- Page 1 TEAC FD-505 Combo Drive Installation Guide 3.5” diskette insertion window eject button 5.25” diskette activity indicator 5.25” eject button insertion window Your FD-505 package includes:...
- Page 2 : / your system and install a flat blade screwdriver Note: The FD-505 comes with two optional pieces of hardware to assist you with a Phillips screwdriver correctly installing your Combo Drive. The two pieces are: a power connector adapter cable and an edge card adapter (see below).
- Page 3 Using an IBM PC compatible cable with a twist at the end connector (Figure C) and the factory default strap settings 1 (shown in Figure D). a) Connect the FD-505 Combo drive to connector A: Connector A: is at the end of the cable as shown in the sketch.
- Page 4 Locate your system’s floppy drive ribbon cable. The cable may be keyed to assist a) Connect the FD-505 Combo drive to connector B: (the untwisted connector). with alignment. If yours is not keyed, it should be attached, so that the color strip Connector B: is the connector to left of the end connector.
- Page 5 Sector not found error. Head seek error or drive out of alignment. TEAC Tech Support: To have installation guides, specification sheets, and other product information faxed to you, 7 days a week, 24 hrs. a day, call our Fax on Demand Line at 213-727-7629.
