  • Page 1 Kasteel Wartburg BBI.113.CUP...
  • Page 2 Il est conseillé de ne pas orienter de FR - Important ! l’équipement avec toboggans vers le sud. Si le sol ne contribue pas à la stabilité de l’équipement à placer, versez 50L de béton par poteau. © Copyright BOERplay 29-11-2021 Revision: BBI 113 CxP...
  • Page 3 Hoofdafmetingen Hauptabmessungen Dimensiones principales Dimensions principales 4,01 m 2,30 m 1,71 m 0,91 m 0,00 m 2,92 m 2,31 m 1,45 m 0,28 m 0,00 m © Copyright BOERplay 29-11-2021 Revision: BBI 113 CxP...
  • Page 4 Zona libre de obstáculos Zone libre d’obstacle 7,01 m 6,02 m Impact area Opvangzone Ausprallbereich Zona de impacto Zone d‘impact Obstacle free zone Obstakelvrije zone Hindernissfreie raum Zona libre de obstáculos Zone libre d’obstacle © Copyright BOERplay 29-11-2021 Revision: BBI 113 CxP...
  • Page 5 Nivel del suelo para postes de metal Nivel del suelo para postes de plástico o madera Niveau au sol pour poteaux en métal Niveau au sol pour poteaux en plastique ou en bois © Copyright BOERplay 29-11-2021 Revision: BBI 113 CxP...
  • Page 6 - assembly manual - module Montagehandleiding - module Montageanleitung - Moduls Manual de ensamblado - módulo Manuel de montage - module MOD.BBI.125.x MOD.BBI.135 MOD.BBI.118.x MOD.BBI.143.x MOD.BBI.104.x MOD.BBI.132.x MOD.BBI.002.x MOD.BBI.002.x MOD.BBI.101.x MOD.BBI.104.x MOD.BBI.110.x MOD.BBI.119.x MOD.BBI.132.x MOD.BBI.135 © Copyright BOERplay 29-11-2021 Revision: BBI 113 CxP...
  • Page 7 Ø3 mm Ø5 mm Ø11 mm Ø12 mm 4,8mm Only for metal posts Alleen voor metalen staanders Nur für Pfosten aus Metall Solo para postes de metal Seulement pour poteaux en métal © Copyright BOERplay 29-11-2021 Revision: BBI 113 CxP...
  • Page 8 1 / 8 Montagevolgorde Montagereihenfolge Orden de esemblado Ordre de montage assembly manual module MOD.BBI.002.x 2 / 8 assembly manual module MOD.BBI.132.x © Copyright BOERplay 29-11-2021 Revision: BBI 113 CxP...
  • Page 9 3 / 8 Montagevolgorde Montagereihenfolge Orden de esemblado Ordre de montage assembly manual module MOD.BBI.118.x 4 / 8 assembly manual module MOD.BBI.125.x © Copyright BOERplay 29-11-2021 Revision: BBI 113 CxP...
  • Page 10 5 / 8 Montagevolgorde Montagereihenfolge Orden de esemblado Ordre de montage assembly manual module MOD.BBI.104.x 6 / 8 assembly manual module MOD.BBI.143.x © Copyright BOERplay 29-11-2021 Revision: BBI 113 CxP...
  • Page 11 7 / 8 assembly manual module MOD.BBI.135 8 / 8 BOER PLAY xxx.xxx.xxx EN 1176 www.boerplay.com © Copyright BOERplay 29-11-2021 Revision: BBI 113 CxP...
  • Page 12 LOGBOEK (Onderstaand logboek kan gebruikt worden om te voldoen aan de eisen, gesteld in artikel 14 van het Warenwetbesluit Attractie- en Speeltoestellen) Type aanduiding Figura Play Artikelnummer BBI.113.CUP Naam toestel Kasteel Wartburg Maximale valhoogte 1,5 m Bouwjaar 2023 Certificaat 065444...
  • Page 13 LOGBOEK Inspectie en onderhoud Datum Tijdstip Naam Naam Geconstateerde Te vervangen inspectie inspectie uitvoerder uitvoerder gebreken onderdelen onderhoud onderhoud inspectie onderhoud Ongevallen Genomen Datum Leeftijd Vermoedelijk oorzaak letsel Opgetreden persoonlijk letsel maatregel n.a.v. ongeval slachtoffer ongeval...
