Skid-Steer Industrial Jib
Model # MIJ-SKD
Operator's Installation
and
Safety Manual
DOC# MIJ-SKD-M
www.haugenattachments.com
Marv Haugen Enterprises Inc. * 1851 Heartland Ave. * Casselton ND 58012 * Phone: 877-580-6218
Advertisement
Table of Contents
Related Manuals for Haugen MIJ-SKD
Summary of Contents for Haugen MIJ-SKD
- Page 1 1851 Heartland Ave. Casselton, ND 58012 Toll Free 877-580-6218 Phone: 701-347-4827 Fax: 701-347-4830 Skid-Steer Industrial Jib Model # MIJ-SKD Operator’s Installation Safety Manual DOC# MIJ-SKD-M www.haugenattachments.com Marv Haugen Enterprises Inc. * 1851 Heartland Ave. * Casselton ND 58012 * Phone: 877-580-6218...
- Page 2 Haugen Skid-Steer Industrial Jibs are designed for use on Skid-Steer loaders and other machines equipped with the skidsteer mount. The MIJ-SKD has been engineered and rated for the Load Capaci- ties as shown on the load chart decal on the Jib and in the load chart in this Manual.
- Page 3 Marv Haugen Enterprises 1851 Heartland Ave. Casselton, ND 58012 Toll Free 877-580-6218 Phone: 701-347-4827 Fax: 701-347-4830 - Operating Rules for Industrial Jibs continued - General Operating Rules 1. Inspections as stated above must be made prior to each use of the Industrial Jib 2.
- Page 4 Horizontal Center of Gravity - See chart below Hook Position Horizontal Center Of Gravity Distance 24.25” 27.75” 24.32” 39.75” 24.45” 51.75” 24.62” 63.25” 25.75” 75.25” 26.72” 87.25” 27.12” 97.25” Marv Haugen Enterprises Inc. * 1851 Heartland Ave. * Casselton ND 58012 * Phone: 877-580-6218...
- Page 5 Multiple Hooks The MIJ-SKD is furnished with a hook and shackle system that can be moved easily to various po- sitions on the Jib as needed. The Hook is rated for a 6000 lbs capacity. More than one hook can be used but the lift capacity would be limited by most extended hook.
- Page 6 All warranty claims must include detailed information regarding make and model of the vehicle on which the Haugen product was mounted, hours of use, description of events that led up to the failure, and any other information helpful in reviewing this claim. All warranty returns must be prepaid. Shipments arriving at our factory on a freight collect basis will be refused by our recieving department.
- Page 7 Marv Haugen Enterprises Inc. * 1851 Heartland Ave. * Casselton ND 58012 * Phone: 877-580-6218...
