Summary of Contents for Frizzlife G Series
- Page 1 OWNER’S MANUAL G r a v i t y - F e d W a t e r F i l t e r S y s t e m Applicable Model No. G190 - Standard G210 - Standard G210 - Scale G210 - Pro G210 - Prox...
-
Page 2: Table Of Contents
CONTENT 1. G-Series Overview 2. Before Installation Inspect The Package Specifications Precautions Product Introduction 3. Installation Guide Installation Steps 4. Filter Replacement Guide Replacement Filters Replacement Instruction 5. Use Tips 6. Maintenance 7. Frequently Asked Questions 8. Limited Product Warranty 9. -
Page 3: G-Series Overview
Register to activate your warranty with Frizzlife. Scan the QR code to register support@frizzlife.com Email us your order ID and full name at Find the Installation Video Search “Frizzlife Gravity-Fed Water Filter System Installation” on www.youtube.com 1. G-Series Overview Model:... -
Page 4: Before Installation
Please take out the system and all the components from the box. Inspect them carefully according to “Product Introduction”, and make sure nothing is missing or damaged during shipping. If any parts are cracked or broken, please do not proceed with installation, and contact Frizzlife for an exchange or diagnosis. E-mail: support@frizzlife.com Specifications... -
Page 5: Precautions
Precautions 1. For cold water use only. 2. Do not allow children under 3 years of age to have access to small parts during the installation of this product. 3. Testing was performed under standard laboratory conditions, actual performance may vary. 4. -
Page 6: Product Introduction
Product Introduction Lid Knob Knob rubber washer Knob metal washer Lid Screw Anti-Slip Mat 3,4,5 have been Filter Cartridge pre-assembled together. Upper Chamber Sealing Rings Stand* (2 pcs) (Only applicable to G210-Scale/G210-Pro/G210-Prox) Wing Nut Washing Funnel Rubber Disc Washer 6.7.8 have been Metal Disc Washer pre-assembled together. -
Page 7: Installation Guide
3.Installation Guide Installation Steps Step 1：Lid Knob Assembly Insert the screw into the lid. Fasten the knob onto the lid with the screw. Knob Screw Knob Rubber Washer 3,4,5 have been Knob Metal Washer pre-assembled together. Screw Step 2: Spigot Assembly For G190-Standard/ G210-Standard/G210-Scale/G210-Pro : Push the metal disc washer and rubber disc washer to the end, close to the spigot, of its thread rod with force. - Page 8 For G210-Prox : Push the metal disc washer and rubber disc washer to the end, close to the spigot, of its thread rod with force. Insert the well assembled spigot into the lower chamber. Install the one flat rubber washer, metal washer, and finally fasten the hex nut with the wrench. Twist the water level tube onto the spigot.
- Page 9 Step 3：Flush the Filter Cartridge Unscrew the wing nut from the filter cartridge. Take out the two sealing rings from the filter cartridge Attach the washing funnel onto the filter cartridge. Flush the filter cartridge for 3-5 mins. Washing Funnel Wing Nut Sealing Rings Filter Cartridge...
- Page 10 Put the lid on the upper chamber. Upper Chamber Lower Chamber NOTE: The G Series Gravity-Fed Systems also come with non-slip mat, which is convenient for users to use on the table or on the stand, improving stability, safety and aesthetics. For G210-Scale /G210-Pro /G210-Prox: Please put the lower chamber onto the stand provided.
-
Page 11: Filter Replacement Guide
Fill the upper chamber with water, pour out the first bucket of water in the lower chamber. Repeat the step again. After 2-3 times of flushing, you can drink water from Frizzlife Gravity-Fed Water Filter System. 4. Filter Replacement Guide... - Page 12 Step 2：Remove the old cartridge Unscrew the wing nut and sealing ring from the bottom of the upper chamber Take out the old cartridge. Upper Chamber Sealing Ring Wing Nut Step 3: Flush the new cartridge. Unscrew the wing nut from the new cartridge. Take out the two sealing rings from the new cartridge Attach the washing funnel onto the new cartridge.
- Page 13 Step 4: Install the new cartridge Push one sealing ring to the end of the thread rob. Insert the threaded rod of the cartridge into the hole in the upper chamber. Fasten the threaded rod of the cartridge with the other sealing ring and the wing nut. Place the upper chamber into the lower chamber.
-
Page 14: Use Tips
5. Use Tips 1. Please ensure the spigot is in the closed position during the flushing and filtration process. 2. Do not fill the upper chamber if the lower chamber is completely full, as this will cause the lower chamber to overflow. 3. -
Page 15: Frequently Asked Questions
Same thing, if your water is full of minerals, the TDS is very high too. The Frizzlife Gravity-Fed System doesn't remove any of the minerals from water, but only stops harmful contaminants like heavy metals (Lead, Mercury, Cadmium) and over 90% of VOCs and Cysts, and it removes greatly the chlorine (99%) from water. -
Page 16: Limited Product Warranty
To be free of defects in material and workmanship by FRIZZLIFE INC, FRIZZLIFE will replace or repair components of the unit that Frizzlife has deemed to be broken within the limits of the warranty without charge. The customer is not responsible for any freight involved with shipping the item back for inspection and shipment of replace- ment for items. - Page 17 Warranty begins on the date of delivery of product to the customer. 1. Frizzlife is not liable for anything that we deem as abuse of the units, including but not limited to, misuse of product outside of intended use, equipment modifications,...
-
Page 18: Warranty Registration
Do not use outdoors or in a location that is subjected to direct sunlight or freezing. This warranty will not be effective unless and until the Frizzlife is shown to have been used in accordance with the installation and maintenance instructions accompanying the product.
