ANALOG CAMERA
User Manual
HCF-8011RV

Advertisement

loading
Need help?

Need help?

Do you have a question about the HCF-8011RV and is the answer not in the manual?

Questions and answers

Related Manuals for Hanwha Vision HCF-8011RV

Summary of Contents for Hanwha Vision HCF-8011RV

  • Page 1 ANALOG CAMERA User Manual HCF-8011RV...
  • Page 2 Analog Camera User Manual Copyright ©2023 Co., Ltd. All rights reserved. Hanwha Vision Trademark Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Copyright of this document is reserved.
  • Page 3 Safety information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit.
  • Page 4 9. If this product fails to operate normally, contact the nearest service center. never disassemble or modify this product in any way. (Hanwha Vision is not liable for problems caused by unauthorized modifications or attempted repair.) 10.
  • Page 5 CAUTION This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 6 Important safety instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifiers) that produce heat.
  • Page 7 To Prevent damage which may caused by IR LED, don't stare at operating lamp. For below models only. HCF-8011RV Hanwha Vision cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products.

  • Page 8: Table Of Contents

    Contents OVERVIEW What's included Optional Accessories for Installation At a Glance INSTALLATION Before installation Installation CONNECTION Connecting to Monitor Connecting to Power CAMERA OPERATION Menu Configuration Camera setup TROUBLESHOOTING Troubleshooting 8_ contents...

  • Page 9: Overview

    Overview WHAT'S INCLUDED Please check if your camera and accessories are all included in the product package. (As for each sales country, accessories are not the same.) Camera Mounting Plate Quick Manual Installation Guide Sticker Machine Screws Torx L wrench English_9...
  • Page 10 Overview OPTIONAL ACCESSORIES FOR INSTALLATION You can purchase appropriate optional accessories available. Wall Mount Hanging Mount Pole Mount SBP-300WM1 SBP-300HM5 SBP-300PM Corner Mount Ceiling Mount SBP-300KM SBP-300CMW 10_ overview...
  • Page 11 AT A GLANCE Item Description Plate that fixes the camera when mounting it to the ceiling or attaching it to a separately Mount plate sold mount. Camera body Body part where the camera lens and connection terminals are included. Display the menu on the screen and move the cursor to four directions to confirm status Function Setup switch or after changing a selected item.

  • Page 12: Installation

    Installation BEFORE INSTALLATION Ensure you read out the following instructions before installing the camera: y It must be installed on the area (ceiling or wall) that can withstand 5 times the weight of the camera including the installation bracket. y Stuck-in or peeled-off cables can cause damage to the product or a fire. y For safety purposes, keep anyone else away from the installation site.
  • Page 13 Installation using the installation guide sticker 2-1. Attach the installation guide sticker on the desired location and then drill the holes for screws and cables. 2-2. Pull out the power and video cables through the cable hole and connect them with the cables on the camera.
  • Page 14 Installation 2-3. Fix the camera body using appropriate screws. When connecting cables from the side, first remove the wiring hole cover of the camera body. 14_ Installation...
  • Page 15 Installation with the mount plate (gang box) 3-1. Fix the camera body using appropriate screws. 3-2. Pull out the power and video cables through the cable hole and connect them with the cables on the camera. When installing the camera, arrange the cables so that they are not damaged or caught. English_15...
  • Page 16 Installation 3-3. Attach the camera body to the mount plate with the supplied machine screws. When connecting cables from the side, first remove the wiring hole cover of the camera body. 16_ Installation...
  • Page 17 4. Assemble the dome cover. Make sure to firmly tighten the fastening screws so that there is no water damage issue. TR20 English_17...

  • Page 18: Connection

    connection CONNECTING TO MONITOR Connect the Video OUT port on the rear panel of the camera to a ENCODER. ALARM NETWORK BACKUP POWER ENCODER Monitor y As the connecting method varies with the instruments, refer to the manual supplied with the instrument. y Only connect the cable when the power is turned off.
  • Page 19 CONNECTING TO POWER You can connect power as shown in the following figure. Power Input Terminal When the resistance value of copper wire is at [20°C(68°F)] Copper wire size (AWG) #24 (0.22 mm #22 (0.33 mm #20 (0.52 mm #18 (0.83 mm Resistance value(Ω/m) 0.078 0.050...

