User Information 1.1 General These operating instructions are part of the • Belt Grinding Machines SM-100/-100W, • Lamellar Grinding Machine SM-90 with the serial numbers indicated on the type plates (the type plate is located on the back of the machine).
User Information 1.2.2 Lists Lists without a particular order that have to be followed are shown as a list with bullet points or indent markings: • Property A – Detail 1 – Detail 2 • Property B 1.2.3 Courses of action The courses of action to be taken to avoid dangers or the required further procedure are marked with an arrow or indent markings: Procedure 1...
5. Before returning the product, wait for the specialist dealer's reply in order to initiate the necessary steps. Friedr. Dick GmbH & Co. KG does not pay any transport costs for returns that have not been explicitly approved.
Environmental Protection Environmental Protection NOTE DISPOSAL Used machines, replacement parts and packaging are made of recyclable materials. The above materials must be disposed of (properly and in an environmentally friendly manner) on your own responsibility and in accordance with the legal regulations applicable in the relevant countries.
Safety Safety 4.1 Meaning of the warnings 4.1.1 Marking of risks of injury In these operating instructions, signal words such as DANGER, WARNING or ATTENTION indicate the gradation of a possible risk of injury. DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
Safety 4.1.4 Symbols for the safety instructions Important or particularly useful information is highlighted using symbols so that it is readily recognised: WARNING – indicates a warning, which must always be noted and followed. INSTRUCTION – indicates instructions, which must be complied with for safety reasons.
• The machines SM-90 and SM-100/-100W are designed for commercial use only and are not intended for mobile use. • The SM-90 and SM-100/-100W machines can be used for the hand-guided dry grinding (sharpening) and polishing of cleaned knives and hoof knives.
Page 12
Safety WARNING RISK OF FIRE IN UNSUITABLE ENVIRONMENTS Moisture or water can cause a short circuit or electric shock. Flying sparks can cause flammable liquids and gases to ignite and lead to burns. The machine may not be exposed to rain or salt water, ...
Safety 4.4 Information signs on the machines Figure 1 – Information on the machines [1-1] Wear personal protective equipment (hearing protection, safety goggles, protective gloves) when working with the machine [1-2] Danger! Electric shock [1-3] Observe the type plate [1-4] Remove the mains plug from the socket [1-5] Read the operating instructions before starting up...
Safety 4.5 Covers WARNING RISK OF INJURY DUE TO MISSING COVERS If the machine is operated without covers and/or protective plates, there is a risk of injury on the abrasive or the material to be ground. Do not operate the machine until all covers and protective ...
Design and function Design and function 5.1 Technical data Motor and electrical equipment 1~230 V: SM-100/-100W SM-90 Power 0.5 kW 0.37 kW Voltage 1~230 V 1~230 V Current intensity 2.1 A 1.7 A Frequency 50 Hz 50 Hz Degree of protection...
Page 16
Height 330 mm 245 mm Weight 14.7 kg 13.1 kg applies for SM-100 with 20° angle of attack of grinding wheel Emissions sound pressure level: Emissions sound pressure level L 76 dB (A) Uncertainty K 3 dB (A) Emissions sound pressure level L...
Design and function 5.2 Design of belt grinding machines SM-100/-100W and lamellar grinding machine SM-90 Figure 2 – Design of machines [2-1] Grinding arm SM-100/-100W [2-2] Grinding belt SM-100/-100W [2-3] Direction of rotation of grinding belt [2-4] Drive motor [2-5]...
Design and function 5.3 Function The machines each consist of two function groups. Belt grinding machines SM-100/-100W The belt grinding machine consists of the grinding arm [2-1] with the grinding belt [2-2] and the polishing station [2-8] with the polishing wheel [2-11].
Putting the Machine into Operation Putting the Machine into Operation 6.1 Installing the machine WARNING RISK OF INJURY IN THE EVENT OF SLIPPING, FALLING OR TILTING MACHINE A slipping, falling or tilting machine can fall on hands or feet and cause serious injury.
Putting the Machine into Operation 6.2 Installing the machines Figure 4 – Installation [4-1] Mounting holes The machines are firmly mounted to the surface with screws through the mounting holes [4-1] (ø 10 mm). Operating Instructions SM-90/-100/-100W...
Putting the Machine into Operation the machine Adjusting WARNING RISK OF INJURY DUE TO ROTATING MACHINE PARTS If the machine is accidentally switched on during adjustment work, there is a risk of injury due to rotating machine parts. Disconnect the mains plug before carrying out any adjust- ...
Putting the Machine into Operation 6.3.2 Adjusting the grinding arm angle (SM-100/-100W) The angle of the grinding arm can be adjusted before working with the machine. To adjust, proceed as follows: [6-1] Adjusting screw Figure 6 – Adjusting the grinding arm angle 1.
[7-1], but do not tighten them yet. 3. Swing the support foot downwards (see arrow on right-side drawing), until the retainer sits on the surface. 4. Tighten the two screws [7-1]. 6.5 Adjusting the belt run (SM-100/-100W) ATTENTION DAMAGE CAUSED BY GRINDING BELT RUNNING ASKEW A belt that runs askew will damage the housing.
