SERVICE AND PARTS MANUAL
®
BROASTER
HDM-4 AND HDM-6
PERFECT HOLD™ DELI CASE
Be sure ALL installers read, understand, and have access to this manual at all times.
Genuine Broaster Chicken®, Broasted®, Broaster Chicken®, Broaster Foods®. and Broasterie® are registered
trademarks. Usage is available only to licensed operators with written authorization from The Broaster Company.
Broaster Company
2855 Cranston Road, Beloit, WI 53511-3991
608/365-0193 broaster.com
© 2001 Broaster Company
Design Certified By:
Manual #15376 11/01 Rev 11/22
Printed In U.S.A.
NSF, UL and CUL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PERFECT HOLD HDM-4 and is the answer not in the manual?

Questions and answers

Related Manuals for Broaster PERFECT HOLD HDM-4

Summary of Contents for Broaster PERFECT HOLD HDM-4

  • Page 1 Be sure ALL installers read, understand, and have access to this manual at all times. Genuine Broaster Chicken®, Broasted®, Broaster Chicken®, Broaster Foods®. and Broasterie® are registered trademarks. Usage is available only to licensed operators with written authorization from The Broaster Company. Broaster Company 2855 Cranston Road, Beloit, WI 53511-3991 608/365-0193 broaster.com...
  • Page 3 Indicates a potentially hazardous situation which, if not avoided, could result in minor injury, property damage or both. All adjustments and repairs shall be made Rags or papers contain- by an authorized Broaster Company repre- ing cooking oil can catch sentative. fire if exposed to heat. Laundering will not remove the oil.

  • Page 4: Table Of Contents

    Upper Control Panel.................... 4 - 3 Lower Control Panel.................... 4 - 4 Power Input Parts, HDM-4 .................. 4 - 5 Power Input Parts, HDM-6 .................. 4 - 6 Power Input Parts, HDM-6 (Effective BD6A40)........... 4 - 7 broaster.com Manual #15376 12/14...

  • Page 6: Electric Power Supply

    3 PH HDM-6 6 ft Countertop Deli Case 120/208 HDM-6 6 ft Complete Deli Case 4500 4-wire grounded 1 PH /240 120/208 4500 4-wire grounded 1 PH HDM-6 6 ft Countertop Deli Case /240 broaster.com Manual #15376 11/01 Rev 12/14...

  • Page 7: Model Hdm-4 Wiring Diagram

    Model HDM-4 Wiring Diagram: broaster.com Manual #15376 11/01 Rev 12/14...

  • Page 8: Model Hdm-6 Single Phase Wiring Diagram

    Model HDM-6 Single Phase Wiring Diagram: broaster.com Manual #15376 11/01 Rev 12/14...

  • Page 9: Model Hdm-6 Single Phase Wiring Diagram (Effective Bd6A40)

    Model HDM-6 Single Phase Wiring Diagram: (EFFECTIVE BD6A40) broaster.com Manual #15376 11/01 Rev 10/20...

  • Page 10: Model Hdm-6 Three Phase Wiring Diagram

    Model HDM-6 Three Phase Wiring Diagram: broaster.com Manual #15376 11/01 Rev 12/14...

  • Page 11: Model Hdm-6 Three Phase Wiring Diagram (Effective Bd6A40)

    Model HDM-6 Three Phase Wiring Diagram: (EFFECTIVE BD6A40) broaster.com Manual #15376 11/01 Rev 10/20...
  • Page 12 Model HDM-4XP broaster.com Manual #15376 11/01 Rev 12/14...
  • Page 13 Model HDM-6XP FL10 H1- TUBULAR HEATING TUBULAR HEATING ELEMENT- 2000W ELEMENT- 1300W broaster.com Manual #15376 11/01 Rev 12/14...

