Extreme Max Boat Lift Boss User Manual

Before installation, read and understand all instructions and warnings.
For installation, refer to installation instructions. Installation requires lift-specific installation kit.
All 120 Volt units MUST have electrical ground fault interrupter protection.
Important
• Read all instructions and warnings prior to installation and use.
• For use by adults over age 18.
• Wait for the motor to come to a complete stop before changing directions.
• Do not lift anything other than your boat.
• Put one of the two keys on a floating key chain and the spare key in a safe place.
• Original Generation 5 units contained a red connector to connect the electronics box to the motor. A replacement gray
connector will be included with all replacement units.
Warning:
• Hazardous voltage. Contact may cause electrical shock and injury. Disconnect before servicing.
• Misuse of this product can result in bodily injury, death, or property damage.
• Do not overload the capacity of the lift or drive system. When lifting, do not let the cradle or pulleys make contact with
the lift frame. Serious injury or dmage could occur.
• When lowering the lift, go down just far enough so the boat will come off of the lift. Running the system too long in
the down cycle will wind the cable backwards and lift the boat, which could cause serious injury or damge.
• To prevent serious personal injuries or death, do not allow children, swimmers or pets on or near the boat lift while
it is in operation as they may become caught under the boat and suffer pinch, amputation or other serious injuries.
• In the event of unintentional or erratic operation permanently unplug unit from power source to disable the system
and contact the Extreme Max service department at 651-357-1862.
• 120 Volt Boat Lift Boss:
o 120 Volt models must only be used on an electrical current equipped with a Ground Fault Circuit
Interrupter (GFCI).
o Supply circuits must be installed to all applicable electrical codes.
o All necessary electrical work should be completed by a licensed electrician.
o Boat Lift Boss unit must be connected to the power source using a marine-rated, 3-prong grounded
cord. The cord should be regularly inspected to ensure a good working condition.
o Improper wiring or lack of a properly installed Ground Fault Circuit Interrupter (GFCI) poses a high
risk of injury or death.
• 12/24 Volt Boat Lift Boss:
o 12/24 Volt models should be paired with marine-grade, deep cycle batteries. Common sizes include
Group 24 and Group 27 batteries.
o Never connect the longer lead (Red) to the motor lead (Gray). The longer lead always goes to the battery.
Caution:
The recessed pigtail connector at the bottom of the Boat Lift Boss Unit allows for a pendant controller option to be
added at any time. Do not tamper with or remove the protective cap unless you are adding the pendant controller
option.
• To order a pendant controller, contact Boat Lift Boss or your local stocking dealer.
120 Volt Boat Lift Boss:
• If the unit is to be left unattended, disconnect the unit from the power source to prevent damage from
lightning and electrical surges.
12/24 Volt Boat Lift Boss:
• If the unit is to be left unattended, disconnect the unit from the power source or press the Power
button to the "Off" setting to prevent damage. The Power button light is off when the unit does not
have power.
• Remote Control Models - Wireless and Handheld – (If applicable)
• Do not attempt to use the key switch and the remote control at the same time.
• Prevent property damage by removing the key from the control box before using the remote control.
If you have any questions regarding this product and its safe use, or if there are any missing or damaged parts, DO NOT return Boat Lift Boss
Call the Boat Lift Boss
Boat Lift Boss™ User Guide
Direct Drive - Generation 5
IMPORTANT INFORMATION
Service Department at: 651-357-1862 or e-mail - boatliftboss@extrememax.com
™
1
to the retailer.
™
3754ex0223
