WARNING: This symbol means WARNING ! BE VIGILANT ! YOUR SAFETY IS AT RISK. The message
that follows the symbol contains important safety information. Read it carefully. Be sure you understand
!
the possible risks of injury or even death.
To avoid all risks, always follow the safety notes con-
tained in this section and throughout this manual.
Put the warning tag shown below on the key for the
keyswitch when servicing or repairing the machine.
One warning tag is supplied with each machine.
Additional tags, Part Number 321-4614, are available
from your service parts supplier.
WARNING: Read the Operator's Manual
carefully and make sure you understand how
!
to operate the controls correctly.
WARNING: Never operate the machine and
attachment controls unless you are seated in
the operator's seat. If you are not in the
!
operator's seat, you run the risk of serious
injury.
WARNING: The machine is built to carry the
operator only. Do not allow passengers to
!
ride on the machine.
Cre 7-56942GB
https://truckmanualshub.com/
SAFETY
PDG0328
WARNING : Prior to starting up the engine
read the safety messages contained in the
operator's manual carefully. Read all safety
stickers on the machine. Have people move
back from the machine. Learn how to use the
controls before starting up the machine. It is
!
your responsibility to follow the manufacturer's
instructions on how to operate and maintain
the machine. It is your responsibility to follow
applicable rules and regulations. Service and
Operator's Manuals are available from your
J.I. Case Dealer.
WARNING: If you wear loose clothing or if
you omit to use safety equipment for your
work, you risk injury. Always wear clothes
that do not risk getting caught in the
!
machine. Other safety equipment may be
necessary, in particular : helmets, safety
shoes, ear plugs, safety glasses, protection
mask, thick gloves and reflecting clothes.
WARNING: When working close to the fan
with the engine running, avoid wearing loose
!
clothing and operate with extreme caution.
WARNING: When checking the hydraulic cir-
cuits, follow procedures to the letter. DO
!
NOT CHANGE procedures.
1001-3
Issued 11-99

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1188 and is the answer not in the manual?

Questions and answers

Summary of Contents for Case 1188

  • Page 1 It is your responsibility to follow applicable rules and regulations. Service and Operator’s Manuals are available from your J.I. Case Dealer. WARNING: If you wear loose clothing or if you omit to use safety equipment for your work, you risk injury. Always wear clothes that do not risk getting caught in the machine.
  • Page 2: Torque Wrenches

    https://truckmanualshub.com/ 1001-7 CORRECT USE OF TORQUE WRENCHES TORQUE Adjusting lever Setting pointer WRENCHES Leverage point handle Manipulator Extension SJ214, for doubling 1/2” square insert capacity of S203 wrenches Open-ended wrench PDG0315 CORRECT USE a - Hold the wrench by the handle provided.
  • Page 3 https://truckmanualshub.com/ 1001-11 PLASTIC PLUG AND CAP REFERENCE CHART Dia. x pas Part number Dia. x pas Part number Tapped orifices and connectors with tighten- ing nuts = screw-type plugs M10 x 1.5 F3237416 M20 x 1.5 L3237421 M12 x 1.5 G3237417 M22 x 1.5 M3237422...
  • Page 4: Fluids And Lubricants

    This yellow fluid is compatible with standard fluid. If adopted, it is advisable to drain the circuit completely. Fluid type ISO VG 46 CASE reference: CASYNTH 46 This grade of fluid must be in conformity with CASE France specification P9903203B Cre 7-79021GB Issued 11-99...
  • Page 5: Shock Absorbers

