KANE VANITY
Assembly Instructions
TOOLS REQUIRED BUT NOT INCLUDED: Phillips head screwdriver
WARNINGS:
Do not throw away packing materials and carton until after assembly.
Assemble all parts on a clean smooth surface.
CARE INSTRUCTIONS:
Avoid direct exposure to sunlight.
Do not place overheat or air conditioning vents.
Adjust levelers so that the furniture sits flat on uneven floors.
Blot spills do not rub, with a clean white cloth.
Do not use harsh chemicals.
Before cleaning any part test a small spot in a hidden area.
You may need to re-tighten all bolts after initial use.
PARTS INCLUDED
(A) Mirror
x1
HARDWARE LIST
(F) Hex key
x1
(J) Spring washer
[1/4"] x20
(N) Nylon strip
x1
EXCLUSIVE AND CONFIDENTIAL PROPERTY OF URBAN OUTFITTERS, INC.
© 2017 UO, Inc. All rights reserved, including all applicable copyright, design and patent
rights. Any unauthorized reproduction, adaptation, distribution or other infringement will be
prosecuted.
(B) Base
(C) Left Leg
x1
(G) Bolt
[1/4" x 2"] x2
(K) Flat washer
[1/4"] x20
(O) Bracket
x2
(D) Right Leg
x1
(H) Bolt
[1/4" x 1"] x10
(L) Half moon metal block
x2
(P) Screw
[M3 x 32mm] x2
URBAN OUTFITTERS
(E) Stretcher
x1
(I) Bolt
[1/4" x 5/8"] x8
(M) Connection bracket
x2
(Q) Screw
[M3 x 19mm] x2
x1