  • Page 14 Inspectie en onderhoud intervallen Maanden Nr. Inspectie Onderhoud tussen controle Speeltoestel controleren op stabiliteit, goede Ontbrekende onderdelen toevoegen, verbindingen en ontbrekende onderdelen. verbindingen vastdraaien. Ontbrekende Bouten, schroeven en moeren controleren op bevestigingsmiddelen aanbrengen en ontbreken, vastzitten, corrosie en slijtage gecorrodeerde onderdelen vervangen. Vervangen van versleten onderdelen en/of Ophangingen controleren op slijtage.
  • Page 15 6. Controleer het terrein regelmatig op zaken die er niet thuis horen, onveilig zijn of uitnodigen tot verkeerd gebruik, bijvoorbeeld giftige planten, glas enz. De controle frequentie is afhankelijk van de belasting. 7. Bedenk dat slecht onderhoud leidt tot onveiligheid en aantoonbare snellere verpaupering van de speelomgeving.
  • Page 17 - module Montagehandleiding - module Montageanleitung - Modul Manual de ensamblado - módulo Manuel de montage - module MOD BBI 002 U © Copyright BOERplay 18-8-2023 Revision: C...
  • Page 18 A (18x) SME.BBI.053.372 Detail B (4x) Detail A (18x) 40 mm 35 mm BSR.026.008.040 KST.DON.010.060 BSR.026.008.035 BSR.030.008.016 BSR.030.008.016 BSR.011.008.015 BSR.010.008.008 KST.DOP.010.060 BSR.010.008.008 BSR.011.008.015 BSR.026.008.035 BSR.026.008.040 BSR.030.008.016 KST.BBI.011.LPE KST.DON.010.060 KST.DOP.010.060 SME.BBI.053.372 MOD BBI 002 U © Copyright BOERplay 18-8-2023 Revision: C...
  • Page 19 Postes de metal Postes de plástico o madera Poteaux en métal Poteaux en plastique ou en bois KST.LAM.100.100 18 mm 50 mm ø5mm ø3mm x 30 BSR.014.005.052 BSR.002.005.050 BSR.014.005.052 KST.LAM.100.100 BSR.002.005.050 MOD BBI 002 U © Copyright BOERplay 18-8-2023 Revision: C...
  • Page 20 Poteaux en plastique ou en bois 70 mm KST.LAM.013.006 BSR.002.005.070 Glue NL Lijm DE Kleber ES Pegamento 50 mm FR Colle ø5mm ø3mm x 30 BSR.002.005.050 BSR.014.005.052 18 mm BSR.002.005.050 BSR.014.005.052 KST.LAM.013.006 MOD BBI 002 U © Copyright BOERplay 18-8-2023 Revision: C...
  • Page 21 OME.KAP.100.204 SMD.BBI.500 S.BBI.005.K S.BBI.002.K S.BBI.002.K S.BBI.002.K Detail C (8x) 120 mm BSR.026.010.120 KST.DON.010.060 BSR.030.010.002 BSR.010.010.010 KST.DOP.010.060 BSR.010.010.010 BSR.026.010.120 BSR.030.010.002 KST.DON.010.060 KST.DOP.010.060 ! Max 12 Nm ! SMD.BBI.500 MOD BBI 002 U © Copyright BOERplay 18-8-2023 Revision: C...
