ordinary Recording/Low Cut Recording Switch You can adjust the Ordinary Recording Mode and Low Cut Recording Mode after turn on the device or choose to turn o the device Switch to di erent Modes as your require... -
Page 9: Polar Pattern
Specification Polar Pattern +5.0 -2.0 -2.0 -4.0 -6.0 -8.0 -10.0 -10.0 -12.0 -14.0 -16.0 -18.0 -20.0 -20.0 -22.0 -24.0 -25.0 dB rel. 1V/Pa Frequency: 500 Hz : 1000 Hz : 4000 Hz : Frequency Response 20Hz 1000 10 000 20 000... -
Page 10: Technical Parameters
Technical Parameters Polar Pattern Omni-directional Sensitivity -35dB ±2dB Gain Range Maximum Increase +10dB Frequency Response 60Hz - 18kHz >65dB Max SPL 100dB Battery CR2032 3V Working Temperature 0℃ ~ +50℃ Storage Temperature -20℃ ~ +60℃... - Page 11 CVM.SIG.LAV V05 多功能单领夹式麦克风 USB-C接口手机 USB-C接口电脑 用户使用手册...
- Page 12 前 言 感谢您购买科唛/Comica SIG.LAV V05(UC)多功能单领夹式麦克风 (USB-C接口设备专用)。 为保证产品的顺畅使用，请在使用前严格阅读本说明书，并正确 组装及操作。 注意事项 本产品在少部分设备的默认视频模式下会出现不兼容情况（此时建 议使用第三方视频软件） 使用过程中，请将手机设置为飞行模式，以避免信号干扰 请勿将本设备放置在热源或干扰源附近使用，如散热器、烤箱、热 点或其它无线设备旁边WIFI 本产品属于高精密仪器类产品，请避免使用时掉落、碰撞或重击 请勿在下雨或潮湿环境环境中使用，否则会有短路的危险...
- Page 13 产品主要功能 . 专用于USB-C接口设备 . 实时监听 . 低切功能 . 超强屏蔽、抗噪咪头 . 无级增益可调 . LED工作指示灯 包装清单 麦克风主体 背夹 便携袋 说明书 保修卡...
- Page 14 部件介绍及说明 麦克风 USB-C音频输出线 监听孔 工作指示灯 咪头 增益调节拨盘 电源/普通录制/低切录制开关 背夹 电池仓...
- Page 15 安装与使用 1.将开关拨至普通录制或低切录制模式，指示灯亮绿灯 拨至普通录制或低切录制开关 指示灯亮绿灯...
- Page 16 ２.把USB-C输出接头插入到设备的USB-C输入接口，打开设备的录制软 件，即可以进行录制...
- Page 17 功能与使用方法 1. 增益调节拨盘 使用过程中，增益调节拨盘可以调节麦克风输出灵敏度 增益调节拨盘 ２. 3.5mm监听孔 通过监听孔，可以实时了解录音情况 ３. 电源/普通录制/低切录制开关 拨动功能开关，可根据需求切换至关闭状态，或者开启状态下 的普通录制、低切录制模式 根据需求拨动至任一功能模式...
- Page 18 技术规格 指向图 +5.0 -2.0 -2.0 -4.0 -6.0 -8.0 -10.0 -10. 0 -12.0 -14.0 -16.0 -18.0 -20.0 -20. 0 -22.0 -24.0 -25.0 dB rel. 1V/Pa Frequency: 500 Hz : 1000 Hz : 4000 Hz : 频响图 20Hz 1000 10 000 20 000...
- Page 19 性能参数 指向性 全指向 咪头灵敏度 -35dB ±2dB 增益调节 最大增加+10dB 频响 60Hz - 18kHz 信噪比 >65dB 最大声压级 100dB 电池 CR2032 3V 工作温度 0℃ ~ +50℃ 储存温度 -20℃ ~ +60℃...
