Toshiba 14CS2R Service Manual page 18

Location
Parts No. Description
No.
C565 24109103 CERAMIC CHIP, 50V B 0.01UF K
C566 24794471 ELECTROLYTIC, 16V 470UF M
C567 24109103 CERAMIC CHIP, 50V B 0.01UF K
C606 24206229 ELECTROLYTIC, 50V 2.2UF M 7L 3A
C607 24206229 ELECTROLYTIC, 50V 2.2UF M 7L 3A
C608 24206229 ELECTROLYTIC, 50V 2.2UF M 7L 3A
C609 24764101 ELECTROLYTIC, 25V 100UF M
C610 24591473 PLASTIC FILM, 50V 0.047UF J
C611 24766100 ELECTROLYTIC, 50V 10UF M
C612 24206100 ELECTROLYTIC, 50V 10UF M 7L 3A
C613 24766100 ELECTROLYTIC, 50V 10UF M
C614 24591473 PLASTIC FILM, 50V 0.047UF J
C615 24763101 ELECTROLYTIC, 16V 100UF M
C616 24764471 ELECTROLYTIC, 25V 470UF M
C630 24764471 ELECTROLYTIC, 25V 470UF M
C631 24206478 ELECTROLYTIC, 50V 0.47UF M 7L 3A
C633 24591823 PLASTIC FILM, 50V 0.082UF J
C634 24591563 PLASTIC FILM, 50V 0.056UF J
C673 24109103 CERAMIC CHIP, 50V B 0.01UF K
C674 24109103 CERAMIC CHIP, 50V B 0.01UF K
* C801 24503507 PLASTIC FILM, AC275V 0.22UF K
C805 24092281 CERAMIC DISC, AC250V E 4700PF
C806 24092281 CERAMIC DISC, AC250V E 4700PF
C810 24086059 ELECTROLYTIC, 400V 270UF M 3D
* C813 24092555 CERAMIC DISC, AC250V E 1000PF M
* C814 24092555 CERAMIC DISC, AC250V E 1000PF M
C861 24214471 CERAMIC DISC, 500V B 470PF K
C864 24797221 ELECTROLYTIC, 50V 220UF M
C873 24092341 CERAMIC DISC, 2KV R 470PF K
C874 24591104 PLASTIC FILM, 50V 0.1UF J
C875 24109681 CERAMIC CHIP, 50V B 680PF K
C876 24109102 CERAMIC CHIP, 50V B 1000PF K
C877 24232103 CERAMIC DISC, 50V F 0.01UF Z
C878 24092341 CERAMIC DISC, 2KV R 470PF K
C879 24206479 ELECTROLYTIC, 50V 4.7UF M 7L 3A
C880 24100103 CERAMIC CHIP, 50V F 0.01UF Z
C884 24640018 ELECTROLYTIC, 160V 220UF
C885 24214471 CERAMIC DISC, 500V B 470PF K
C886 24214471 CERAMIC DISC, 500V B 470PF K
C887 24764471 ELECTROLYTIC, 25V 470UF M
C889 24764222 ELECTROLYTIC, 25V 2200UF M
C893 24092341 CERAMIC DISC, 2KV R 470PF K
* C896 24092553 CERAMIC DISC, AC250V B 470PF K
C897 24092557 CERAMIC DISC, AC250V E 2200PF M
C899 24539224 PLASTIC FILM, 50V 0.22UF J
C902 24092345 CERAMIC DISC, 2KV 1000PF K
C904 24109391 CERAMIC CHIP CK73B 50V 390PF K
C905 24109331 CERAMIC CHIP, 50V B 330PF K
C907 24109391 CERAMIC CHIP CK73B 50V 390PF K
C910 24766478 ELECTROLYTIC, 50V 0.47UF M
C912 24763471 ELECTROLYTIC, 16V 470UF M
C913 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A
C971 24203470 ELECTROLYTIC, 16V 47UF M 7L 3A
CA01 24232103 CERAMIC DISC, 50V F 0.01UF Z
CA02 24105101 CERAMIC CHIP, 50V CH 100PF J
CA03 24105220 CERAMIC CHIP, 50V CH 22PF J
CA04 24105220 CERAMIC CHIP, 50V CH 22PF J
CA30 24105270 CERAMIC CHIP, 50V CH 27PF J
CA42 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A
CA45 24109103 CERAMIC CHIP, 50V B 0.01UF K
CA51 24109272 CERAMIC CHIP, 50V B 2700PF K
CA52 24109152 CERAMIC CHIP, 50V B 1500PF K
CA53 24105181 CERAMIC CHIP, 50V CH 180PF J
CA54 24766330 ELECTROLYTIC, 50V 33UF M
CA55 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A
CA58 24105101 CERAMIC CHIP, 50V CH 100PF J
CA60 24206229 ELECTROLYTIC, 50V 2.2UF M 7L 3A
Location
Parts No. Description
No.