  • Page 22 Plastic or wooden posts Metalen staanders Kunststof of houten staanders Pfosten aus Metall Pfosten aus Kunststoff oder Holz Postes de metal Postes de plástico o madera Poteaux en métal Poteaux en plastique ou en bois MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 23 1 / 17 Detail B (3x) KST.DON.010.020 BSR.030.010.002 OPE.BBI.336.062 BSR.023.010.065 KST.DOP.010.060 Detail A (3x) KST.DON.010.020 BSR.030.010.002 BSR.010.010.010 KST.DOP.010.060 BSR.047.006.030 OPE.BBI.244.072 BSR.010.010.010 BSR.023.010.065 BSR.030.010.002 BSR.047.006.030 KST.BUS.012.020 KST.DON.010.020 KST.DOP.010.060 OPE.BBI.336.062 OPE.BBI.244.072 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 24 BSR.021.010.040 KST.DOP.010.010 BSR.010.010.010 BSR.030.010.002 KST.BUS.012.020 KST.DON.010.060 KST.DON.010.060 KST.DOP.010.010 Detail D (4x) OPE.BBI.030.xxx KST.ROR.006.000 BSR.010.010.010 BSR.021.010.040 BSR.030.010.002 BSR.053.005.030 KST.ROR.006.000 BSR.053.005.030 KST.BUS.012.020 KST.DON.010.060 BSR.053.005.030 KST.DOP.010.010 KST.ROR.006.000 OPE.BBI.030.010 OPE.BBI.038.090 OPE.BBI.030.022 30 mm OPE.BBI.030.032 OPE.BBI.038.090 OPE.BBI.236.062 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 25 3 / 17 OPE.BBI.245.062 KST.BBI.013.LPE OPE.BBI.246.072 KST.BBI.013.LPE OPE.BBI.247.062 KST.BBI.013.LPE OPE.BBI.248.072 KST.BBI.013.LPE OPE.BBI.098.062 Detail E (16x) ✔ BSR.010.008.008 BSR.010.008.008 BSR.052.008.060 KST.BBI.013.LPE OME.BBI.021 OME.BBI.021 OPE.BBI.098.062 BSR.052.008.060 OPE.BBI.245.062 OPE.BBI.246.072 OPE.BBI.247.062 OPE.BBI.248.072 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 26 4 / 17 F (3x) F (3x) F (3x) F (3x) Detail F (12x) KST.ROR.006.000 BSR.053.005.035 BSR.053.005.035 35 mm KST.ROR.006.000 BSR.053.005.035 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 27 5 / 17 OPE.BBI.237.062 OPE.BBI.239.072 Detail D (4x) OPE.BBI.030.xxx KST.ROR.006.000 KST.ROR.006.000 BSR.053.005.030 BSR.053.005.030 BSR.053.005.030 KST.ROR.006.000 OPE.BBI.030.010 OPE.BBI.030.022 OPE.BBI.038.090 OPE.BBI.030.032 OPE.BBI.038.090 30 mm OPE.BBI.237.062 OPE.BBI.239.072 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 28 6 / 17 KST.BBI.025.LPE OPE.BBI.097.072 KST.BBI.013.LPE KST.BBI.013.LPE OPE.BBI.096.062 Detail E (8x) ✔ BSR.010.008.008 BSR.010.008.008 BSR.052.008.060 OME.BBI.021 KST.BBI.013.LPE BSR.052.008.060 KST.BBI.025.LPE OME.BBI.021 OPE.BBI.096.062 OPE.BBI.097.072 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 29 7 / 17 KST.BBI.026.LPE OPE.BBI.249.072 OPE.BBI.242.072 OPE.BBI.243.072 Detail E (9x) ✔ BSR.010.008.008 BSR.010.008.008 BSR.052.008.060 OME.BBI.021 KST.BBI.026.LPE BSR.052.008.060 OME.BBI.021 OPE.BBI.249.072 OPE.BBI.242.072 OPE.BBI.243.072 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 30 SME.BBI.037.916 SME.BBI.037.916 SME.BBI.037.916 OPE.BBI.241.072 Detail I (1x) BSR.021.010.060 BSR.035.010.030 BSR.021.010.060 BSR.035.010.030 ✔ OPE.BBI.238.xxx Detail G (4x) Detail H (2x) BSR.011.008.015 BSR.011.008.015 BSR.021.010.060 BSR.030.008.016 BSR.030.008.016 BSR.052.008.035 BSR.035.010.030 BSR.052.008.035 KST.LAM.042.003 OPE.BBI.238.xxx