    https://truckmanualshub.com/ 1002-27 1188LC model 1188CK model Sprocket Type..................D60 ..............D60 Weight ................61.60 kg .............. 61.60 kg Number of teeth (per sprocket)..........21 ................ 21 Retaining screw torque setting ......... 500 Nm ............... 500 Nm PDG0385 Original dimension A................664.6 mm ............664.6 mm B................
  • Page 6 https://truckmanualshub.com/ 1002-9 TRANSPORTATION OVERALL DIMENSIONS PDH0126 NOTE: For top of cab to ground, see "Overall dimensions". P2A Version P2AL and P2A+2A Versions Boom Dipper Boom Dipper 1.70 m 3.00 9.15 1.70 m 3.45 9.20 2.20 m 3.15 8.90 2.20 m 3.70 8.95 4.80 m...
  • Page 7 https://truckmanualshub.com/ 1002-16 Tools NOTE: The selection of bucket capacity depends on the density of the material (See "Density of various spoils and materials" in the operator’s manual) and the attachment configuration as well as the compactness and structure of the ground. Earthmoving buckets Width CECE capacity...
  • Page 8 https://truckmanualshub.com/ 1002-27 Hydraulic reservoir Weight of empty reservoir..........................215 kg Reservoir capacity ..............................180 L Total system capacity ............................288 L Water radiator/oil cooler Empty weight ..............................51 kg Capacity (water) ..............................6 L Capacity (oil)................................2.3 L Radiator cap pressure ............................1.03 bar Attachment and swing control block (control lever) Weight ................................
  • Page 9 https://truckmanualshub.com/ 4001-9 INSTRUMENT PANEL WIRING INSTRUMENT PANEL (FRONT FACE) PDH0235 7- way connector : minimum pilot pressure red warning lamp, hydraulic oil temperature indicator, battery- charge red warning lamp, audible warning cut- out push button, engine oil pressure red warning lamp, alarm orange warning lamp, stop alarm red warning lamp.
  • Page 10 https://truckmanualshub.com/ 4001-19 WORKING LIGHTS ROTATING LIGHT BLOWER HEATER AIR FUEL HEATING WINDSHIELD WIPER WINDSHIELD WASHER CIGARETTE LIGHTER (OPTIONAL) CONDITIONING DEVICE UPPERSTRUCTURE ATTACHMENT PDH0226 Lep 7-57590GB Issued 09-94...
  • Page 11 https://truckmanualshub.com/ 4001-16 ELECTRICAL SCHEMATIC (PLATE 2) ELECTRICAL CABINET FLOOR B25 Threshold detector (788) Hourmeter Fuse, 30 A, starter motor solenoid, thermostart P10 Instrument panel Fuse, 5 A, starter key switch H30 Cold start assistance switch lighting (optional) Fuse, 7.5 A, instrument panel, hourmeter Key switch F27 Fuse, 5 A, remote controlled or articulated Working light switch...
  • Page 12 https://truckmanualshub.com/ 4001-35 ENGINE MODULE AND UPPERSTRUCTURE WIRING (OPTIONAL) ELECTRICAL CABINET 1 Connecting strip 2 Air conditioner See page 6 UPPERSTRUCTURE B23 Overload indicator (optional) B56 Boom raising range limitation detector (optional) R50 Fuel heater (optional) Adjustable or articulated boom extending electro-valve (optional) Adjustable or articulated boom retracting electro-valve (optional) Y50 Adjustable boom raising height limiter solenoid valve (optional) Y52 Quick coupler solenoid valve (optional)
  • Page 13 https://truckmanualshub.com/ 4001-24 ELECTRICAL SCHEMATIC (PLATE 7) ELECTRICAL CABINET SC1 Direction indicator (commodo), main beam and dip switch, side lights and headlight flasher switch F15 Fuse 15A, main beam headlights F16 Fuse 5A, stop lights FLOOR F17 Fuse 5A, LH stop light B53 Steering pressure switch F18 Fuse 5A, RH front side light B52 Pressure switch for minimum braking pressure...
  • Page 14 https://truckmanualshub.com/ 4001-5 CM99J047 Cre 7-26540GB Issued 11-99...
  • Page 15 https://truckmanualshub.com/ 4001-18 ELECTRICAL SCHEMATIC (PLATE 3) INSTRUMENT PANEL FLOOR P10 Instrument panel B50 Parking brake pressure switch H32 Overload indicator switch lighting (optional) B52 Pressure switch for minimum braking pressure S21 Overload indicator switch (optional) B53 Steering pressure switch E15 Rear LH side light ELECTRICAL CABINET Fuse, 7.5 A, instrument panel, hourmeter UPPERSTRUCTURE...
