- Page 1 TRIM LINE SCREEN ROOM 9672XX.009, 9672XX.216 Trim Line Screen Room Installation and Operation Manual . . . . . . . . . 2 Form No. 3317189.000 (French 3317190.000) 10/18 | ©2018 Dometic Corporation...
-
Page 2: Table Of Contents
Contents Trim Line Screen Room 1 Explanation of Symbols and Service Center & Dealer Locations Visit: www.dometic.com Safety Instructions Read these instructions carefully. These instructions This manual has safety information and instructions to MUST stay with this product. help you eliminate or reduce the risk of accidents and injuries. -
Page 3: Supplemental Directives
Trim Line Screen Room. HAZARD. Failure to obey the following warnings could result in death or serious Dometic recommends that the following tools and injury: materials be used while installing the Trim Line Screen •... -
Page 4: Intended Use
For guidance on how to install the Trim Line The manufacturer accepts no liability for damage in the Awning, consult the Dometic Trim Line Awning following cases: Installation and Operation Manual available on • Faulty assembly or connection www.dometic.com. -
Page 5: Install The Front Panels
Trim Line Screen Room Installation 4.3 Install the Front Panels Ensure the correct orientation of all panels prior to installation. The interior and exterior sides of all panels can be determined by locating the privacy panels; the privacy panel is always on the inside of the screen room. Install the front panels by completing the following steps: 1. -
Page 6: Attach The Rear Skirt
Installation Trim Line Screen Room 4.7 Secure the Screen Room to the NOTICE: If the camper does not have canvas covers to attach the side panels to, fold the side panel flaps Ground directly around the lifter mechanisms as shown in Figure 6. -
Page 7: Operation
5 Operation 10 Opening the Privacy Panels DANGER! CARBON MONOXIDE POISONING. The Dometic Trim Line Screen Room is designed to Do not operate any appliances (gas, combustion, expand the living space of campers, providing a place etc.) venting into the screen room enclosure with for dining, sleeping, or just relaxing. -
Page 8: Limited One-Year Warranty
LIMITED ONE-YEAR WARRANTY AVAILABLE AT WWW. DOMETIC.COM/WARRANTY. IF YOU HAVE QUESTIONS, OR TO OBTAIN A COPY OF THE LIMITED WARRANTY FREE OF CHARGE, CONTACT: DOMETIC CORPORATION CUSTOMER SUPPORT CENTER 1120 NORTH MAIN STREET ELKHART, INDIANA, USA 46514 1-800-544-4881 OPT 3... -