KST.LAM.042.003 SME.BBI.037.916 OPE.BBI.241.072 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 31 9 / 17 Detail J (2x) BSR.025.006.040 KST.KLM.042.010 BSR.010.006.006 BSR.010.006.006 BSR.025.006.040 KST.KLM.042.010 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 32 10 / 17 Detail J (6x) BSR.025.006.040 KST.KLM.042.010 BSR.010.006.006 BSR.010.006.006 BSR.025.006.040 KST.KLM.042.010 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 33 11 / 17 F (3x) F (3x) Detail F (6x) KST.ROR.006.000 BSR.053.005.035 35 mm KST.ROR.006.000 BSR.053.005.035 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 34 SME.BBI.036.916 SME.BBI.036.916 SME.BBI.036.916 OPE.BBI.240.062 Detail K (1x) BSR.021.010.060 BSR.035.010.030 BSR.021.010.060 BSR.035.010.030 ✔ OPE.BBI.238.xxx Detail G (4x) Detail H (2x) BSR.011.008.015 BSR.011.008.015 BSR.021.010.060 BSR.030.008.016 BSR.030.008.016 BSR.052.008.035 BSR.035.010.030 BSR.052.008.035 KST.LAM.042.003 OPE.BBI.238.xxx KST.LAM.042.003 SME.BBI.036.916 OPE.BBI.240.062 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 35 13 / 17 ✔ Detail M (6x) Detail J (2x) KST.KLM.042.010 BSR.025.006.040 KST.KLM.042.010 BSR.010.006.006 BSR.010.006.006 BSR.025.006.040 KST.KLM.042.010 BSR.053.005.035 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 36 14 / 17 Detail G (3x) BSR.011.008.015 BSR.030.008.016 BSR.052.008.035 BSR.011.008.015 BSR.030.008.016 BSR.052.008.035 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 37 15 / 17 Detail J (6x) BSR.025.006.040 KST.KLM.042.010 BSR.010.006.006 BSR.010.006.006 BSR.025.006.040 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 38 16 / 17 Detail F (3x) KST.ROR.006.000 BSR.053.005.035 35 mm BSR.030.010.002 KST.BUS.012.020 KST.ROR.006.000 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision: BSR.053.005.035...
  • Page 39 17 / 17 Ground level Maaiveld Bodennahe Nivel del suelo Niveau au sol MOD.BBI.143.A BSR.014.005.053 MOD.BBI.143.G BSR.002.005.070 KST.ROR.006.000 Detail N (8x) MOD.BBI.143.A MOD.BBI.143.G 30 mm 70 mm BSR.014.005.053 BSR.002.005.070 KST.ROR.006.000 ø5mm ø3mm x 30 MOD BBI 143 © Copyright BOERplay 20-7-2020 Revision:...
  • Page 40 Metalen staanders Kunststof of houten staanders Pfosten aus Metall Pfosten aus Kunststoff oder Holz Postes de metal Postes de plástico o madera Poteaux en métal Poteaux en plastique ou en bois MOD BBI 125 © Copyright BOERplay 4-3-2020 Revision: A...
  • Page 41 1 / 5 OPE.BBI.078.062 OPE.BBI.058.072 Detail A (4x) OPE.BBI.030.xxx KST.ROR.006.000 KST.ROR.006.000 BSR.053.005.030 BSR.053.005.030 OPE.BBI.038.090 30 mm BSR.053.005.030 KST.ROR.006.000 OPE.BBI.030.010 OPE.BBI.030.022 OPE.BBI.030.032 OPE.BBI.038.090 OPE.BBI.058.072 OPE.BBI.078.062 MOD BBI 125 © Copyright BOERplay 4-3-2020 Revision: A...
  • Page 42 OPE.BBI.059.072 B (3x) C (2x) B (3x) C (4x) C (3x) Detail B (6x) Detail C (9x) BSR.011.008.015 BSR.030.008.016 BSR.052.008.035 ✔ BSR.010.008.008 OME.BBI.021 BSR.052.008.060 BSR.010.008.008 BSR.011.008.015 BSR.030.008.016 BSR.052.008.035 BSR.052.008.060 OME.BBI.021 OPE.BBI.059.072 MOD BBI 125 © Copyright BOERplay 4-3-2020 Revision: A...
