E-one EXTREME Series Installation Instructions Manual

Hide thumbs Also See for EXTREME Series:

Advertisement

Quick Links

Download this manual
WH101
Installation
Instructions
& Warranty
Information
For Simplex Grinder Pump Stations
Universal Wet Well and
Integrated Ballast Design
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the EXTREME Series and is the answer not in the manual?

Questions and answers

Related Manuals for E-one EXTREME Series

Summary of Contents for E-one EXTREME Series

  • Page 1 WH101 Installation Instructions & Warranty Information For Simplex Grinder Pump Stations Universal Wet Well and Integrated Ballast Design...
  • Page 2 Environment One Grinder Pump Feature Identification 1. GRINDER PUMP BASIN – High density polyethylene (HDPE). 2. ACCESSWAY COVER – Station lid with integral vent (non-traffic rated) 3. ELECTRICAL QUICK DISCONNECT (EQD) – Electrical lead from pump core terminates here (NEMA 6P). 4.
  • Page 3 Figure 1 Overview of WH101 Station Installation FAILURE TO COMPLY WITH INSTALLATION INSTRUCTIONS WILL VOID WARRANTY...
  • Page 4 This is a sewage handling pump and must be vented in accordance with local plumbing codes. Do not install the unit in locations classified as hazardous in accordance with the National Electric Code, ANSI/NFPA 70. All piping and electrical systems must be in compliance with applicable local and state codes.
  • Page 5 5. VENT INSTALLATION: The unit must be properly vented to ensure correct operation of the pump. Standard WH101 stations are supplied with an integrated vent located in the tank cover. The tank cover should be located above finished grade to permit proper station ventilation. Other tank venting options are available.
  • Page 6 on the connector and pull the supply cable out through the connector until it hits the crimped-on stop feature on the cable, approximately 24” from the EQD. **IMPORTANT: All but 24” of the cable must be pulled out of the station, and the portion of the cable between the EQD and the molded in cable breather should be secured in the hook provided to ensure that the pump functions properly.
  • Page 7 splices should not be used. Longer cables are available from E/One. Plug VALVE OPEN VALVE CLOSED and seal all electrical components (junction box, conduit, etc.) inside SLIDER VALVE SLIDER VALVE tank and control panel to ensure a O-RING watertight connection. Failure to seal SCH 80 PVC NIPPLE all moisture may cause premature...
  • Page 8 Adjusting the Height of the Grinder Pump Station TO INCREASE STATION HEIGHT 6 INCHES 1. Increasing station height can be done without cutting the station. Use the E/One Extender cover shroud kit (ND0082G01) and follow the instructions that are included with the kit. TO INCREASE STATION HEIGHT MORE THAN 6 INCHES or TO REDUCE THE STATION HEIGHT: REMOVE EXISTING COVER ASSEMBLY (Fig.
  • Page 9 11. Attach the vent pipe extension with the 2” vent coupling, bringing the vent well above grade. 12. Clean all dirt and debris from top four corrugations on tank. Install the 24” coupler gasket on the tank between the top two corrugations with the white or yellow line facing out and on top. 13.

  • Page 10: Lifting Instructions

    Lifting Instructions FAILURE TO FOLLOW THESE INSTRUCTIONS COMPLETELY WILL VOID THE WARRANTY. Transporting unit to installation site: Always lift a unit from the bottom for the purpose of transportation. The station should be received attached to a pallet for this purpose.
  • Page 11 Grinder Pump Station Ballast Calculations and Assumption Any buried vessel that is submerged or partially submerged in water will be acted on by an upward buoyant force that attempts to return the vessel to a non-submerged state. The magnitude of this buoyant force is equal to the volume of the vessel that is submerged multiplied by the density of water.
  • Page 14 A Precision Castparts Company Environment One Corporation 2773 Balltown Road Niskayuna, New York 12309–1090 Voice: (01) 518.346.6161 Fax: 518.346.6188 NA0067P01 Rev N www.eone.com 12/23...

  • Page 15: General Information

    User Instructions for the Environment One Grinder Pump General Information Your home is served by a low pressure sewer system; the key element is an Environment One grinder pump. The tank collects all solid materials and wastewater from the house. The solid materials are then ground to a small size suitable for pumping as a slurry with the wastewater.

  • Page 16: Limited Warranty

    E/One Sewers Limited Warranty For E/One Extreme D-Series, W-Series & Upgrade Environment One Corporation offers a limited warranty that guarantees its product to be free from defects in material and factory workmanship for a period of two years from the date of installation, or 27 months from the date of shipment, whichever occurs first, provided the product is properly installed,...
