Moustache MO-CD228P-12 Operation Manual

Both abnormal operations may result in the activation of the automatic thermal
motor overload protection circuit which terminates power to the shredder. A
paper jam could cause the thermal motor overload protection to terminate AC
power to the motor. Never allow the shredder to remain in a jammed condition
with the AC power turned on.
For a minor paper jam
Place the slide switch in the REV position and pull the remaining sheets of paper
out of the feed opening. Remove the not shredded portion of paper from the top
and clean any excess paper shreds from the feed opening.
For a major paper jam
Turn off or unplug the power cord from the AC outlet and wait at least 30
minutes for the thermal overload protection to reset.
Plug in the AC power cord and place the slide switch in the AUTO position.
If paper was left inside the feed opening prior to the overload, place the
slide switch in the REV position, grasp the excess paper from the top, and
pull it out. Be careful to not place your fingers near the feed opening or
serious harm could result. Clear any excess paper shreds from the feed
opening. Place the slide switch in the AUTO position. You are now ready to
resume normal shredding.
Specifications
Shred Type:
Shred Size:
Waste Container Capacity:
Standard Shredding Capacity:
Feed Opening:
Input:
Shredder Dimension:
Shredding Speed:
Continuous Working Time:
Cross Cut
5/32"×1-13/32"(4×35mm)
6.6 gallons(25L)
12 sheets of 80g/m²
220mm
110-120VAC,60Hz,4.0A
14.1"×9.6"×18.3"(360x244x464mm)
2.2m/min
3mins on/30 mins off
CROSS CUT PAPER SHREDDER
MO-CD228P-12 Operation manual
