Toshiba 14CS2R Service Manual page 20

Location
Parts No. Description
No.
RS02 24011471 CHIP, METAL FILM, 1/20W 470 OHM J
RS04 24011223 CHIP, METAL FILM, 1/20W 22K OHM J
RS06 24000445 CHIP JUMPER, 1608TYPE
RV02 24011750 CHIP, METAL FILM, 1/20W 75 OHM J
RV11 24011750 CHIP, METAL FILM, 1/20W 75 OHM J
RV12 24011181 CHIP, METAL FILM, 1/20W 180 OHM J
RV13 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
COILS & TRANSFORMERS
L101 23289929 COIL, PEAKING COIL 82MMH, TRF4820AU
L102 23238562 COIL, PEAKING, TRF4109AJ
L103 23238503 COIL, PEAKING, TRF4129AJ
L104 23238506 COIL, PEAKING, TRF4229AJ
L105 23238506 COIL, PEAKING, TRF4229AJ
L106 23238713 COIL, PEAKING, TRF4120AJ
L107 23238713 COIL, PEAKING, TRF4120AJ
L108 23238709 COIL, PEAKING, TRF4270AJ
L162 23289928 COIL, PEAKING COIL 68MMH, TRF4680AU
L301 23103249 CORE, FERRITE BEAD 3.5X4.5, TEM2011AO
L462 23231169 COIL, DEFLECTION YOKE, TDY314PY
L462C 23993623 COMPENSATOR, TC-L
L514 23289919 COIL, PEAKING, TRF4120AU
L661 23221129 CHOKE COIL, TRF9240AC
L662 23221129 CHOKE COIL, TRF9240AC
L864 23103249 CORE, FERRITE BEAD 3.5X4.5, TEM2011AO
L883 23103279 FILTER, FERRITR CHOKE 3.5X5X2,
TEM2014AO
L884 23248230 COIL, CHOKE, TLN3142AC
* L901 23200532 COIL, DG, TSB-2360AH
LA03 23103279 FILTER, FERRITR CHOKE 3.5X5X2,
TEM2014AO
LA04 23103279 FILTER, FERRITR CHOKE 3.5X5X2,
TEM2014AO
LA05 23289918 COIL, PEAKING, TRF4100AU
LC01 23238513 COIL, PEAKING, TRF4R22AJ
LC04 23289918 COIL, PEAKING, TRF4100AU
LZ02 23221129 CHOKE COIL, TRF9240AC
T401 23224983 TRANSFORMER, HORIZONTAL DRIVE,
TLN1039
* T461 23236768 TRANSFORMER, HORIZ OUTPUT
T801 23211761 COIL, LINE FILTER, TRF3148BF
* T862 23217635 TRANSFORMER, TPW3532AM
SEMICONDUCTORS
Q100 23009668 IC, P/N 2IN1 VCD MICRO, A8801CPCN4V63
Q101 23114611 TRANSISTOR, 2SC3357
Q103 23205006 TRANSISTOR, KTC4075Y
Q104 23205006 TRANSISTOR, KTC4075Y
Q108 70200984 IC, A/V SW 3IN1X1 SOP-8C, MM1113XFBE
Q109 23205081 TRANSISTOR, 2SA1980-Y(BU
Q112 23205006 TRANSISTOR, KTC4075Y
Q115 23205006 TRANSISTOR, KTC4075Y
Q116 23205005 TRANSISTOR, KTA2014Y
Q130 23205204 TRANSISTOR, NPN VEBO=25V,
KTC2875B-RTK
Q196 23205085 TRANSISTOR, 2SC5343-Y(BUL
Q301 23009352 IC, AN5522
Q301B 72471081 SCREW, 3X8MM
Q402 23114755 TRANSISTOR, 2SC2482FA-1
Q404 23314968 TRANSISTOR, 2SD2599(FA)
Q404B 72471082 SCREW, 3X10MM
Q421 23314141 TRANSISTOR, 2SC3852
Q422 23009843 IC, REGULATOR +5V 4%, S7805PI
Q422B 70391355 SCREW, BIND HEAD TAP-TITE B,
BITTB 3X8 SZN
Q430 23314980 TRANSISTOR, 2SD2549 P
Location
Parts No. Description
No.