Putting the Machine into Operation 6.7 Switching on the grinding and honing machine WARNING RISK OF INJURY DUE TO DAMAGED OR INCORRECTLY MOUNTED MACHINE PARTS Using the machine with damaged electric parts or power cables can cause injuries due to electric shocks or malfunctions. Dam- aged grinding belts or flaps can be flung away.
Page 26
Wear suitable protective gloves. Switch on the machine as follows: 1. Check the belt run (SM-100/-100W only – see 6.5 Adjusting the belt run (SM-100/-100W)) 2. Insert the plug into the socket. 3. Press the green button [9-2] at the switch.
Putting the Machine into Operation 6.8 Switching off the machine 1. Press the red button [9-1] at the switch. 2. Wait until the grinding belt, the lamellar grinding wheel and the polishing wheel come to a standstill. DANGER RISK OF ELECTRIC SHOCK If the plug is removed from the socket by pulling the power ca- ble, the connection between the plug and cable can be damaged and is therefore a substantial source of danger.
Operation Operation ATTENTION DAMAGE TO ADHESIVES Dirty cutting tools can irreparably damage the grinding belt, lamellar wheel and polishing wheel. Only machine clean cutting tools. CAUTION RISK OF BURNS DUE TO HOT SURFACES The surfaces can heat with long-term use. This can cause burns and damage the machine.
Machine the cutting tool with very little pressure on the grinding belt. After several grinding passes, cool down the cutting tool in a water bath. 7.1.1 Grinding cutting tools (SM-100/-100W) Grinding zones [10-1] Grinding with underlay for straight grinding [10-2]...
Page 30
Operation [12-1] Cutting tool blade [12-2] Positioning angle for the cutting tool blade Figure 12 – Grinding a cutting tool 1. Clean the cutting tool before use. 2. Position the cutting tool on the machine so that the cutting edge [11-1] points in the direction of rotation of the grinding belt [11-2].
Operation 7.1.2 Grinding cutting tools (SM-90) [13-1] Cutting tool blade [13-2] Direction of rotation of the lamellar grinding wheel [13-3] Right-angled alignment of the cutting tool with the lamellar grinding wheel Figure 13 – Grinding a cutting tool [14-1] Cutting tool blade [14-2] Positioning angle for the cutting tool blade...
Operation 7.1.3 Polishing cutting tools (SM-90/-100) Figure 15 – Polishing a cutting tool [15-1] Positioning angle slanted relative to the running direction (approx. 30°–60°) [15-2] Positioning angle to the polishing wheel 1. Hold the polishing compound against the running polishing wheel until the surface is covered.
Operation 7.2 Machining hoof knives 7.2.1 Grinding hoof knives (SM-100W) [16-1] Narrow grinding belt [16-2] Right hoof knife [16-3] Groove of hoof knife Figure 16 – Grinding a hoof knife 1. Clean the hoof knife before use. 2. Position the hoof knife on the machine so that the cutting edge points in the direction of rotation of the grinding belt [16-1].
Operation 7.2.2 Polishing hoof knives (SM-100W) [17-1] Polishing wheel [17-2] Right hoof knife [17-3] Groove of hoof knife Figure 17 – Polishing a hoof knife 1. Hold the polishing compound against the running polishing wheel [17-1] until the surface is covered. 2.
maintenance or repair work. Exclusively use original spare parts from Friedr. Dick GmbH & Co. KG. WARNING RISK OF INJURIES DUE TO IMPROPER REPAIR WORK Improper repairs may limit or alter the functioning and result in electric shock or serious injury.
Servicing and Maintenance 8.2 Changing the grinding belt (SM-100/-100W) Change the grinding belt as soon as it has become blunt (interval approx. 30–50 grinding operations). To replace, proceed as follows: [18-1] Right-hand side panel [18-2] Fastening screws Figure 18 – Grinding arm...
Servicing and Maintenance 8.3 Changing the lamellar grinding wheel (SM-90) Change the lamellar grinding wheel as soon as its diameter has become smaller than that of the working area. To replace, proceed as follows: [20-1] Lamellar grinding wheel [20-2] [20-3] Fastening screws [20-4] Lock nut...
Servicing and Maintenance 8.4 Changing the polishing wheel The polishing wheel [21-5] must be changed if it is worn to below the work- ing area [21-6]. To replace, proceed as follows: Figure 21 – Changing the polishing wheel [21-1] Fastening screws for lid [21-2] [21-3] Mounting nut...
Spare parts Spare parts A spare parts drawing and a spare parts list are available at www.dick.de. CAUTION RISK OF INJURY DUE TO WRONG SPARE PARTS The use of parts other than original spare parts poses an unpre- dictable risk that may result in injuries.
• EN IEC 61000-3-2:2019, • EN 61000-3-3:2013 + A1:2019, • EN IEC 63000:2018, • EN 55014-1:2017, • EN 55014-2:2015. The person authorised to compile technical documents at Friedr. Dick GmbH & Co. KG is Mr Steffen Uebele, Managing Director. Operating Instructions SM-90/-100/-100W...
