LB6-20ILWCBW
Notice to Customer
Thank you very much for your purchasing our PATLITE
products.
● Request the installation and wiring be performed by
a professional contractor if construction work is
involved.
● If there are any questions concerning this product,
refer to the contact information at the end of this
document and contact your nearest PATLITE Sales
Representative.
To the Contractor
●Read this manual carefully prior to installation.
LB6-20ILWCNW
Multi-color Signal Tower with
TYPE
L B 6 - IL
General Instruction Manual
Installation
Operation
1
2
3
4
5
6
7
Troubleshooting
8
Specifications
9
Replacement Parts
10
Option Parts
11
Attach/detach
the Buzzer unit
12
Attach/detach
the Head cover
1
GA0009717̲01
Maintenance
ページ
2
3
4
5
7
8
16
17
19
20
21
24
Advertisement
Related Manuals for Patlite LB6-IL
Summary of Contents for Patlite LB6-IL
-
Page 1: Table Of Contents
LB6-20ILWCNW LB6-20ILWCBW Troubleshooting Specifications Notice to Customer Replacement Parts Thank you very much for your purchasing our PATLITE products. ● Request the installation and wiring be performed by Option Parts a professional contractor if construction work is involved. ● If there are any questions concerning this product,... -
Page 2: Read This First
Read this First Safety Precautions The safety precautions that should always be followed in order to prevent injury to user or other individuals as well as prevent damage to property are described below. ■ The level of injury or damage caused by ignoring these safety precautions and using the product improperly is categorized and described below. -
Page 3: Model Number Configuration
Model Number Configuration Model Specifications Installation With or without buzzer Body color Assembly Model 20Seg. / 20IL with Buzzer Off white IO-Link Control No Buzzer Direct Mount / M12Connector Example LB6-20ILWCBW ● 20Seg. / IO-Link Conterol ● Direct Mount / M12 Connector ● with Buzzer ● Off white... -
Page 4: Names And Dimensions
Names and Dimensions Unit：mm LB6-20ILWCBW LB6-20ILWCNW Buzzer Unit Head Cover 53.5 Outer top Outer top Outer lens Outer lens 315.5 IO-Link communication LED IO-Link communication LED Body Body Nameplate Nameplate Bracket Bracket Waterproof sheet Waterproof sheet M30 Nut M30 Nut M12 Connector M12 Connector Pin Configuration (5pin female) -
Page 5: Installation
Installation Caution ● This product is for indoor use only. ● Do not use the product with the Head cover or Buzzer unit removed. ● Do not apply excessive force when installing or removing the head cover and buzzer unit. Failure to do could result in damage to the unit. - Page 6 ① Check the mounting position of the product and the NPT pole. ② Turn the body in the counterclockwise direction and remove the Body from the bracket. ③ While holding part ‘A’, attach the Bracket to the NPT pole. Body Positioning indicators ...
-
Page 7: Wiring
Wiring Caution ● Turn off the power before wiring. There is a risk of short-circuiting and damage to the internal circuitry. ● Ensure the proper working voltage is used and that direct current or alternating current is properly applied. Any mistake in wiring may result in damage. ●... -
Page 8: How To Use
How to Use This product is IO-Link supported. Wire according to P.6 ”5 Wiring”. LED and buzzer can be controlled from the IO-Link master. By changing the “Operating Mode” setting, the unit can operate in the following modes. ・Simple Mode ・Level Mode ・Animation Mode In level mode, animation mode and user preferences, the LEDs are controlled segment by segment. - Page 9 The parameters used in each mode are listed in the table below. For common matters, see P.14 ” ■Matters common to all mode ”. Mode Simple Level Animation Parameter ◯ ◯ ◯ 2000: LED Intensity ◯ ◯ ◯ 2001: Buzzer Sound Level ◯...
- Page 10 ■ Parameter setting For parameters, download and use the IODDs on the Type LB6 page of the website (https://www.patlite.com). Also download and use the parameter sheet in the same way. ■ Simple Mode This mode allows control by setting the contents of the LED and the buzzer.
- Page 11 □Select User Color "Select User Color" allows you to select an arbitrary LED colour to be used in Simple mode. See P.14 "□About LED Color" for the color to be selected. □Tier Color "Tier Color" corresponds to the table below. LED Color Set Value Green...