  • Page 14: Control Panel Service

    2. Remove screws (9) from desired panel. HDM-6: Three 20 Amp fuses are mounted in the 3. Pull panel out and down so back is power input box. visible. 5. Main Power Switch: Turns unit on or off. broaster.com Manual #15376 12/14...

  • Page 15: Display Lamp Dimmer

    2. Remove timer knob (11). 3. Disconnect timer wires. 4. Remove mounting screws from the timer. 5. Install new timer (2) in reverse order. Be sure all wire connections are secure and in their original location. broaster.com Manual #15376 12/14...

  • Page 16: Indicator Lights

    5. Remove fuse cap (14) and remove cator light are 240 volt all other indicator fuse (4). Check across fuse with an lights are 120 volt. ohmmeter. Meter should indicate a closed circuit. Replace fuse with cor- rect amperage fuse. See label. broaster.com Manual #15376 12/14...

  • Page 17: Fuse Holder Replacement

    Meter should indi- cate a closed circuit. 6. Check across remaining terminals with an ohmmeter. Meter should indicate a closed circuit. If not, power switch is faulty. broaster.com Manual #15376 12/14...

  • Page 18: Thermostat

    1. Slide bulb into bulb guard. 2. Install large capillary nut and tighten. 3. Install small cinch nut finger tight. Turn 1/4 with a wrench. DO NOT over- tighten small cinch nut, thermostat damage may occur. broaster.com Manual #15376 12/14...

  • Page 20: Display Lamp Sockets

    6. Remove retaining guard (4) by sliding and in their original location. upwards until it is free. 7. Receptacle assembly can now be pushed out from the inside of the well and removed. broaster.com Manual #15376 11/01 rev 12/14...

  • Page 21: Cooling Fan

    3. Pull panel out and down so back is vis- ible. 4. Disconnect one wire from suspected fan (5). 5. Check across two wires with an ohm- meter. Meter should indicate a closed circuit. If not, fan is faulty. broaster.com Manual #15376 11/01 rev 12/14...

  • Page 22: Replacement Parts

    4 - REPLACEMENT PARTS Outer Parts: broaster.com Manual #15376 11/01 Rev 12/21...
  • Page 23 Bottom Door Glide 14258 14258 14265 14765 RH Door Assembly** Drive Screw 15362 15362 Top Door Glide (handle end) 14257 14257 Cooling Fan Not Shown 12943 12943 Door Catch Spacer 15333 15334 Cont’d on next page broaster.com Manual #15376 11/01 Rev 01/22...
  • Page 24 Inner Air Duct 15295 15310 Top Door Glide 15428 15428 (Opp handle end) As viewed from the back of the unit. Includes all glides. This designation is as viewed from the front of the unit. broaster.com Manual #15376 11/01 Rev 01/22...

  • Page 25: Upper Control Panel

    Part No. Indicator Light 120V 14340 14340 Indicator light 220V 15112 15112 Timer 12911 12911 14337 14337(long) Dimmer Panel 14805(short) Dimmer 14341 14341 Dimmer Knob 12912 12912 Timer knob 12912 12912 Screw 14963 14963 broaster.com Manual #15376 11/01 Rev 11/22...

  • Page 26: Lower Control Panel

    14442 Ceramic Wire Nut Not Shown 14911 14911 * Located in power input box on HDM-6 only. ** Effective BD6A40 ) Prior to S/N BD6A40 there were 3 #14509 holders and 3 #14510 fuses broaster.com Manual #15376 11/01 Rev 12/21...

  • Page 27: Power Input Parts, Hdm-4

    Power Input Parts HDM- broaster.com Manual #15376 11/01 Rev 12/14...

  • Page 28: Power Input Parts Hdm-6

    Power Input Parts HDM-6 broaster.com Manual #15376 11/01 Rev 12/14...

  • Page 29: Power Input Parts Hdm-6 (Effective Bd6A40)

    Power Input Parts HDM-6 (EFFECTIVE BD6A40) broaster.com Manual #15376 11/01 Rev 12/14...
