ILT Muses of Light DeSisti EUTERPE Instruction Manual

540w vari-white from 2.700 to 6.500 k - enhanced cri 95 white light, with adjustable correlated colour temperature
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ILT ITALY srl
Via Cancelliera, 10/a
00041 Albano Laziale (Rome) Italy
tel. +39 06-902901 fax +39 06-90231051
www.desisti.it
EUTERPE
540W Vari-White from 2.700 to 6.500 °K - Enhanced CRI > 95
White light, with Adjustable Correlated Colour Temperature
INSTRUCTION MANUAL
MANUFACTURER
ILT Italy S.r.l.
Via Cancelliera # 10a, 00041 Albano Laziale (Rome- Italy).
Tel. +39/06/902901 Fax. +39/06/90231051
www.desisti.itE-mail:
desisti@desisti.it
This Manual is applicable to the De Sisti – Storaro The Muses of Light - EUTERPE
Revised on March 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Muses of Light DeSisti EUTERPE and is the answer not in the manual?

Questions and answers

Related Manuals for ILT Muses of Light DeSisti EUTERPE

Summary of Contents for ILT Muses of Light DeSisti EUTERPE

  • Page 1 ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it EUTERPE 540W Vari-White from 2.700 to 6.500 °K - Enhanced CRI > 95 White light, with Adjustable Correlated Colour Temperature INSTRUCTION MANUAL MANUFACTURER ILT Italy S.r.l.
  • Page 2 ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it 1. INTRODUCTION Congratulations on your purchase of EUTERPE Vari White lighting fixture. EUTERPE is a high power, highly efficient spotlight using DE SISTI modular PCB boards system with a total of 740 LEDs combined with 185 Wide Flood lenses.

  • Page 3: Safety Instructions

    ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it 3. CHARACTERISTICS AND PERFORMANCE DATA DESCRIPTION VALUE DESCRIPTION VALUE LED Power 540 W Protection Type IP23 – rain protected 600W @ 230V | 600W @120V...

  • Page 4: Working Conditions

    ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it Electrical connections: IMPORTANT The cores in this mains lead are colored in accordance with the following code: Europe America Ground Green & yellow Green or green &...

  • Page 5: Installation Instructions

    ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it WARNING : - DO NOT MOUNT THE LUMINAIRE ON A NORMALLY FLAMMABLE SURFACE. - USE OF SANDBAGS AND TIE-ROD/PUSH-ROD IS MANDATORY (EXTERNAL USE).

  • Page 6: Local Menu

    ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it E. Stand Alone operation: Using the navigation buttons and display readout ( refer to the “Local Menu” chapter )navigate to Manual and set the desired intensity (for additional operations see “Local Menu” chapter) DMX operation: Connect DMX cable.
  • Page 7 ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it Knob It allow to regulate both DIMMING and CCT Variation. Pushing it the display will switch from DIMMING to CCT CONTROL By rotating it clockwise the DIMMING increase from 0% to 100% while the CCT Changes from 2.750°K up to 6.900 °K.

  • Page 8: Micro Usb Port

    ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it Button SET 1 When in Storaro Mode it will set the CCT to 5600K. In De Sisti mode with long press it will memorize the cur-...
  • Page 9 ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it The following are the BASIC FUNCTIONS and COMMANDS that are provided on the LOCAL MENU of the LED DEVICE. The unit is provided with a USER MENU accessible instantly on the product.

  • Page 10: Basic Functions

    ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it Basic functions: DMX CHART Menu and settings The unit occupies 2 channels in 8bit mode an 3 channels in 16bit mode .
  • Page 11 ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it Change DMX address To change the unit DMX address navigate into the menu until you reach the voice “DMX Address” Push Button 2 to enter the menu voice and Button 3 and 4 to reach the desired address.
  • Page 12 ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it Storaro Mode: In this mode you can work as the Master prefers to work on the set. DMX channels will be only for dim- ming while CCT tuning it will be al- lowed only manually on the driver.
  • Page 13 ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it Backlight=On: The display light will be al- ways ON Backlight= Off: The display light will switch OFF after 10 seconds without any user command.
  • Page 14 ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it Change the Dimming Speed To change the Dimming Speed to change the device reaction while dimming with the possibil- ity to choose between Fast and...
  • Page 15 ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it Activate the wireless DMX module To switch on or off the Wire- less Module, navigate into the menu until you reach the voice “Wireless”.
  • Page 16 ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it CCT Tuning from 2700°K to 6500°K To set the dimming value rotate the encoder knob until you reach the desired CCT level.
  • Page 17 ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it The RF ON Green LED indicator will turn on and after few seconds also the LINK LED indicator will turn on. The unit will automatically pair with the nearest sender active.

  • Page 18: Firmware Upgrade

    ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it SET 1: 5600K SET 2: 4300K SET 3: 3200K The user then will be allowed to tune the CCT from the “preset value” and the related indicator LED will turn off once the CCT value will change from the preset.
  • Page 19 ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it Install the USB drivers en- tering the proper folder and launching the .exe inside it. Then enter the BOOT- LOADER folder and launch the exe Bootloader De Sisti Vx.x.
  • Page 20 ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it 8) Push the button “Erase-Program- Verify. 9) Software will start to erase the old firmware and up- load the new one, then will check the FW integrity.
  • Page 21 ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it 7. DIMENSIONS This Manual is applicable to the De Sisti – Storaro The Muses of Light - EUTERPE Revised on March 2021...

  • Page 22: Periodic Inspection & Maintenance

    ILT ITALY srl Via Cancelliera, 10/a 00041 Albano Laziale (Rome) Italy tel. +39 06-902901 fax +39 06-90231051 www.desisti.it 8. PERIODIC INSPECTION & MAINTENANCE This product requires very little routine maintenance, if any, but has special cleaning instructions: Disconnect fixture from power and allow it to cool for 10 min.