- Page 12 ■ Level Mode In this mode, LED and buzzer contents are set by parameters and controlled by process data values. Refer to the table below for process data transmission. bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0 Buzzer Byte 0 User Preference Select Not used ON/OFF...
- Page 13 ■ Animation Mode In this mode, the LED and buzzer contents are set by parameters, and the level mode is displayed sequentially. Refer to the table below for process data transmission. bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0 Buzzer Animation Animation Byte 0...
- Page 14 ■ Matters common to all mode □LED Color The "LED Color" used in each mode corresponds to the table below. Color images may differ from actual colors due to screen conditions or printing conditions. Set value Color image Set value Color image ー...
- Page 15 □Buzzer Pattern "Buzzer Pattern" used in each mode corresponds to the table below. Pattern Set value Continuous Beep Sound Rapid Intermittent Beep Rapid Hi-Low Sweep Sound Continuous Beep Sound 500ms ON / 500ms OFF Rapid Intermittent Beep 500ms ON / 500ms OFF Rapid Hi-Low 500ms ON / 500ms OFF Sweep Sound 500ms ON / 500ms OFF □LED Intensity...
- Page 16 □Direction of Flow (Level Mode, Animation Mode) "Direction of Flow" sets the starting position of the lighting. Refer to the table below for the setting. Starting position Set value Starts lighting from segment 1 Starts lighting from segment 20 □Scope of Apperance (Level Mode, Animation Mode) Each segment lights up with the LED color/LED pattern set.
- Page 17 Troubleshooting Troubleshoot problems that occur by following the instructions in the table below. Problem Confirmation Remedy Please check " How to Use" (P.8) Is the processing data correct? before submitting your process data. Please check " How to Use" (P.8) Are the parameters correct? before set value.
- Page 18 Specifications General Specifications Product Name Multi-color Signal Tower with IO-Link Model LB6-20ILWCNW LB6-20ILWCBW Rated Voltage 24V DC Operating Voltage Range 18V - 30V DC Std. 200mA 250mA Max. 250mA 300mA Current Consmption At rated voltage, with IO-Link communication. All LED segments continuously illuminate in white. Dimming:100% Condition (Only LB6-20ILBW)Buzzer Sound "...
- Page 19 Buzzer Specifications No.1 No.2 Continuous beep sound / 3,378Hz No.3 Rapid intermittent beep / 3,378Hz Rapid Hi-Lo / 2,016Hz & 3,012Hz No.4 Sweep sound / 1,000Hz - 4,032Hz No.5 Buzzer Sound Continuous beep sound / 3,378Hz 500ms ON / 500ms OFF No.6 / Typical Frequency No.7...
- Page 20 Replacement Parts The following replacement parts for this product are available for customer to change or replace. Head Cover 60 W NPT Pole Bracket 60 O-Ring 60 Accessories O-Ring 60 1pcs M30 Nut 1pcs 1 pcs Waterproof sheet 60 1pcs...
- Page 21 Option Parts The optional parts for this product are listed below. (Top line: Part Name; Bottom: Model) Buzzer Unit LB6-BW （Unit：mm） External Diagram Model Number Configuration Model Body Color LB6 − B W Model Number 53.5 W ：Off-White Φ60 General Specifications Model LB6-B -20℃...
- Page 22 Attach/detach the Buzzer Unit Follow the instruction below when attaching and detaching the buzzer unit. Wa r ning ● Be sure that it is disconnected from the power source before working on it C a ut ion ● Do not apply excessive torque or strong shock to each unit or body. Failure to comply will result in damage or malfunction.
- Page 23 ＜Troubleshooting the Buzzer Unit Attachment＞ The Buzzer Unit is generally in the status shown in the diagram below after removal. Buzzer Unit Groove Positioning Mark Outer top Outer lens Buzzer Unit (Detached) Bottom View The rib inside of the Buzzer Unit fits into the groove when the Buzzer Unit has been removed from the product.
- Page 24 Use the procedure below if the Buzzer Unit does not attach properly. Turn the part inside the Buzzer Unit in the counter-clockwise direction. Turn until the rib fits into the groove, then attach the Buzzer Unit to the product. Turn this part in the counter-clockwise direction.
- Page 25 Atttach/detach the Head Cover Follow the instruction below when attaching and detaching the buzzer unit. Wa r ning ● Be sure that it is disconnected from the power source before working on it C a ut ion ● Do not apply excessive torque or strong shock to each unit or body. Failure to comply will result in damage or malfunction.
