Summary of Contents for Vivo MOUNT-TVSG1
- Page 1 Wall Mount Designed for Samsung TV’s SKU: MOUNT-TVSG1 Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/mount-tvsg1...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 Package Contents A (x1) B (x1) C (x1) D (x1) E (x1) Left Wall Plate Right Wall Plate Left TV Plate Right TV Plate Kickstand F (x2) G (x4) H (x2) I (x1) Protective Film Square Pad Round Pad Sticker Included Hardware &...
-
Page 4: Assembly Options
Preparing Your TV Find the center of your TV using Measuring Tape (T-A). Mark the distance of your TV’s top VESA mounting holes on Measuring Tape (T-A). If the VESA holes are 1000mm (39.4”) or greater, swap Left Wall Plate (A) and Right Wall Plate (B), and use the orientation through the remainder of the manual. - Page 5 - Option 1 - VESA Holes - STEP 1 Assemble Left TV Plate (C) and Right TV Plate (D) to the TV using Spacers (M-D) and appropriate Screws (M-A through M-C) and the spacers provided with your TV. Note: Ensure you are using the top VESA holes...
- Page 6 STEP 2 Remove adhesive backing from Square Pads (G) and place them on the back of the TV. Mount Kickstand (E) to one of the lower VESA holes using M8x18mm Screw (M-B) to access the TV ports. Proceed to Wall Mount Instructions on pg.
- Page 7 Option 2 - Recessed Pockets STEP 1 Remove the adhesive backing from Protective Film (F) and place into the Recessed Pockets holes on the TV, making sure the arrows are facing inward. Recessed Pockets STEP 2 Assemble Left TV Plate (C) and Right TV Plate (D) to the TV using Spacers (M-D) and Screws (M-A through M-C).
- Page 8 STEP 3 Remove adhesive backing from Square Pads (G) and place them on the back of the TV. Mount Kickstand (E) to one of the lower VESA holes using M8x18mm Screw (M-B) to access the TV ports. Proceed to Wall Mount Instructions on pg.
-
Page 9: Wall Mounting
Wall Mounting *Note: If installing One Connect Box to the back side of TV, please refer to Mounting Instructions on pg. 14 Stud/Wood Wall Installation Secure Measuring Tape (T-A) to the wall in the desired location using Stickers (I). Align the marks on Measuring Tape (T-A) with the outside of the Tabs on Left Wall Plate (A) and Right Wall Plate (B). - Page 10 Cont’D Insert Anchors (W-B) and mount wall plates using ST5.5x55mm Screws (W-A) and a Phillips screwdriver. Hang Left TV Plate (C) and Right TV Plate (D) over Left Wall Plate (A) and Right Wall Plate (B).
- Page 11 Cont’d Pull down on TV to lock TV Plates (C,D) into Wall Plates (A,B). CONCRETE/BRICK Secure Measuring Tape (T-A) to the wall in the desired location using Stickers (I). Align the marks on Measuring Tape (T-A) with the outside of the Tabs on Left Wall Plate (A) and Right Wall Plate (B).
- Page 12 Cont’d Pre-drill the marked locations, and use an 8mm (5/16”) drill bit drilling appoximately 60mm (2.4”) deep. Insert Anchors (W-B) and mount Wall Plates using ST5.5x55mm Screws (W-A) and a Phillips screwdriver.
- Page 13 Hang Left TV Plate (C) and Right TV Plate (D) over Left Wall Plate (A) and Right Wall Plate (B). ull down on TV to lock TV Plates (C,D) into Wall Plates (A,B).
- Page 14 One Connect Box Mouting Instructions STEP 1 Install the mounting screws that came with your TV to the location on the back of the TV specified in your instructions. Install the One Connect Box by sliding and clicking it into place.
- Page 15 Removing TV From Wall To remove the TV, lift up on one side first to unlock one plate, then lift up and unlock the other side. Lift the TV up and out of the mount.
- Page 16 LAST UPDATED: 02/23/24 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
