After connection to the gas supply, check for leaks
with soapy water. Light up the burners and turn the
knobs from max position 1* to minimum position 2*
to check ame stability.
ADAPTING TO DIFFERENT TYPES OF GAS
In order to adapt the appliance to a type of gas
other than the type for which it was manufactured
(indicated on the rating label), follow the dedicated
steps provided after installation drawings.
ELECTRICAL WARNINGS
IMPORTANT: The data relevant to the voltage an
power absorptions are indicated on the rating plate.
The power cable must be long enough to connect
the appliance, once tted in its housing, to the main
power supply. Do not pull the power supply cable.
It must be possible to disconnect the appliance
from the power supply by unplugging it if plug is
accessible, or by a multi-pole switch installed
upstream of the socket in accordance with the wiring
rules and the appliance must be earthed in
conformity with national electrical safety standards.
Do not use extension leads, multiple sockets or
adapters. The electrical components must not be
accessible to the user after installation. Do not use the
appliance when you are wet or barefoot. Do not
operate this appliance if it has a damaged power
cable or plug, if it is not working properly, or if it has
been damaged or dropped.
If the supply cord is damaged, it must be replaced
with an identical one by the manufacturer, its service
agent or similarly quali ed persons in order to avoid a
hazard - risk of electrical shock.
INJECTORS TABLE
Type of gas Type of burner
used
Semi-rapid
NATURAL GAS
Auxiliary
G20
(Methane)
2 Ring
LIQUEFIED Semi-rapid
PETROLEUM GAS Auxiliary
(Butane) G30 2 Ring
LIQUEFIED Semi-rapid
PETROLEUM GAS Auxiliary
G31
(Propane) 2 Ring
Type of gas used
G20 20 mbar
G30 28-30 mbar
G31 37 mbar
ELECTRIC SUPPLY: 220-240 V ~ 50-60 Hz - 1,1W
Injector
marking
97 A
78 A
140 H1
66 A
50
91
66 A
50
91
Model con guration
4 BURNERS
2SR - 1AUX - 1DC
2SR - 1AUX - 1DC
2SR - 1AUX - 1DC

CLEANING AND MAINTENANCE

WARNING: Ensure that the appliance is switched
o and disconnected from the power supply before
performing any maintenance operation; never use
steam cleaning equipment - risk of electric shock.
Do not use abrasive or corrosive products,
chlorine-based cleaners or pan scourers.
DISPOSAL OF PACKAGING MATERIALS
The packaging material is 100% recyclable and is marked with the recycle
symbol .
The various parts of the packaging must therefore be disposed of
responsibly and in full compliance with local authority regulations
governing waste disposal.
DISPOSAL OF HOUSEHOLD APPLIANCES
This appliance is manufactured with recyclable or reusable materials.
Dispose of it in accordance with local waste disposal regulations. For
further information on the treatment, recovery and recycling of household
electrical appliances, contact your local authority, the collection service
for household waste or the store where you purchased the appliance. This
appliance is marked in compliance with European Directive 2012/19/EU,
Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent
negative consequences for the environment and human health.
The symbol on the product or on the accompanying documentation
indicates that it should not be treated as domestic waste but must be
taken to an appropriate collection center for the recycling of electrical and
electronic equipment.
ENERGY SAVING TIPS
Use pots and pans with bottom width equal to that of the cooking zone.
Only use at-bottomed pots and pans.
When possible, keep pot lids on during cooking.
Use a pressure cooker to save even more energy and time.
Place the pot in the middle of the cooking zone marked on the hob.

DECLARATION OF CONFORMITY

This appliance meets the Ecodesign requirements set out in European
Regulation n. 66/2014, in conformity to the European standard EN 30-2-1.
Rated thermal Rated
ow rate consumption
kW
1,65 157 l/h
1,00 95 l/h
3,50 333 l/h
1,65 120 g/h
1,00 73 g/h
3,30 240 g/h
1,65 118 g/h
1,00 71 g/h
3,30 236 g/h
Rated thermal
owrate (kW)
7,80
7,60
7,60
CATEGORY II2H3+
Reduced heat
capacity
kW
min.
0,40
0,40 17
2,20
0,40
0,40 20
2,20
0,40
0,40 25
2,20
Total rated Air required (m3) for
consumption burning 1m3 of gas
743 l/h
553 g/h
543 g/h
Gas pressure
mbar
rat. max.
20 25
28-30 35
37 45
9,52
30,94
23,80