Q431 23205209 TRANSISTOR, NPN R1=2.2K R2=47K,
SRC1205S (SOT-23)
Q610 23000867 IC, AN5274
Q610B 70391355 SCREW, BIND HEAD TAP-TITE B,
BITTB 3X8 SZN
Q612 23205005 TRANSISTOR, KTA2014Y
Q801 23009243 IC, POW SW.REG.IC VDS=650V,
PO=STR-W5753A
Q801B 70391355 SCREW, BIND HEAD TAP-TITE B,
BITTB 3X8 SZN
Q819 23205006 TRANSISTOR, KTC4075Y
Q840 23114733 TRANSISTOR, 2SC2655-Y
* Q862 23906937 IC, PHOTO COUPLER, ON3171-R
Q880 23205209 TRANSISTOR, NPN R1=2.2K R2=47K,
SRC1205S (SOT-23)
Q901 23205203 TRANSISTOR, NPN VCEO=300V, KTC3207
Q903 23205203 TRANSISTOR, NPN VCEO=300V, KTC3207
Q905 23205203 TRANSISTOR, NPN VCEO=300V, KTC3207
Q907 23205005 TRANSISTOR, KTA2014Y
Q908 23205202 TRANSISTOR, 2SC5344Y
QA02 23906923 IC, CAT24WC08P
QA51 23205006 TRANSISTOR, KTC4075Y
QA52 23205005 TRANSISTOR, KTA2014Y
QA53 23205005 TRANSISTOR, KTA2014Y
QA60 23205006 TRANSISTOR, KTC4075Y
QB30 23205006 TRANSISTOR, KTC4075Y
QB31 70129444 IC, PST994D
QB43 23205209 TRANSISTOR, NPN R1=2.2K R2=47K,
SRC1205S (SOT-23)
QB60 23205006 TRANSISTOR, KTC4075Y
QB61 23205006 TRANSISTOR, KTC4075Y
QV10 23205081 TRANSISTOR, 2SA1980-Y(BU
QV13 23000359 IC, MM1111XF
D101 23316411 DIODE, ZENER, HZT33-12
D150 23316231 DIODE, 1SS355
D224 23316231 DIODE, 1SS355
D301 23357372 DIODE, AXIAL, EU2JGF-41U2
D302 23357372 DIODE, AXIAL, EU2JGF-41U2
D303 23316794 DIODE, SC570ALFE2
D406 23357372 DIODE, AXIAL, EU2JGF-41U2
D408 23357372 DIODE, AXIAL, EU2JGF-41U2
D421 23118622 DIODE, ZENER, RD10ES B2
D431 23118622 DIODE, ZENER, RD10ES B2
D432 23316231 DIODE, 1SS355
D441 23118516 DIODE, ZENER, RD9.1ES B3
D472 23316231 DIODE, 1SS355
D612 23316231 DIODE, 1SS355
D622 23316231 DIODE, 1SS355
D801 23316796 DIODE, VRRM=600V IF=1A DO-41,
ERB12-06E
D802 23316796 DIODE, VRRM=600V IF=1A DO-41,
ERB12-06E
D803 23316796 DIODE, VRRM=600V IF=1A DO-41,
ERB12-06E
D804 23316796 DIODE, VRRM=600V IF=1A DO-41,
ERB12-06E
D818 23118507 DIODE, ZENER, RD13ESA B3
D840 23118529 DIODE, ZENER, RD5.6ES B2
D861 23118502 DIODE, ZENER, RD16ESA B2
D864 23357164 DIODE, D1NL20U
D873 23357341 DIODE, 1SS133
D874 23357341 DIODE, 1SS133
D876 23118529 DIODE, ZENER, RD5.6ES B2
D877 23118631 DIODE, ZENER, RD3.3ESA B2
D880 23118508 DIODE, ZENER, RD13ES B2
D883 23357372 DIODE, AXIAL, EU2JGF-41U2
D885 23357372 DIODE, AXIAL, EU2JGF-41U2
– 20 –