  • Page 20: Camera Operation

    camera operation MENU CONFIGURATION MAIN SETUP ◦ ◦ VIDEO FORMAT CVBS ◦ ◦ ◦ BASIC USER INDOOR PROFILE ◦ ◦ BACKLIGHT ◦ DAY/NIGHT SSDR ◦ ◦ ◦ ◦ ◦ OUTDOOR INDOOR WHITE BAL ◦ ◦ AWC ; SET MANUAL ◦ ◦...

  • Page 21: Camera Setup

    CAMERA SETUP Use the Function Setup switch within the camera. VIDEO FORMAT 1. From the Setup menu, select the MAIN SETUP <VIDEO FORMAT >.  0. VIDEO FORMAT 2. Select the VIDEO mode. 1. PROFILE BASIC y The video output can be selected 2.
  • Page 22 Camera operation y USER : Automatically configures the camera to your custom settings. 1) Select Custom for Simple Setup mode. 2) Configure the menu options to your custom settings. 3) The settings are automatically saved as Custom mode. 4) Profile user mode don't initialize when menu resets. 3.
  • Page 23 White Bal (White Balance) Use the White Balance function to adjust the screen color. 1. From the Setup menu, select the MAIN SETUP <White Bal>. 0. VIDEO FORMAT 2. Select the desired mode. 1. PROFILE BASIC Select one of the following 5 modes, ...
  • Page 24 Camera operation EXPOSURE 1. From the Setup menu, select the MAIN SETUP <EXPOSURE>. 0. VIDEO FORMAT 2. Select each item and set it properly. 1. PROFILE BASIC 2. SSDR y BRIGHTNESS : The brightness of the 3. WHITE BAL screen can be adjusted. ...
  • Page 25 BACKLIGHT The camera uses high performance DSP chips that are designed to clearly display the object and the background despite severe reverse light. 1. From the Setup menu, select the MAIN SETUP <BACKLIGHT>. 0. VIDEO FORMAT 2. Select the desired mode. 1.
  • Page 26 Camera operation At night, it only operates when the size of a highlight goes over the threshold in a dark environment. At night, HLC does not operate when it is overall too bright or dark. In daytime, HLC does not operate when it is too dark. y WDR When there are both bright and dark areas at the same time, this mode makes both areas distinctive.
  • Page 27 SPECIAL 1. From the Setup menu, select the <SPECIAL>. 2. Select each item and set it properly. y DISPLAY SPECIAL Select <DISPLAY>. ❶  1. DISPLAY Set the following items. ❷ 2. IMAGE ADJ 3. DAY/NIGHT AUTO 4. RETURN - CAM TITLE CAM TITLE ①...
  • Page 28 Camera operation y IMAGE ADJ Select <IMAGE ADJ>. ❶ IMAGE ADJ Set the following items. ❷  1. GAMMA 0.45 2. PED LEVEL IIIII IIIIIIIIIIIIII - GAMMA : The setting range is 0.20 3. COLOR GAIN IIIIIIIIII IIIIIIIII ~ 1.0. The closer to 1.0 the 4.
  • Page 29 y DAY/NIGHT: You can display pictures in color or in black and white. Select <DAY/NIGHT>. ➊ Select the desired mode. ➋ - AUTO : Switch to color mode DAY/NIGHT during the daytime and BURST  b/w at night or in low light. DURATION NORMAL y BURST : Activate or deactivate...
  • Page 30 Camera operation EXIT y SAVE : Save the current settings and exit the MAIN SETUP menu. y NOT SAVE : Do not save the current settings and exit the MAIN SETUP menu. y RESET : Revert camera to factory settings. 30_ camera operation...
  • Page 31 troubleshooting TROUBLESHOOTING If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an authorized technician. Problems Troubleshooting Nothing appears on the screen. y Check that the power cord and line connection between the camera and monitor are properly connected.