  • Page 43 3 / 5 OPE.BBI.060.072 Detail D (4x) BSR.035.008.002 KST.DON.010.020 BSR.052.008.060 BSR.010.008.008 BSR.010.008.008 KST.DOP.010.020 BSR.035.008.002 BSR.052.008.060 KST.DON.010.020 KST.DOP.010.020 OPE.BBI.060.072 MOD BBI 125 © Copyright BOERplay 4-3-2020 Revision: A...
  • Page 44 OPE.BBI.044.032 OPE.BBI.064.022 OME.BBI.056 OME.BBI.056 Detail B (8x) ✔ BSR.010.008.008 OME.BBI.021 BSR.052.008.060 Detail E (4x) BSR.010.008.008 BSR.010.010.010 BSR.030.010.002 BSR.026.010.040 BSR.010.010.010 BSR.030.010.002 KST.DOP.010.020 BSR.052.008.060 BSR.026.010.040 KST.DON.010.020 KST.DON.010.020 KST.DOP.010.020 OME.BBI.021 OME.BBI.056 OPE.BBI.044.032 OPE.BBI.045.032 OPE.BBI.064.022 MOD BBI 125 © Copyright BOERplay 4-3-2020 Revision: A...
  • Page 45 BSR.026.010.040 BSR.030.010.002 BSR.030.010.002 KST.DON.010.020 BSR.010.010.010 KST.DOP.010.020 KST.DOP.010.020 BSR.026.010.040 SME.BBI.002 KST.DON.010.020 MOD.BBI.125.A BSR.014.005.052 MOD.BBI.125.G BSR.002.005.050 KST.ROR.006.000 Detail F (2x) MOD.BBI.125.A MOD.BBI.125.G 18 mm 50 mm BSR.014.005.052 BSR.002.005.050 KST.ROR.006.000 ø5mm ø3mm x 30 MOD BBI 125 © Copyright BOERplay 4-3-2020 Revision: A...
  • Page 46 Plastic or wooden posts Metalen staanders Kunststof of houten staanders Pfosten aus Metall Pfosten aus Kunststoff oder Holz Postes de metal Postes de plástico o madera Poteaux en métal Poteaux en plastique ou en bois © Copyright BOERplay 26-2-2020 Revision: MOD BBI 104...
  • Page 47 1 / 3 Detail A (5x) ✔ BSR.010.008.008 OME.BBI.021 BSR.052.008.060 OPE.BBI.011.061 OPE.BBI.010.062 OPE.BBI.028.062 BSR.010.008.008 BSR.052.008.060 OME.BBI.021 OPE.BBI.010.062 OPE.BBI.011.061 OPE.BBI.028.062 © Copyright BOERplay 26-2-2020 Revision: MOD BBI 104...
  • Page 48 2 / 3 Detail B (1x) OPE.BBI.030.xxx KST.ROR.006.000 KST.ROR.006.000 BSR.053.005.030 BSR.053.005.030 OPE.BBI.038.090 30 mm Detail C (1x) OPE.BBI.038.090 OPE.BBI.029.072 BSR.053.005.030 KST.ROR.006.000 KST.ROR.006.000 BSR.053.005.030 OPE.BBI.031.010 30 mm BSR.053.005.030 KST.ROR.006.000 OPE.BBI.029.072 OPE.BBI.030.032 OPE.BBI.031.010 OPE.BBI.038.090 © Copyright BOERplay 26-2-2020 Revision: MOD BBI 104...
  • Page 49 Niveau au sol pour poteaux en métal Niveau au sol pour poteaux en plastique ou en bois KST.ROR.006.000 Detail D (4x) MOD.BBI.104.A MOD.BBI.104.G 30 mm 70 mm BSR.014.005.053 BSR.002.005.070 KST.ROR.006.000 ø5mm ø3mm x 30 © Copyright BOERplay 26-2-2020 Revision: MOD BBI 104...
  • Page 50 Modul manual de instalación del módulo instructions d'installation du module MOD BBI 135 © Copyright BOERplay 10-2-2020 Revision: A...