CC01 24109103 CERAMIC CHIP, 50V B 0.01UF K
CC02 24109103 CERAMIC CHIP, 50V B 0.01UF K
CC08 24105330 CERAMIC CHIP, 50V CH 33PF J
CS01 24203220 ELECTROLYTIC, 16V 22UF M 7L 3A
CS02 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A
CS04 24109102 CERAMIC CHIP, 50V B 1000PF K
CS05 24109102 CERAMIC CHIP, 50V B 1000PF K
CS07 24109102 CERAMIC CHIP, 50V B 1000PF K
CS15 24109102 CERAMIC CHIP, 50V B 1000PF K
CV10 24762471 ELECTROLYTIC, 10V 470UF M
CV11 24203220 ELECTROLYTIC, 16V 22UF M 7L 3A
RESISTORS
R101 24011563 CHIP, METAL FILM, 1/20W 56K OHM J
R102 24011123 CHIP, METAL FILM, 1/20W 12K OHM J
R105 24011331 CHIP, METAL FILM, 1/20W 330 OHM J
R106 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J
R107 24011330 CHIP, 1/20W 33 OHM J
R108 24011272 CHIP, 1/20W 2.7K OHM J
R109 24011682 CHIP, METAL FILM, 1/20W 6.8K OHM J
R110 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R111 24011360 METAL FILM CHIP, 1/20W 36 J
R112 24000445 CHIP JUMPER, 1608TYPE
R113 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J
R114 24011472 CHIP, METAL FILM, 1/20W 4.7K OHM J
R116 24011682 CHIP, METAL FILM, 1/20W 6.8K OHM J
R117 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J
R121 24011221 CHIP, METAL FILM, 1/20W 220 OHM J
R122 24000445 CHIP JUMPER, 1608TYPE
R124 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R130 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
R131 24011221 CHIP, METAL FILM, 1/20W 220 OHM J
R132 24011271 CHIP, METAL FILM, 1/20W 270 OHM J
R133 24011271 CHIP, METAL FILM, 1/20W 270 OHM J
R134 24011561 CHIP, METAL FILM, 1/20W 560 OHM J
R135 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R136 24011513 CHIP, METAL FILM, 1/20W 51K OHM J
R139 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J
R140 24011101 CHIP, METAL FILM, 1/20W 100 OHM J
R141 24011331 CHIP, METAL FILM, 1/20W 330 OHM J
R142 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R143 24011333 CHIP, METAL FILM, 1/20W 33K OHM J
R144 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R145 24011303 CHIP, METAL FILM, 1/20W 30K OHM J
R146 24011224 CHIP, METAL FILM, 1/20W 220K OHM J
R147 24011152 CHIP, METAL FILM, 1/20W 1.5K OHM J
R148 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J
R149 24011684 CHIP, METAL FILM, 1/20W 680K OHM J
R150 24000445 CHIP JUMPER, 1608TYPE
R156 24553153 OXIDE METAL FILM, 1W 15K OHM J
R158 24011152 CHIP, METAL FILM, 1/20W 1.5K OHM J
R166 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R167 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R168 24011473 CHIP, METAL FILM, 1/20W 47K OHM J
R169 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R171 24011473 CHIP, METAL FILM, 1/20W 47K OHM J
R172 24011162 CHIP, METAL FILM, 1/20W 1.6K OHM J
R173 24011102 CHIP, METAL FILM, 1/20W 1K OHM J
R174 24011473 CHIP, METAL FILM, 1/20W 47K OHM J
R175 24011223 CHIP, METAL FILM, 1/20W 22K OHM J
R176 24011473 CHIP, METAL FILM, 1/20W 47K OHM J
R177 24011223 CHIP, METAL FILM, 1/20W 22K OHM J
R178 24011103 CHIP, METAL FILM, 1/20W 10K OHM J
R179 24011222 CHIP, METAL FILM, 1/20W 2.2K OHM J
R180 24011473 CHIP, METAL FILM, 1/20W 47K OHM J
R181 24011223 CHIP, METAL FILM, 1/20W 22K OHM J
R182 24011162 CHIP, METAL FILM, 1/20W 1.6K OHM J
– 18 –