  • Page 51 1 / 3 POL.BBI.003.203 12 mm 12 mm POL.BBI.003.203 MOD BBI 135 © Copyright BOERplay 10-2-2020 Revision: A...
  • Page 52 2 / 3 Detail A (4x) BSR.023.010.040 KST.ROR.010.000 BSR.017.010.005 BSR.017.010.005 BSR.023.010.040 KST.ROR.010.000 POL.BBI.003.203 MOD BBI 135 © Copyright BOERplay 10-2-2020 Revision: A...
  • Page 53 3 / 3 Detail B (4x) BSR.030.010.002 BSR.011.010.020 BSR.011.010.020 BSR.030.010.002 MOD BBI 135 © Copyright BOERplay 10-2-2020 Revision: A...
  • Page 54 Metalen staanders Kunststof of houten staanders Pfosten aus Metall Pfosten aus Kunststoff oder Holz Postes de metal Postes de plástico o madera Poteaux en métal Poteaux en plastique ou en bois MOD BBI 132 © Copyright BOERplay 3-11-2020 Revision: B...
  • Page 55 1 / 5 11mm Remove floor fixings (2x) NL Verwijder vloer bouten (2x) DE Bodenbefestigungen entfernen (2x) ES Retire las fijaciones del piso (2x) FR Retirer les fixations au sol (2x) MOD BBI 132 © Copyright BOERplay 3-11-2020 Revision: B...
  • Page 56 2 / 5 SME.BBI.003.916 Detail A (2x) BSV.030.010.002 BSV.023.010.050 BSV.023.010.050 BSV.030.010.002 SME.BBI.003.916 MOD BBI 132 © Copyright BOERplay 3-11-2020 Revision: B...
  • Page 57 3 / 5 MOD.BBI.132.A BSR.014.005.052 MOD.BBI.132.G BSR.002.005.050 KST.ROR.006.000 Detail B (2x) MOD.BBI.132.A MOD.BBI.132.G 18 mm 50 mm BSR.014.005.052 BSR.002.005.050 KST.ROR.006.000 ø5mm ø3mm x 30 MOD BBI 132 © Copyright BOERplay 3-11-2020 Revision: B...
  • Page 58 4 / 5 OPE.BBI.090.062 SNT.BBI.004 Detail C (3x) BSR.023.010.040 BSR.034.010.002 KST.ROR.010.000 BSR.023.010.040 BSR.034.010.002 KST.ROR.010.000 OPE.BBI.090.062 SNT.BBI.004 MOD BBI 132 © Copyright BOERplay 3-11-2020 Revision: B...
  • Page 59 5 / 5 ✔ ✔ 0,87 m 1,24 m Detail D (2x) BSV.020.006.040 BSV.035.006.020 OPE.BBI.223.xxx BSV.010.006.006 BSV.035.006.020 BSV.020.006.040 BSV.035.006.020 BSV.010.006.006 OPE.BBI.223.xxx MOD BBI 132 © Copyright BOERplay 3-11-2020 Revision: B...
  • Page 60 Plastic or wooden posts Metalen staanders Kunststof of houten staanders Pfosten aus Metall Pfosten aus Kunststoff oder Holz Postes de metal Postes de plástico o madera Poteaux en métal Poteaux en plastique ou en bois MOD BBI 118 © Copyright BOERplay 28-2-2020 Revision:...
  • Page 61 1 / 2 OPE.BBI.061.072 Detail A (3x) BSR.011.008.015 BSR.030.008.016 BSR.030.008.016 BSR.052.008.035 OPE.BBI.061.072 BSR.011.008.015 BSR.030.008.016 BSR.052.008.035 MOD BBI 118 © Copyright BOERplay 28-2-2020 Revision:...
  • Page 62 2 / 2 MOD.BBI.118.A BSR.014.005.053 MOD.BBI.118.G KST.ROR.006.000 BSR.002.005.070 Detail B (4x) MOD.BBI.118.A MOD.BBI.118.G 30 mm 70 mm BSR.014.005.053 BSR.002.005.070 KST.ROR.006.000 ø5mm ø3mm x 30 MOD BBI 118 © Copyright BOERplay 28-2-2020 Revision:...
